Samsung QP105D-5K 105" 5K Ultra-Wide Commercial Display
PRODUCT DESCRIPTION
Samsung QP105D-5K 105" 5K Ultra-Wide Commercial Display (LH105QPD5BGXXS) - Local Warranty
One 105-Inch 21:9 Canvas Instead of a Multi-Screen Array
The Samsung QP105D-5K delivers a 105-inch 21:9 display at 5120 x 2160, replacing the two- and three-screen arrays that boardrooms, briefing centres and control spaces have traditionally used to get this much width. Because it is a single panel there are no bezel seams crossing the image, no alignment to maintain over the life of the room and no per-screen source management. Content that spans the full width — a programme timeline, a floor plan, a live operations dashboard — simply runs edge to edge without being carved up between displays.
5K Detail That Holds Up at Conference-Table Distance
At 5120 x 2160 the QP105D-5K carries genuine 5K detail across its width, so spreadsheets, CAD drawings, project schedules and multi-source layouts stay legible for the people sitting closest to the screen, not only for those at the back of the room. A 500-nit panel with a 4000:1 contrast ratio keeps that detail readable in a meeting room or a lobby with the blinds open, where a consumer-grade panel would have to be dimmed or shaded to cope with Singapore daylight.
Tizen 8.0 With 16 GB On Board and a 24/7 Rating
Tizen 8.0 and 16 GB of internal storage run content directly on the display, so a room-defining installation needs no external media player or PC hidden behind the panel and no second power and data provision for it. The QP105D-5K is rated for 24 hours a day, 7 days a week of continuous commercial operation, and Samsung VXT gives your team remote scheduling, status monitoring and power control across every room and every site from a single cloud console.
Modern Source Connectivity Including HDMI 2.1 and USB-C
Three HDMI 2.1 inputs and DisplayPort 1.4 carry the bandwidth a 5K signal needs from current players and workstations, while USB-C provides a single-cable connection for a laptop brought into the room by a visitor. Two USB-A ports, RJ45 and RS232 in and out cover local media, wired networking and integrator control systems. Built-in Wi-Fi and Bluetooth allow deployment where a data drop is unavailable, and the panel operates across a 0 to 40 degree Celsius range.
Samsung QP105D-5K Datasheet — Technical Specifications
General
| Product | Samsung QP105D-5K 105" 5K Ultra-Wide Commercial Display |
| Part Number (SKU) | LH105QPD5BGXXS |
| Display Type | Ultra-wide (21:9) commercial signage |
| Operating Time | 24/7 continuous commercial operation |
| Platform | Tizen 8.0 |
| Internal Storage | 16 GB |
| Local Warranty (Singapore) | Supplied by SourceIT with GST invoice |
Display
| Screen Size | 105" |
| Resolution | 5,120 x 2,160 (5K) |
| Aspect Ratio | 21:9 |
| Brightness | 500 nit |
| Contrast Ratio | 4,000:1 |
Smart Platform & Management
| Embedded Player | Yes — Tizen 8.0 on board, no external player required |
| Internal Storage | 16 GB |
| Content Management | Samsung VXT cloud signage platform (subscription sold separately) |
| Remote Control & Monitoring | RS232 In / Out and RJ45 (LAN) |
| Wireless | Built-in Wi-Fi and Bluetooth |
Connectivity
| HDMI | 3 x HDMI 2.1 |
| DisplayPort | 1 x DisplayPort 1.4 |
| USB | 2 x USB-A, 1 x USB-C |
| Network | 1 x RJ45 (LAN) |
| Serial Control | RS232 In / Out |
| Wi-Fi | Built-in |
| Bluetooth | Supported |
Physical & Environmental
| Depth | 48.1 mm |
| Colour | Black |
| Operating Temperature | 0°C to 40°C |
Specifications are taken from Samsung's published product data for this model. Where Samsung does not publish a figure for this exact model it has been left out rather than estimated.
Compatibility & Installation
Mounting and room planning
At 105 inches on a 21:9 ratio the QP105D-5K is considerably wider than a 98-inch 16:9 panel and shorter in height, so the wall it lands on has to be planned around its width rather than its diagonal. Samsung does not publish a VESA pattern, weight or a portrait-orientation rating for this model on its Singapore data, so we do not claim any of them here; send us the room drawing and we will confirm the mounting interface, the weight and the handling requirement with Samsung before brackets are ordered. The panel is 48.1 mm deep, so it finishes close to the wall.
What it connects to
Three HDMI 2.1 inputs and DisplayPort 1.4 carry the bandwidth a 5120 x 2160 signal needs from a current media player, a video conferencing codec, a workstation or a matrix switcher. USB-C gives a visitor a single-cable laptop connection at the table. Two USB-A ports take local media and service devices, and RS232 in and out plus RJ45 give an integrator the control and monitoring paths a boardroom control system expects.
Network and content management
Tizen 8.0 with 16 GB of internal storage runs content on the panel, so a signage or wayfinding role needs no external player. Samsung VXT provides cloud scheduling, playlist management, device health monitoring and remote power control across rooms and sites from one console, with a subscription licensed separately from the hardware. Built-in Wi-Fi and Bluetooth cover deployment where a wired drop is not available at the wall.
Where it fits against other Samsung displays
No other Samsung panel in our catalogue shares the 21:9 5K format. The nearest conventional alternatives by physical scale are the Samsung QB98T and the Samsung QM98T-B, both 98-inch 16:9 4K panels, or the Samsung QP85A-8K where resolution matters more than width.
Package Contents & Samsung QPD Range
In the box
Samsung does not publish a package contents list for the QP105D-5K on its Singapore product data, so we do not itemise one here. SourceIT will confirm the exact carton contents for the current production revision with your quotation.
Package contents follow Samsung's product data for this model; items not listed by Samsung are not claimed here.
Where it fits in the Samsung signage range
The QP105D-5K is the only 21:9 5K ultra-wide panel SourceIT lists, so there is no sibling size to rank it against — it is specified for its shape and its single-panel width, not as one rung on a size ladder. If a conventional 16:9 panel would serve the room, the closest alternatives by scale are the Samsung QB98T and the Samsung QM98T-B at 98 inches 4K. Where pixel density matters more than width, the Samsung QP85A-8K is the higher-resolution option. For a multi-panel approach with visible seams but greater flexibility of shape, see the Samsung video wall range starting with the VM55C-E.
Datasheet & Downloads
SourceIT can email the current data sheet revision for the QP105D-5K together with a quotation, including the confirmed weight and mounting interface for your wall. Send us the room drawing and we will size the install and the source chain with you.
Frequently Asked Questions — Samsung QP105D-5K
Why choose one 21:9 panel over two 16:9 screens?
A single panel has no bezel seam crossing the image, no alignment to maintain and one source path instead of two. Content that is genuinely wide — a timeline, a floor plan, a wide dashboard, a video call alongside a document — runs edge to edge rather than being split across a join.
Is 5K actually useful, or is 4K enough?
At 5120 x 2160 the extra horizontal pixels are what let a 21:9 panel show a genuinely wide layout at readable size. In a boardroom where people sit within a few metres of a 105-inch screen, spreadsheets, drawings and side-by-side sources stay legible rather than becoming soft.
Does it need an external media player?
No. Tizen 8.0 runs on the panel with 16 GB of internal storage, so signage and wayfinding content plays from the display itself. The HDMI 2.1, DisplayPort 1.4 and USB-C inputs are there for room sources and laptops.
Can a visitor connect a laptop with one cable?
Yes. The USB-C input carries video from a laptop over a single cable, which is the usual expectation in a modern boardroom. HDMI 2.1 and DisplayPort 1.4 cover workstations and codecs that need the full 5K bandwidth.
Can I run it 24 hours a day?
Yes. The QP105D-5K is rated for 24/7 continuous commercial operation, so it can serve as a lobby or operations display that is never switched off, as well as a meeting-room screen.
Is it a touchscreen?
No. The QP105D-5K is a non-touch display. For interactive writing and annotation, the Samsung Flip interactive range is the relevant product family.
How big is the wall it needs?
Because the ratio is 21:9, the panel is wider and shorter than a 16:9 screen of the same diagonal, so the wall must be planned to its width. Samsung does not publish the panel dimensions or weight for this model on its Singapore data, so we do not quote figures — send us the room drawing and we will confirm them with Samsung.
What warranty and invoicing do I get?
Every QP105D-5K sold by SourceIT comes with local Singapore warranty and a GST invoice on every unit, which is what your finance and procurement teams need for claims and for local service.
