Samsung QH50C 50" UHD 4K Commercial Display
PRODUCT DESCRIPTION
Samsung QH50C 50" UHD 4K Commercial Display (LH50QHCEBGCXXS) - Local Warranty
700-Nit Brightness for Shopfronts and Daylight-Facing Walls
The Samsung QH50C is built for the positions that defeat ordinary displays: shopfront windows, glazed atriums, transport concourses and any wall that catches direct daylight for part of the day. At 700 nits it holds contrast and colour where a standard 350-nit panel washes out by mid-morning, and a 4000:1 contrast ratio on a VA panel keeps dark content from flattening under ambient light. In Singapore, where glazed frontages and bright lobbies are the norm rather than the exception, that brightness headroom is often what decides whether a screen position works at all.
UHD 4K Detail With Quantum Processor Lite Upscaling
A 3840 x 2160 panel gives the QH50C the pixel density to carry dense content at close viewing distances, which matters for menu boards, departure information and pricing walls that people read from a metre away. Quantum Processor Lite upscales HD sources towards 4K, so legacy content and camera feeds still hold up rather than looking soft. Dynamic Crystal Color widens the colour range so brand assets and video reproduce faithfully, and ENERGY STAR 8.0 certification with EPEAT registration supports corporate procurement and sustainability reporting.
Smart Calibration, Director Mode and DICOM Simulation
Smart Calibration lets an installer colour-calibrate the panel from a mobile app rather than carrying specialist instruments to site, which keeps a multi-screen deployment consistent without adding a day to the commissioning schedule. Director Mode gives fine control over picture settings for content-critical installations such as showrooms and briefing rooms. DICOM Simulation Mode reproduces the greyscale curve used for viewing medical reference imagery, which makes the QH50C usable in clinical education rooms and consultation spaces as well as signage positions.
Even Bezels, Centred 200 x 200 VESA Holes and 24/7 Operation
Even bezels on all four sides mean the QH50C looks identical in landscape or portrait and aligns cleanly when units are mounted together. Centred VESA holes on a 200 x 200 mm pattern simplify bracket alignment and let the panel sit true on standard mounts without shimming, which is a real time saving on a multi-screen fit-out. At 28.5 mm deep and 12.4 kg the display sits close to the wall, and it is rated for 24 hours a day, seven days a week of continuous operation.
Samsung QH50C Datasheet — Technical Specifications
General
| Product | Samsung QH50C 50" UHD 4K Commercial Display |
| Part Number (SKU) | LH50QHCEBGCXXS |
| Display Type | High-brightness commercial signage display |
| Operating Time | 24/7 commercial operation |
| Platform | Tizen 7.0 |
| Certifications | ENERGY STAR 8.0, EPEAT |
| Local Warranty (Singapore) | Supplied by SourceIT with GST invoice |
Display
| Screen Size | 50 inch |
| Resolution | 3840 x 2160 (UHD 4K) |
| Brightness | 700 nits |
| Panel Type | VA |
| Contrast Ratio | 4000:1 |
| Picture Enhancement | Quantum Processor Lite 4K upscaling, Dynamic Crystal Color |
| Picture Modes | Director Mode, DICOM Simulation Mode |
| Calibration | Smart Calibration via mobile app |
Video & Audio
| Audio Output | Stereo mini-jack out |
| Audio Input | Not fitted |
Smart Platform & Management
| Operating System | Tizen 7.0 |
| Internal Storage | 16 GB flash |
| External Player | Not required — content plays on the panel |
| Serial Control | RS232 in and out |
Connectivity
| HDMI | 3 x HDMI 2.0 |
| DisplayPort | 1 x DP 1.2 |
| USB | 2 x USB |
| LAN | 1 x Ethernet (RJ45) |
| Serial | RS232 in and out |
| IR | IR input |
| Wi-Fi | Built-in |
| Bluetooth | Supported |
Physical & Environmental
| Depth | 28.5 mm |
| Bezel | Even bezels on all four sides |
| Weight | 12.4 kg |
| VESA Mount | 200 x 200 mm, centred hole pattern |
| Orientation | Landscape and portrait |
| Colour | Black |
Power
| Power Supply | AC 100-240 V, 50/60 Hz |
| Typical Power Consumption | 165 W |
| Sleep Mode Power | 0.5 W |
Specifications are taken from Samsung's published product data for this model. Where Samsung does not publish a figure for this exact model it has been left out rather than estimated.
Compatibility & Installation
Mounting and orientation
The QH50C mounts on a 200 x 200 mm VESA pattern with centred holes, which balances the panel on the bracket and simplifies alignment across a row of screens. Landscape and portrait are both supported, and the even bezels mean the display reads the same either way. At 28.5 mm deep and 12.4 kg it suits slim wall plates and recessed joinery. Samsung lists the WMN-B50SC wall mount and the STN-L4355C stand as matching accessories for this size.
What it connects to
Three HDMI 2.0 inputs and one DisplayPort 1.2 input cover media players, laptops, room controllers, set-top sources, camera feeds and 4K content. Two USB ports handle content drives and peripherals. Audio leaves over a stereo mini-jack output to a local amplifier or soundbar; there is no audio input on this model, so sound arrives embedded with the video signal.
Network and content management
Tizen 7.0 with 16 GB of internal flash runs scheduled content on the display itself, so no external media player is required at each screen. RJ45 Ethernet and built-in Wi-Fi with Bluetooth cover network delivery and device management. RS232 in and out provides a serial control path from a room controller or building management system, with several displays daisy-chained on one run. Smart Calibration is driven from a mobile app, so colour matching across a deployment does not need instruments on site.
Related models
For the same 700-nit specification at a much larger diagonal, see the Samsung QH98C. Where the position is indoors under controlled lighting and 700 nits is more than needed, the Samsung QM50C covers the same size in the QMC range.
Package Contents & Samsung QHC Range
In the box
- Samsung QH50C 50" UHD 4K commercial display
Package contents follow Samsung's product data for this model; items not listed by Samsung are not claimed here.
Samsung QHC range
| Model | Size |
| QH43C | 43 inch |
| QH50C (this listing) | 50 inch |
| QH55C | 55 inch |
| QH65C | 65 inch |
| QH75C | 75 inch |
| QH98C | 98 inch |
| QH115FX | 115 inch |
Datasheet & Downloads
SourceIT can email the current data sheet revision for the QH50C together with a quotation. Ask for it when you enquire and we will send the latest published version along with pricing and lead time.
Frequently Asked Questions — Samsung QH50C
Is 700 nits enough for a shopfront window?
For most Singapore shopfronts under an awning or a covered walkway, yes — 700 nits is double the output of a typical indoor commercial panel and holds its image through the trading day. A position in unshaded direct sun facing outward is a different problem and calls for a purpose-built high-brightness window display.
Can it run 24 hours a day?
Yes. The QH50C is rated for 24 hours a day, seven days a week of continuous commercial operation.
Does it need an external media player?
No. Tizen 7.0 with 16 GB of internal flash plays scheduled content on the panel. HDMI and DisplayPort inputs remain available for a player or PC where one is already part of the design.
Can it be mounted in portrait?
Yes. Landscape and portrait are both supported, on a 200 x 200 mm VESA pattern with centred holes that keeps the panel balanced on the bracket in either orientation.
What is DICOM Simulation Mode for?
It reproduces the greyscale curve used when viewing medical reference imagery, which makes the display suitable for clinical education rooms, consultation spaces and teaching environments. It is a simulation mode for reference viewing, not a certified diagnostic display.
How does the QH series differ from the QM series?
Brightness and picture tooling. QHC models run at 700 nits against 500 nits or less on comparable QMC models, and add Smart Calibration, Director Mode and DICOM Simulation. Choose QH where daylight or bright ambient lighting is the constraint.
Can it be controlled from a room controller or BMS?
Yes. RS232 in and out allows serial control and daisy-chaining, and RJ45 Ethernet gives a network control path. Both are standard on this model.
What warranty applies and will I get a GST invoice?
Every unit sold by SourceIT carries local Singapore warranty and is supplied with a GST invoice. Warranty is handled locally rather than through a parallel-import channel.
