D-Link 10GBASE BiDi SFP+ Transceiver w/o DDM 20Km (DEM-436XT-BXU)

D-Link 10GBASE BiDi SFP+ Transceiver w/o DDM for 20Km Fiber Optic Connectivity

The D-Link 10GBASE BiDi SFP+ Transceiver (DEM-436XT-BXU) is a high-performance solution designed for extending 10Gbps fiber optic connectivity over long distances. This transceiver supports a reach of up to 20 kilometers over single-mode fiber, making it an excellent choice for applications where long-range, high-bandwidth connectivity is required. Utilizing BiDi (Bidirectional) technology, the DEM-436XT-BXU uses a single fiber strand for both transmitting and receiving data, maximizing the efficiency of your fiber infrastructure while maintaining high-speed connectivity across extended distances.

Efficient BiDi Technology for Cost-Effective Long-Distance Connectivity

BiDi technology enables the transmission and reception of data on a single fiber strand, reducing the need for additional fiber cables and thus cutting installation costs. The D-Link DEM-436XT-BXU is ideal for environments where fiber resources are scarce or expensive to install, such as long-distance connections between buildings, campus-wide networks, or data centers. By utilizing a single fiber pair for both transmission and reception, this transceiver doubles the capacity of your fiber optic links, making it an efficient solution for network expansion.

Plug-and-Play Simplicity for Easy Network Integration

The D-Link DEM-436XT-BXU features a plug-and-play design, making installation straightforward and hassle-free. The transceiver is compatible with a wide variety of network devices that support SFP+ ports, providing flexibility and scalability in any network setup. Whether you're extending your existing fiber-optic network or building a new one, this transceiver simplifies the process by enabling easy integration with minimal configuration. Its simple installation process ensures a quick deployment, helping businesses to expand their infrastructure with minimal disruption.

Reliable 10Gbps Performance Over 20Km Without DDM

The D-Link DEM-436XT-BXU offers reliable 10Gbps data transfer over 20 kilometers, making it ideal for high-bandwidth applications across large enterprise networks, data centers, or metropolitan area networks (MANs). As a non-DDM (Digital Diagnostic Monitoring) version, it does not include real-time diagnostics features; however, it still delivers stable performance, ensuring your network remains reliable without the need for additional monitoring tools. This makes it a cost-effective choice for businesses that do not require real-time diagnostic data but still need robust 10Gbps fiber optic connectivity.

Why Choose the D-Link DEM-436XT-BXU 10GBASE BiDi SFP+ Transceiver?

The D-Link DEM-436XT-BXU 10GBASE BiDi SFP+ Transceiver is perfect for organizations seeking long-distance, high-performance fiber optic connectivity at a lower cost. With its BiDi technology, 20km reach, and 10Gbps speed, it provides an efficient solution for extending network capacity without requiring extra fiber runs. Whether you're upgrading your network infrastructure or building a new one, the DEM-436XT-BXU offers reliable, high-speed connectivity for your long-distance communication needs.

Technical Specifications

• Product Type: 10GBASE BiDi SFP+ Transceiver
• Wavelength: 1330nm Tx / 1270nm Rx
• Distance: Up to 20 kilometers
• Data Rate: 10Gbps
• Interface: Single-mode Fiber
• Connector Type: LC
• DDM: No (without Digital Diagnostic Monitoring)
• Application: Data Centers, Enterprise Networks, Long-Distance Fiber Connectivity
• Operating Temperature: 0°C to 70°C (32°F to 158°F)
• Power Consumption: <1W
• GTIN: 0790069262790

Detailed Specification

• Enhanced Small Form-Pluggable (SFP+) form factor
• Hot pluggable
• Support 10G Ethernet
• Feature Digital Diagnostics Monitoring (DDM)
• RoHS Compliant
• Compliant with MSA (Multiple Source Agreement)
• Compliant with IEEE802.3ae and 802.3aq standards
