Samsung SM85H 85" 4K Spatial Signage Display
PRODUCT DESCRIPTION
Samsung SM85H 85" Spatial Signage Display (LH85SMHPBGCXXS) - Local Warranty
85 Inches of Glasses-Free Depth for Atriums and Concourses
The Samsung SM85H is the flagship of the spatial signage range, pairing an 85-inch 3840 x 2160 VA panel with an optical 3D plate that delivers perceived depth with no glasses or headsets. At this scale the effect reads from across a mall atrium, an airport concourse or a showroom floor rather than only at close range, and 178-degree viewing angles keep it intact for groups approaching from either side. This is the format to specify when the display itself is meant to be the landmark people walk towards.
True 3D Enhancer Works With the Content You Already Have
Samsung's True 3D Enhancer adds real-time depth to conventional flat material, so the SM85H can run existing brand films, product renders and campaign stills without a specialist 3D production pipeline behind it. Native 3D assets are supported as well, which lets a creative team begin with converted content and introduce purpose-built spatial pieces as the library matures. Scheduling and playback behave exactly like any other Samsung signage panel on the estate, so the operations team learns nothing new.
500-Nit UHD Panel Rated for 24/7 Commercial Duty
A 500-nit VA panel with a 4000:1 contrast ratio keeps 4K spatial content legible under atrium daylight and retail downlighting, and the SM85H is rated for 24 hours a day, 7 days a week of continuous operation. A 21.0 mm bezel keeps the frame tight around the image so attention stays on the content rather than the hardware, and the panel is built for the sustained duty cycle that a permanent public installation demands over a multi-year tenancy.
Tizen 7.0 On Board and Just 52 mm Deep
Tizen 7.0 with 16 GB of internal storage runs content directly on the display, so an 85-inch install needs no media player, PC or extra enclosure behind the screen and no second power and data drop. At 52 mm deep and 49 kg the panel mounts close to the wall despite its size, though the weight makes a properly engineered mount and a two-person lift non-negotiable. Three HDMI inputs plus DisplayPort cover live feeds and external sources, and Samsung VXT gives your team remote scheduling, monitoring and power control across every site.
Samsung SM85H Datasheet — Technical Specifications
General
| Product | Samsung SM85H 85" Spatial Signage Display |
| Part Number (SKU) | LH85SMHPBGCXXS |
| Display Type | Spatial (glasses-free 3D) commercial signage |
| Operating Time | 24/7 continuous commercial operation |
| Platform | Tizen 7.0 |
| Internal Storage | 16 GB |
| Local Warranty (Singapore) | Supplied by SourceIT with GST invoice |
Display
| Screen Size | 85" |
| Resolution | 3,840 x 2,160 (4K UHD) |
| Panel Type | VA |
| Brightness | 500 nit |
| Contrast Ratio | 4,000:1 |
| Viewing Angle | 178° / 178° (H/V) |
| Bezel Width | 21.0 mm |
| 3D Technology | Virtual 3D plate with True 3D Enhancer |
Smart Platform & Management
| Embedded Player | Yes — Tizen 7.0 on board, no external player required |
| Internal Storage | 16 GB |
| Content Management | Samsung VXT cloud signage platform (subscription sold separately) |
Connectivity
| HDMI | 3 x HDMI |
| DisplayPort | 1 x DisplayPort |
| USB | 2 x USB |
Physical & Environmental
| Depth | 52 mm |
| Weight | 49 kg |
| Bezel Width | 21.0 mm |
| Colour | Black |
Power
| Power Consumption (typical) | Approximately 440 W |
Specifications are taken from Samsung's published product data for this model. Where Samsung does not publish a figure for this exact model it has been left out rather than estimated.
Compatibility & Installation
Mounting and placement
At 49 kg the SM85H needs a mount and a substrate rated well above the panel weight, plus a two-person lift on site. Samsung does not publish a VESA pattern or a portrait-orientation rating for the 85-inch spatial model on its Singapore data, so we do not claim either here; tell us the wall build-up and we will confirm the mounting interface with Samsung before the bracket is ordered. At 52 mm deep the panel still finishes close to the wall, so the visual weight stays in the image rather than the housing.
What it connects to
Three HDMI inputs and one DisplayPort input accept a media player, a workstation, a camera feed or a matrix switcher output, and two USB ports handle local media and service. Most spatial installations run entirely from the on-board player, so the inputs exist for a live feed, a room system or a temporary event source rather than as a permanent requirement.
Network and content management
Tizen 7.0 with 16 GB of internal storage plays content locally, and Samsung VXT provides cloud scheduling, playlist management, device health monitoring and remote power control across a multi-site estate from a single console. A VXT subscription is licensed separately from the hardware. Local playback means a short network outage does not blank an 85-inch landmark in front of the public.
Related models
The same glasses-free technology is available as the Samsung SM55H at 55 inches 4K for a window bay or lobby and the Samsung SM32H at 32 inches Full HD for close-range windows and showcases. Where the depth effect is not the point, the Samsung QM85C is the conventional 85-inch 4K signage equivalent.
Package Contents & Samsung Spatial Signage Range
In the box
Samsung does not publish a package contents list for the SM85H on its Singapore product data, so we do not itemise one here. SourceIT will confirm the exact carton contents for the current production revision with your quotation.
Package contents follow Samsung's product data for this model; items not listed by Samsung are not claimed here.
Samsung spatial signage range
| Model | Size | Resolution |
| SM32H | 32" | 1,920 x 1,080 (Full HD) |
| SM55H | 55" | 3,840 x 2,160 (4K UHD) |
| SM85H (this listing) | 85" | 3,840 x 2,160 (4K UHD) |
Datasheet & Downloads
- Samsung Singapore — 85" Spatial Signage SMHX-P product page (LH85SMHPBGCXXS)
- Samsung Singapore — SM85H (SM85HX-P) manuals, firmware and downloads
SourceIT can email the current data sheet revision for the SM85H together with a quotation, including a mounting and lifting note for the 49 kg panel. Tell us the wall and the viewing distance and we will size the install with you.
Frequently Asked Questions — Samsung SM85H
Do viewers need glasses or a headset?
No. A 3D plate bonded to the panel separates the left and right eye images optically, so anyone walking past perceives the depth with nothing to wear and no app to install. That is what makes it workable for an unattended atrium or concourse placement.
Why go to 85 inches rather than 55?
Scale determines the distance at which the effect registers. An 85-inch panel reads as a feature from across an atrium, a concourse or a showroom floor, while a 55-inch panel is sized for a window bay or a lobby wall people pass within a few metres of. Choose by how far away the audience first sees it.
Do I have to produce special 3D content?
Not to start. True 3D Enhancer converts standard flat content to a spatial look in real time, so existing brand films and product renders run as they are. Native 3D assets are supported as well, for when you want to commission purpose-built depth content.
Does it need an external media player?
No. Tizen 7.0 runs on the panel with 16 GB of internal storage, so content plays from the display itself. The three HDMI inputs and DisplayPort are there for a live feed or a room system if you want one.
Can it run 24 hours a day?
Yes. The SM85H is rated for 24/7 continuous commercial operation, which is the baseline for a permanent public landmark display that is never switched off.
What does the installation need to allow for?
The panel weighs 49 kg and is 52 mm deep. That calls for a mount and a substrate rated comfortably above the panel weight and a two-person lift on site. Samsung does not publish a VESA pattern for this model, so confirm the mounting interface with us before the bracket is ordered.
Can it be mounted in portrait?
Samsung does not publish a portrait-orientation rating for the spatial series, so we do not claim one here. If your design calls for portrait, raise it with us early and we will confirm with Samsung.
What warranty and invoicing do I get?
Every SM85H sold by SourceIT comes with local Singapore warranty and a GST invoice on every unit, which is what your finance and procurement teams need for claims and for local service.
