TP-Link Omada 4G+ Cat6 AX3000 Gigabit VPN Gateway with 4-Port PoE+
Email sales@sourceit.com.sg or use Request for Quotation below and our team will confirm the latest price, availability and lead time.
PRODUCT DESCRIPTION
TP-Link Omada 4G+ Cat6 AX3000 Gigabit VPN Gateway with 4-Port PoE+ (ER706WP-4G) - 5 Years Local Warranty
The ER706WP-4G puts a 4G+ Cat6 modem with dual SIM slots, AX3000 Wi-Fi 6, four PoE+ ports and a full Omada VPN gateway into one desktop, wall or rack-mountable box — a complete small-site network edge that can run on mobile broadband, fixed broadband, or both.
4G+ Cat6 Mobile Broadband With Dual SIM Failover
The built-in 4G+ Cat6 modem is rated at up to 300 Mbps downlink and 50 Mbps uplink, fed by two detachable 4.0 dBi LTE antennas. Two Nano SIM slots run as SIM1 active / SIM2 standby: if the active SIM loses service, the gateway fails over automatically so a branch, pop-up shop or construction site office stays online. Wired WAN is available too through the Gigabit WAN and SFP ports, for 4G as primary or as backup to fixed broadband.
AX3000 Wi-Fi 6 Built In
Dual-band Wi-Fi 6 delivers 2402 Mbps on 5 GHz (HE160) and 574 Mbps on 2.4 GHz through three detachable dual-band antennas, with OFDMA, MU-MIMO and beamforming. It supports seamless roaming and Omada Mesh with EAPs that support Mesh, so the gateway can be the first access point of a larger Omada Wi-Fi deployment rather than a separate island.
Four PoE+ Ports With a 45 W Budget
Four Gigabit RJ45 ports provide 802.3at/af PoE+ output with a 45 W total budget, enough to power Omada access points, IP phones or cameras directly from the gateway without a separate PoE switch at small sites. Alongside them sit a Gigabit SFP WAN/LAN port and a Gigabit WAN port.
Full Omada VPN and Security Feature Set
IPsec (100 tunnels), SSL (50), PPTP and L2TP (50 each), OpenVPN (55), WireGuard (20) and GRE (Standalone Mode) are supported, with published IPsec throughput between 646.5 and 670.5 Mbps and WireGuard at 387.7 Mbps. Signature-based IDS/IPS (229 Mbps TCP) and DPI application control (933 Mbps TCP) sit alongside URL and web group filtering, flood defence and ARP inspection, backed by 150,000 concurrent sessions.
Cloud-Managed With Zero-Touch Provisioning
Managed through Omada Central, an OC200/OC300 Hardware Controller or the Software Controller, the ER706WP-4G appears alongside Omada switches and APs with automatic discovery, monitoring and abnormal-event warnings, and can be run from the Omada App. Zero-Touch Provisioning with the Cloud-Based Controller lets IT pre-stage configuration for remote sites.
Ideal For
Branch offices, retail outlets, temporary and construction sites, and SMEs that want 4G primary or backup internet, Wi-Fi 6 and PoE in a single Omada gateway. Supplied by SourceIT with local Singapore warranty, GST invoice and project pricing on request.
ER706WP-4G Datasheet — Technical Specifications
General
| Model | ER706WP-4G |
| Official Product Name | Omada 4G+ Cat6 AX3000 Gigabit VPN Gateway with 4-Port PoE+ |
| Brand | TP-Link Omada |
| Warranty | 5 Years Local Warranty (Singapore) |
Hardware
| Interface | 1× Gigabit SFP WAN/LAN Port, 1× Gigabit WAN Port, 4× Gigabit LAN/WAN Ports |
| PoE Ports (RJ45) | 4× ports PoE+ output (802.3at/af), 45 W PoE budget |
| Network Media | 10BASE-T, 100BASE-TX, 1000BASE-T (max 100 m) |
| Button | Reset Button |
| Flash | 256 MB NAND |
| DRAM | 512 MB DDR4 |
| LED | System, WLAN, SFP, LTE1, LTE2, PoE Max, LTE Signal, WAN, PoE |
| Antenna | Wi-Fi: three 5 GHz 5.5 dBi & 2.4 GHz 4.5 dBi dual-band detachable antennas; LTE: two 4.0 dBi omnidirectional detachable antennas |
| Dimensions (W × D × H) | 8.9 × 5.2 × 1.4 in (226 × 131 × 35 mm) |
| Mounting | Desktop / Wall-Mounting / Rackmount |
| Max. Power Consumption | 64.9 W with PoE max; 19.8 W without PoE |
4G
| SIM Type | 2× Nano SIM card (4G+ Cat6); SIM1 active / SIM2 standby failover |
| Speed | Downlink: 300 Mbps; Uplink: 50 Mbps |
| Network Type | LTE band plan published by TP-Link (EU version): 4G LTE-FDD B1/B3/B5/B7/B8/B20/B28/B32 plus TDD bands — see the datasheet for the full band list |
Wireless
| Wi-Fi Frequency & Signal Rate | 2.4 GHz: 574 Mbps; 5 GHz: 2402 Mbps (HE160) |
| Advanced Features | Seamless Roaming, Mesh (with EAP that supports Mesh), OFDMA, Beamforming, MU-MIMO, rate limiting, airtime fairness, WPA/WPA2/WPA3 encryption |
| Guest Network | Supported |
Performance
| Concurrent Sessions | 150,000 |
| New Sessions / Second | 5,100 |
| NAT (Static IP) | 947.1 Mbps / 940.1 Mbps |
| NAT (DHCP) | 949.2 Mbps / 941.1 Mbps |
| NAT (PPPoE) | 942.6 Mbps / 941.1 Mbps |
| NAT (L2TP) | 875.4 Mbps / 892.0 Mbps |
| NAT (PPTP) | 881.2 Mbps / 895.8 Mbps |
| 66 Byte Packet Forwarding Rate | 1,453,489 pps / 1,453,488 pps |
| 1,518 Byte Packet Forwarding Rate | 81274 pps / 91275 pps * |
| IPsec VPN Throughput | 646.5 Mbps to 670.5 Mbps depending on cipher suite |
| GRE | Unencrypted: 545.3 Mbps; Encrypted: 282.6 Mbps |
| WireGuard VPN | 387.7 Mbps |
| OpenVPN | 115.5 Mbps |
| L2TP VPN Throughput | Unencrypted: 990.0 Mbps; Encrypted: 475.0 Mbps |
| PPTP VPN Throughput | Unencrypted: 1177.9 Mbps; Encrypted: 177.4 Mbps |
| SSL VPN Throughput | 122.5 Mbps |
| DPI Throughput | TCP: 933 Mbps; UDP: 927 Mbps |
| IPS Throughput | TCP: 229 Mbps; UDP: 188 Mbps |
VPN
| IPsec VPN | 100 IPsec VPN tunnels; LAN-to-LAN, Client-to-LAN |
| SSL VPN | 50 tunnels |
| PPTP VPN | PPTP VPN Server; PPTP VPN Client (10); 50 tunnels; MPPE encryption |
| L2TP VPN | L2TP VPN Server; L2TP VPN Client (10); 50 tunnels; L2TP over IPSec |
| OpenVPN | OpenVPN Server; OpenVPN Client (5); 55 OpenVPN tunnels; Certificate and Account modes |
| WireGuard VPN | 20 tunnels |
| GRE | Supported (Standalone Mode only) |
Security
| DPI | Application control via DPI / updated app library |
| IDS/IPS | Signature-based IPS/IDS threat detection |
| Access Control | Source/Destination IP Based Access Control |
| Filtering | Web Group Filtering, URL Filtering, Web Security |
| ARP Inspection | Sending GARP Packets, ARP Scanning, IP-MAC Binding |
| Attack Defense | TCP/UDP/ICMP Flood Defense, Block TCP Scan (Stealth FIN/Xmas/Null) |
Management
| Centralized Management | Omada Cloud-Based Controller, Omada Hardware Controller (OC300 / OC200), Omada Software Controller |
| Omada App / Cloud Access | Yes |
| Zero-Touch Provisioning | Yes — requires the Omada Cloud-Based Controller |
| Service | Dynamic DNS with multiple providers and customisation |
| Maintenance | Web Management Interface, Remote Management, Export & Import Configuration, SNMP, Diagnostics, NTP, Port Mirroring, Syslog |
| Management Features | Automatic Device Discovery, Intelligent Network Monitoring, Abnormal Event Warnings |
Environment & Certification
| Operating Temperature | 0 °C to 40 °C (32 °F to 104 °F) |
| Storage Temperature | -40 °C to 70 °C (-40 °F to 158 °F) |
| Operating Humidity | 10% to 90% non-condensing |
| Storage Humidity | 5% to 90% non-condensing |
| Certification | CE, FCC, RoHS |
| System Requirements | Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 7/8/8.1/10/11, MAC OS, NetWare, UNIX or Linux |
* Reproduced as published by TP-Link; the two directional figures differ by 10,000 pps, which looks like a typo on the official page (sibling models publish 81,274 / 81,275 pps). Actual 4G speeds vary with the service plan, network capacity and environment.
Compatibility & Software Support
The ER706WP-4G is part of the Omada ecosystem: gateways, switches and access points are managed together from one controller, under one set of policies, with one view of the network. Cloud and app features listed below require the device to be adopted into an Omada Controller.
| Omada SDN Controller | Supported — adopt and manage centrally from Omada Central (Cloud-Based Controller), the Omada Hardware Controller or the Omada Software Controller |
| Omada App | Supported — remote management from iOS and Android |
| Omada Cloud Access | Supported — requires adoption into an Omada Controller |
| Standalone Mode | Supported — the gateway can also be configured on its own via its web interface |
| Zero-Touch Provisioning | Supported — requires the Omada Cloud-Based Controller |
Package Contents & Ordering Information
What’s in the Box
| Package Contents | ER706WP-4G, Power Adapter, Quick Installation Guide |
Ordering Information
| Model | ER706WP-4G |
| Recommended Retail Price (incl. GST) | S$459.00 |
Datasheet & Downloads
Frequently Asked Questions — ER706WP-4G
Does the ER706WP-4G need an Omada Controller?
No. The ER706WP-4G runs standalone through its own web interface. Adopting it into an Omada Software, Hardware or Cloud-Based Controller is what unlocks central configuration, monitoring, firmware management and cloud/app access across every Omada device on site.
What warranty does SourceIT provide?
Five years local Singapore warranty. Every ER706WP-4G sold by SourceIT comes with a GST invoice.
Is stock held locally?
SourceIT holds fast-moving Omada lines in Singapore. Anything not in local stock is brought in on indent — ask us for the current lead time before committing to a project date.
Is this model available for project orders?
Yes. TP-Link supplies this model for project deployments; contact SourceIT with your bill of materials for pricing and lead time.
Can SourceIT quote this for a project or tender?
Yes. Send the bill of materials and we will quote the whole Omada build — controller, gateway, switching, access points and optics — with local warranty and support.
