TP-Link InSight S385DPS 8MP Outdoor ColorPro Panoramic Bullet Network Camera, 5mm Lens
PRODUCT DESCRIPTION
TP-Link VIGI 8MP Outdoor ColorPro Panoramic Bullet Network Camera (InSight S385DPS) - 5 Years Local Warranty
The TP-Link InSight S385DPS is an 8MP outdoor panoramic bullet camera that stitches two 5 mm F1.0 lenses into a single 180° horizontal view (5456x1520). Dual 1/1.79" sensors and ColorPro night vision keep colour in low light, and red-blue warning lights, a speaker and alarm I/O add active deterrence. It is rated IP67 and IK10.
Panoramic Coverage, Richer Details
Dual-lens stitched panoramic imaging fuses two lenses to widen the field of view to 180° horizontally, reducing blind spots and the number of install points. 8MP resolution with smart video enhancement improves clarity in backlit and low-light scenes.
Colour at Night
Ultra-low-light ColorPro night vision delivers colour imaging in dark environments, preserving identifiers such as faces, clothing and vehicle colours. Two IR LEDs and two white LEDs each reach 50 m.
Smarter Detection, Precise Alerts
People & Vehicle Analytics and Human & Vehicle Classification reduce false alarms, with intrusion, loitering and line-crossing detection. Red-blue warning lights and sound alerts provide visible and audible deterrence.
Easy Integration, Efficient Bandwidth
Audio in/out and alarm in/out interfaces link to external microphones, speakers and sirens, while H.265+ compression reduces bandwidth and storage.
Ideal For
Car parks, loading bays, building perimeters, forecourts and open yards where one wide 180° view reduces the number of install points. Supplied by SourceIT with local Singapore warranty and GST invoice.
InSight S385DPS Datasheet — Technical Specifications
General
| Model | InSight S385DPS |
| Official Product Name | VIGI 8MP Outdoor ColorPro Panoramic Bullet Network Camera |
| Brand | TP-Link |
| Warranty | 5 Years Local Warranty (Singapore) |
Camera
| Image Sensor | Dual 1/1.79" Progressive Scan CMOS |
| Shutter Speed | 1/3 to 1/10000 s |
| Slow Shutter | Yes |
| Minimum Illumination | 0.0005 Lux; 0 Lux with IR/White Light |
| Day/Night Mechanism | IR Cut Filter |
| Day/Night Switch | Unified/ Scheduled/ Auto |
Lens
| Type | Fixed Focal Lens |
| Focal Length | 5 mm |
| Aperture | Dual F1.0 |
| FOV | Horizontal FOV: 180°, Vertical FOV: 51°, Diagonal FOV: 180° |
| Lens Mount | M16 |
| DORI Distance | 5mm: • D: 249 ft (76 m) • O: 95 ft (29 m) • R: 46 ft (14 m) • I: 23 ft (7 m) |
Angle Adjustment (Manual)
| Range | Pan: 0° to 360°, Tilt: 0° to 90°, Rotation: 0° to 360° |
Illuminator
| IR LED | • Quantity: 2 • Range: 164 ft (50 m) • Wavelength: 850 nm |
| White LED | • Quantity: 2 • Range: 164 ft (50 m) |
| Illuminator On/Off Control | Auto/Scheduled/Always on/Always off |
Video
| Max. Resolution | 5456x1520 |
| Main Stream | • Frame Rate: 50Hz: 1fps 5fps 10fps 15fps 20fps 25fps; 60Hz: 1fps 5fps 10fps 15fps 20fps 24fps • Resolution: 5456x1520, 4096x1152, 2160x608 Note: Enabling people counting or object attribute analysis limits the frame rate to 20fps. |
| Sub-Stream | • Frame Rate: 50Hz: 1fps 5fps 10fps 15fps 20fps 25fps; 60Hz: 1fps 5fps 10fps 15fps 20fps 24fps • Resolution: 2160x608, 1280x360 Note: Enabling people counting or object attribute analysis limits the frame rate to 20fps. |
| Bit Rate Control | CBR, VBR |
| Video Compression | • Main Stream: H.265+/H.265/H.264+/H.264 • Sub-Stream: H.265/H.264 |
| H.264 Type | High Profile |
| H.264+ | Main Stream Supported |
| H.265 Type | Main Profile |
| H.265+ | Main Stream Supported |
| Video Bit Rate | • Main Stream: 256 Kbps to 8 Mbps • Sub-Stream: 64 Kbps to 1024 Kbps |
| Image Settings | • Mirror • Brightness • Contrast • Saturation • Sharpness • Exposure • WDR • White Balance • Prevent Overexposure to Infrared Light • HLC Adjustable by Client Software |
| Image Enhancement | BLC/3D DNR/HLC/SmartIR |
| Wide Dynamic Range | 120 dB |
| SNR | ≥ 52 dB |
| Image Parameters Switch | Yes |
| Privacy Mask | Up to 4 Masks |
| ROI | 4 Regions |
| OSD Setting | Yes |
Audio
| Audio Communication | Two-Way Audio |
| Audio Input | Built-in Dual-Microphone Audio In Interface |
| Audio Output | Built-in Speaker Audio Out Interface |
| Audio Compression | Yes |
| Audio Sampling Rate | 8 KHz |
| Environment Noise Filtering | Yes |
| Audio Bit Rate | 64 Kbps (G.711 alaw) |
Network
| Protocol | TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP, SMTP, SNMP |
| ONVIF | Yes |
| API | Open Network Video Interface (Profile S/T/G) |
| Simultaneous Live View | 3 Main Streams & 3 Sub-Streams |
| Client | VIGI App, Web UI, VIGI VMS, VIGI Cloud VMS, VIGI Config Tool, VIGI PC Client |
| Web Browser | • Google Chrome® 57 and above • Firefox® 52 and above • Safari® 11 and above • Microsoft® Edge 91 and above |
| Cloud | Yes |
| Security | Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication, 802.1X Authentication |
Alarm and Event Management
| Smart Event | • Intrusion Detection • Line-Crossing Detection • Region Entering Detection • Region Exiting Detection • Loitering Detection • People Detection • Vehicle Detection • Abnormal Sound Detection • Scene Change Detection |
| Basic Event | • Motion Detection (Enhanced with Human & Vehicle Classification for more accurate alerts) • Video Tampering Detection • Exception (Illegal Login) • Alarm Input Device |
| Alarm Linkage | • Memory Card Video Recording • Upload to FTP Server • Alarm Output Device • Push Notifications • Send to Alarm Server • Active Defence-Sound Alarm • Active Defence-Light Alarm • Email Alarm |
Deep Learning Function
| People & Vehicle Analytics | Search and filter to people or vehicle of interest based on many different attributes, making post-event search faster and easier.‡ |
Interfaces
| Network Interface | 1 RJ45 10/100M Self-Adaptive Ethernet Port, PoE |
| Alarm | 1 Alarm In, 1 Alarm Out Red-Blue Warning Lights |
| Reset Button | Yes |
| Power | DC Power Port |
| On-board Storage | Built-In Memory Card Slot, Support MicroSD Card, up to 512 GB* |
| Built-in Microphone | Yes; Records Anything Going on within a 16.4-ft (5 m) Radius of the Camera |
| Built-in Speaker | Yes |
| Audio | 1 Audio In, 1 Audio Out |
General
| Operating Temperature | -30 °C to 60 °C (-22 °F to 140 °F) |
| Storage Temperature | -40 °C to 60 °C (-40 °F to 140 °F) |
| Operating Humidity | 95% or Less (Non-Condensing) |
| Storage Humidity | 95% or Less (Non-Condensing) |
| Material | Metal |
| Net Weight | 1.12 kg |
| Power Supply | • 12V DC ± 5%, Max. 18W, 5.5 mm Coaxial Power Plug • PoE: 802.3at, Class 4, Max. 21W |
| Protection | IP67 Weatherproof, IK10 Vandal-Proof |
| Product Dimensions (L x W x H) | 10.5 x 4.6 x 3.5 in (266 x 116 x 90 mm) |
| Certifications | CE, NTRA, VCCI, KC, BSMI, FCC, IP67, IK10, ONVIF |
‡ This feature must be used with VIGI specified software. * The microSD card and pole mounting kits are not included in the package. TP-Link publishes a single 5 mm lens configuration for this model and no gross weight.
Compatibility & Software Support
| Client | VIGI App, Web UI, VIGI VMS, VIGI Cloud VMS, VIGI Config Tool, VIGI PC Client |
| Cloud | Yes |
| ONVIF | Yes |
| API | Open Network Video Interface (Profile S/T/G) |
| Web Browser | • Google Chrome® 57 and above • Firefox® 52 and above • Safari® 11 and above • Microsoft® Edge 91 and above |
| On-board Storage | Built-in memory card slot, microSD up to 512 GB (card not included) |
| Power | PoE (802.3at) or 12V DC |
| Deep-Learning Search | People & Vehicle Analytics must be used with VIGI specified software |
Package Contents & Ordering Information
Package Contents
| Included | • VIGI Network Camera • Quick Start Guide • Waterproof Cable Attachments • Mounting Accessories |
The microSD card and pole mounting kits are not included in the package.
Ordering Information
| Model | InSight S385DPS |
| SKU | InSight S385DPS |
| Warranty | 5 Years Local Warranty (Singapore) |
Datasheet & Downloads
Frequently Asked Questions — InSight S385DPS
How wide is the view?
TP-Link specifies a 180° horizontal, 51° vertical and 180° diagonal field of view from two stitched 5 mm lenses, at a maximum resolution of 5456x1520.
Does it record colour at night?
Yes. ColorPro night vision provides colour imaging in low light, and two white LEDs (50 m range) can illuminate the scene in darkness. Two 850 nm IR LEDs (50 m) are also fitted.
How is it powered?
PoE (802.3at, Class 4, max. 21 W) or 12V DC (max. 18 W). Use a PoE+ (802.3at) switch or injector.
What warranty does SourceIT provide?
SourceIT supplies the InSight S385DPS with a 5 Years Local Warranty (Singapore), handled locally with a GST invoice. See the TP-Link replacement warranty policy link under Datasheet & Downloads for how claims are processed.
Can SourceIT quote this for an office or a project?
Yes. SourceIT quotes the InSight S385DPS for single offices and multi-site projects, including matching VIGI cameras, hard drives and PoE switches. Contact SourceIT with the quantity and site details for a formal quotation.
