D-Link 10/100Base-TX UTP to 100Base-FX SC SM 30km Fiber Media Converter
PRODUCT DESCRIPTION
D-Link 10/100Base-TX UTP to 100Base-FX SC Single-mode 30km Fiber Smart Media Converter (DMC-1530SC/E) - Lifetime Local Warranty
D-Link Smart Media Converter for Long-Distance Fiber Connectivity
The D-Link 10/100Base-TX UTP to 100Base-FX SC Single-mode 30km Fiber Smart Media Converter (DMC-1530SC/E) is the ideal solution for extending network connections over long distances using fiber optics. This advanced media converter bridges 10/100Base-TX Ethernet over UTP (unshielded twisted pair) to 100Base-FX single-mode fiber, supporting transmission distances of up to 30 kilometers. Whether you need to connect remote buildings or expand your network reach, the DMC-1530SC/E delivers reliable, high-speed fiber connectivity for demanding network environments.
10/100Base-TX to 100Base-FX Conversion for Enhanced Network Flexibility
Supporting both 10/100Base-TX Ethernet and 100Base-FX fiber, the D-Link DMC-1530SC/E offers a seamless bridge between copper and fiber networks. This versatility allows businesses to upgrade from copper Ethernet to fiber optic technology while maintaining compatibility with existing infrastructure. By converting Ethernet signals to fiber, the DMC-1530SC/E ensures smooth data transmission, higher bandwidth, and extended network reach, making it a great choice for expanding office networks, data centers, or remote connections.
Single-mode Fiber for Reliable, Long-Distance Connectivity
The DMC-1530SC/E uses single-mode SC fiber to provide high-performance, long-distance connectivity. With support for transmission distances up to 30 kilometers, it offers a robust solution for businesses that need to connect remote locations or extend their local network infrastructure. Single-mode fiber is known for its low attenuation, allowing signals to travel further with minimal loss, ensuring that your data remains reliable and high-speed even across large distances. This feature makes the DMC-1530SC/E an excellent option for large campuses, remote offices, or industrial networks.
Smart Media Converter with Advanced Features
As a smart media converter, the D-Link DMC-1530SC/E offers automatic speed negotiation to ensure optimal performance. It intelligently adjusts to the best network speed based on connected devices, improving overall network efficiency. The converter also features LED indicators for power, link, and activity, providing real-time status monitoring to help identify and resolve any issues quickly. These smart features simplify network management and ensure reliable, consistent performance for critical business applications.
Why Choose the D-Link DMC-1530SC/E Smart Media Converter?
The D-Link DMC-1530SC/E offers a comprehensive solution for businesses that need to extend their networks using fiber optics. With its ability to convert 10/100Base-TX Ethernet to 100Base-FX single-mode fiber, it provides a high-performance, long-distance networking solution. The advanced features, such as auto-negotiation and real-time status monitoring, ensure smooth, reliable performance while reducing network management complexity. Whether you're connecting remote offices or upgrading to fiber-optic infrastructure, the DMC-1530SC/E is the ideal choice for expanding your network with ease and efficiency.
Technical Specifications
General
Model: DMC-1530SC/E
Product Type: Smart Media Converter
Conversion Type: 10/100Base-TX (UTP) to 100Base-FX (Fiber)
Deployment: Standalone or chassis-based (DMC-1000 series)
Interfaces
RJ-45 Port: 1 × 10/100Base-TX Ethernet (UTP)
Fiber Port: 1 × 100Base-FX SC connector (single-mode)
LED Indicators: Power, Link/Activity, Speed, Duplex status
Network & Performance
Data Rates: 10 Mbps / 100 Mbps
Duplex Mode: Half-duplex and Full-duplex supported
Flow Control:
- IEEE 802.3x (full-duplex)
- Backpressure (half-duplex)
Forwarding Mode: Store-and-forward
Forwarding Rate: Full wire-speed forwarding
Auto Features: Auto-negotiation and Auto MDI/MDIX
Fiber Specifications
Fiber Type: Single-mode fiber (SMF)
Connector Type: SC
Wavelength: 1310 nm
Maximum Distance: Up to 30 km
Smart Features
Link Loss Carry Forward (LLCF) support
Link Loss Return (LLR) support
Link pass-through functionality
DIP switch configuration (speed, duplex, forced mode)
Intelligent fault detection and link monitoring
Standards & Protocols
IEEE 802.3 (10Base-T)
IEEE 802.3u (100Base-TX / 100Base-FX)
IEEE 802.3x Flow Control
Physical Specifications
Dimensions: Approx. 120 × 88 × 25 mm
Form Factor: Compact metal casing
Installation: Desktop or rack-mount via chassis
Hot-Swappable: Supported when used with chassis
Power
Input: External power adapter (~7.5V / 1.5A typical)
Power Consumption: Low power design (~2–7W range depending on model)
Environmental
Operating Temperature: 0°C to 40°C
Storage Temperature: -25°C to 70°C
Operating Humidity: 10% – 90% non-condensing
Storage Humidity: 5% – 90% non-condensing
Compliance & Certifications
EMI: FCC Class B, CE, VCCI
Safety: Industrial-grade compliance
RoHS: Yes
Key Features
Extends Fast Ethernet over fiber up to 30 km
Smart link fault detection (LLCF/LLR)
Supports both standalone and chassis deployment
Plug-and-play with auto-negotiation
Reliable long-distance connectivity with minimal signal loss
Typical Use Cases
Building-to-building network connectivity
Campus and enterprise network extension
CCTV and surveillance backbone
Industrial and telecom infrastructure
