TP-Link Omada AX1800 Wireless Dual-Band Ceiling Mount Wi-Fi 6 Access Point

TP-Link Omada AX1800 Wireless Dual Band Ceiling Mount Access Point (EAP620 HD) - 5 Years Local Warranty

The EAP620 HD is Omada's AX1800 dual-band Wi-Fi 6 ceiling access point on a Gigabit PoE+ uplink. At 12 W typical draw it is the low-power, low-cost way to bring Wi-Fi 6 efficiency — OFDMA, 1024-QAM, MU-MIMO — to an existing Gigabit PoE network without re-cabling or replacing switches.

AX1800 Wi-Fi 6 on Existing Gigabit Infrastructure

The EAP620 HD serves up to 1201 Mbps on 5 GHz and 574 Mbps on 2.4 GHz through 2x2 internal antennas on each band. Its uplink is a standard Gigabit RJ-45 port with 802.3at PoE, which is the point of this model: it drops into the cabling and switching most Singapore offices already have. Maximum draw is 12 W on the EU model and 13.5 W on the US model, so PoE budget is rarely a constraint even across many APs.

OFDMA Is the Real Upgrade Over Wi-Fi 5

Moving from 802.11ac to Wi-Fi 6 at this capacity class is not about peak speed — it is about how the airtime is shared. OFDMA divides each channel into resource units so the AP serves many small client transmissions in one go instead of queueing them one behind another, which is exactly the pattern a room full of phones, laptops and IoT sensors produces. 1024-QAM and the 4x longer OFDM symbol add per-client throughput and better resilience at range.

Band Steering, Load Balancing and Seamless Roaming

Band steering moves dual-band capable clients onto 5 GHz so the 2.4 GHz radio is left for devices that need it. Load balancing spreads clients across nearby APs instead of letting one become a hotspot, and airtime fairness stops a single slow legacy client consuming a disproportionate share of the channel. Seamless roaming, available once the AP is adopted into a controller, hands clients between APs without dropping calls.

WPA3, Captive Portal and up to 16 SSIDs

The EAP620 HD supports WPA3, WPA2 and WPA Personal and Enterprise with 802.1X, captive portal authentication for guest onboarding, SSID-to-VLAN mapping, wireless MAC address filtering, client isolation and rogue AP detection. Up to 16 SSIDs are available, eight per band, which is enough to separate corporate, guest, IoT and voice traffic across the estate without adding hardware.

Central Management Under Omada SDN

Adopted into an Omada Cloud-Based Controller, OC300, OC200 or the Omada Software Controller, the EAP620 HD is configured, monitored and updated alongside every other Omada gateway, switch and AP on site, with no licence fee for cloud access. Multi-site management, L3 management and a management VLAN are supported, along with SNMP v1/v2c/v3, SSH, HTTPS, local and remote syslog and email alerts. The AP also runs standalone through its own web interface.

Ideal For

Singapore offices, clinics, schools, serviced offices and retail units moving from 802.11ac to Wi-Fi 6 on existing Gigabit PoE+ switching, and IT teams or MSPs who want one Omada controller across every site. Supplied by SourceIT with local Singapore warranty, GST invoice and project pricing on request.
