TP-Link Omada 20-Port Gigabit Easy Managed Switch with 16-Port PoE+ (ES220GMP)
TP-Link Omada 20-Port Gigabit Easy Managed Switch with 16-Port PoE+ (ES220GMP) - 5 Year Warranty
High PoE+ Capacity for Power-Intensive Devices
The TP-Link Omada ES220GMP features 16 Gigabit 802.3af/at-compliant PoE+ RJ45 ports, delivering up to 30W per port.
With a total PoE budget of 250W, it powers devices like IP cameras, access points, and VoIP phones efficiently.
Flexible Connectivity Options
This switch offers 2 Gigabit RJ45 ports and 2 Gigabit SFP slots, providing versatile uplink options for various network setups.
Its fanless design ensures silent operation, suitable for noise-sensitive environments.
Centralized Cloud Management
Integrated with Omada SDN, the ES220GMP supports centralized cloud management via the web or Omada app.
Features like Zero-Touch Provisioning (ZTP) simplify deployment and management, improving operational efficiency.
Advanced Networking Features
Supports VLAN, IGMP Snooping, QoS, and automatic loop prevention for reliable and secure network performance.
PoE Auto Recovery and Port Isolation enhance surveillance networking reliability.
Durable and Scalable Design
Housed in a durable metal casing, the ES220GMP is rack-mountable and designed for scalability.
Its compact 1U form factor fits standard server racks.
Technical Specifications
Feature: Ports – 16× PoE+ RJ45, 2× RJ45, 2× SFP
PoE Budget – 250W (up to 30W per port)
Switching Capacity – 40 Gbps
Packet Forwarding Rate – 29.76 Mpps
MAC Address Table – 8K
Packet Buffer Memory – 4 Mbit
Jumbo Frame – 15 KB
VLAN Support – 4K VID, 32 VLAN Groups
QoS Features – 8 Priority Queues, WRR, Queue Weight Config
Loop Prevention – Yes
IGMP Snooping – Yes
PoE Auto Recovery – Yes
Dimensions (W×D×H) – 440 × 180 × 44 mm
Weight – 2.5 kg
Operating Temperature – -5°C to 50°C
Operating Humidity – 10% to 90% non-condensing
Certifications – FCC, CE, RoHS
Detailed Specifications
Omada 20-Port Gigabit Easy Managed Switch with 16-Port PoE+
PORT: 16× Gigabit PoE+ Ports, 2x Gigabit Non-PoE Ports, 2×SFP Port
SPEC: 802.3at/af, 250W PoE Power
FEATURE: Integration with Omada SDN Controller, Flow Control, Loopback Detection, Port Isolation, Port Mirroring, LAG, VLAN, IGMP Snooping, QoS, Storm Control
