TP-Link Omada 24-Port Gigabit Easy Smart Switch

TP-Link 24-Port Gigabit Easy Smart Switch (TL-SG1024DE) - Local Warranty

The TL-SG1024DE is a 24-port Gigabit Easy Smart switch built for small and medium businesses that have outgrown unmanaged switching but do not want the cost or complexity of a fully managed platform. It gives you VLANs, QoS and IGMP snooping through a simple web interface, in a fanless 1U rack chassis that draws under 15 W.

Twenty-Four Gigabit Ports in a Silent 1U Chassis

All 24 RJ45 ports run at 10/100/1000 Mbps with auto-negotiation and auto MDI/MDIX, giving a 48 Gbps switching capacity and a 35.7 Mpps forwarding rate. The unit is fanless, so it can sit in an open comms cabinet, a reception area or a small office rack without adding noise to the room. At 294 x 180 x 44 mm it occupies a single rack unit and ships with the rackmount kit and rubber feet, so it works equally well free-standing on a shelf.

VLAN Segmentation Without a Command Line

Easy Smart switching exists for the network that needs separation but not a CLI. The TL-SG1024DE supports up to 32 simultaneous VLANs drawn from the full 4K VLAN ID range, in MTU, port-based and 802.1Q tag-based modes. That is enough to keep voice, CCTV, guest Wi-Fi and staff data apart on the same physical switch, configured from a browser rather than a terminal session. Loop prevention and cable diagnostics are built in for the moments when a patching mistake would otherwise take the network down.

QoS and IGMP Snooping for Voice and Video Traffic

Traffic prioritisation covers port-based, 802.1p and DSCP priority across four queues, with rate limiting and storm control to stop a single misbehaving device from saturating the switch. IGMP Snooping v1/v2/v3 keeps multicast traffic on the ports that actually requested it, which matters as soon as IP cameras, digital signage or IPTV appear on the same network. Static link aggregation and port mirroring round out the feature set for uplink resilience and troubleshooting.

Low Power Draw and a Documented Thermal Envelope

Maximum power consumption is 14.19 W at 220 V/50 Hz with a maximum heat dissipation of 48.39 BTU/h, so a full 24-port switch adds very little to the cabinet's thermal or electrical load. It runs on 100-240 V AC at 50/60 Hz directly from the supplied power cord, with an operating range of 0-40 C and 10-90% non-condensing humidity — comfortably within what a Singapore comms room or air-conditioned office will present.

Ideal For

Singapore SMEs, retail outlets, clinics and schools that need 24 Gigabit ports with VLAN segmentation and multicast control, and integrators specifying a quiet, rack-mountable access switch where a fully managed model would be over-specified. Supplied by SourceIT with local Singapore warranty, GST invoice and project pricing on request.
