MAXHUB XBoard V555T 55" Microsoft Teams Rooms Interactive Display
PRODUCT DESCRIPTION
MAXHUB XBoard for Microsoft Teams Rooms V555T 55" 4K All-in-One Certified Interactive Display with Windows 11 IoT PC Module (V555T) - 3 Years Local Warranty
55" All-in-One Microsoft Teams Rooms Display
The MAXHUB V555T is the 55" member of MAXHUB's XBoard for Microsoft Teams Rooms range — an interactive display that runs the full Microsoft Teams Rooms on Windows experience from a slot-in PC module (12th Gen Intel Core i5-1240P, 16GB DDR4, 256GB M.2 SSD, Windows 11 IoT). A 50MP trident camera, 16-microphone array and 2.1 speaker system are built in, so a meeting room needs only the display, a network connection and a touch console.
Trident 50MP Camera with Speaker Tracking
One 50MP wide lens and two 50MP telephoto lenses give 5x hybrid zoom, with auto framing, speaker tracking, multiple-speaker tracking and intelligent focus to keep remote attendees focused on whoever is talking.
16-Mic Array with Up to 15 m Pick-up
The 16-microphone array covers 180° with a best pick-up distance of 8 m and a maximum of 15 m, backed by an intelligent audio fence, AI spatial sound, AEC, ANC and AGC. Two 10 W speakers and a 20 W subwoofer (2.1 channels) fill small to large meeting rooms.
50-Point Infrared Touch and Wireless Presentation
The 25% haze non-glare surface uses MAXHUB's infrared touch technology with 50 touch points, ±0.5 mm accuracy and ≤2.5 ms response. Wi-Fi 6, Bluetooth 5.1 and a built-in wireless access point for wireless presentation are included, and a dedicated RJ45 port connects a Teams Rooms touch console.
Need help choosing? Email sales@sourceit.com.sg with your room size, platform and quantity and we will recommend the right configuration.
MAXHUB V555T Datasheet — Technical Specifications
General
| Product Name | MAXHUB XBoard for Microsoft Teams Rooms V555T |
| Part Number | V555T |
| Series | MAXHUB XBoard V7 Series for Microsoft Teams Rooms |
| Platform | Microsoft Teams Rooms on Windows (Windows 11 IoT) |
| Local Warranty (Singapore) | 3 years, supplied by SourceIT with a GST invoice |
Display
| Screen Size | 55" |
| Resolution | 3840 x 2160 (4K UHD) |
| Refresh Rate | 60 Hz |
| Colour Gamut | 90% NTSC |
| Viewing Angle | 178° (H) / 178° (V) |
| Colour Depth | 1.07 billion (10-bit) |
| Colour Accuracy | ΔE ≤ 1.5 |
| Response Time | 8 ms |
| Operation | 16 hours / 7 days |
| Surface | 25% haze non-glare |
| Lifespan | > 50,000 hours |
Touch
| Technology | Intelligent Touchscreen Technology (infrared recognition) |
| Touch Points | 50 |
| Response Time | ≤ 2.5 ms |
| Accuracy | ±0.5 mm |
| Object Recognition | ≥ 1.5 mm |
| Writing Height | ≤ 1 mm |
Camera
| Camera System | Trident: 1 x 50MP wide + 2 x 50MP telephoto |
| Wide Lens FOV | 86° HFOV |
| Zoom | 5x hybrid |
| AI Features | Auto framing, speaker tracking, multiple-speaker tracking, intelligent focus |
Audio
| Microphones | 16-mic array |
| Pick-up Angle | 180° |
| Pick-up Range | 8 m best / 15 m maximum |
| Speakers | 2.1 channel: 2 x 10 W + 20 W subwoofer |
| Audio Processing | Intelligent audio fence, AI spatial sound, AEC, ANC, AGC |
PC Module (slot-in, included)
| Processor | 12th Gen Intel Core i5-1240P |
| Graphics | Intel Iris Xe Graphics eligible |
| Memory | 16GB DDR4 (2 x 8GB) |
| Storage | 256GB M.2 SSD |
| Operating System | Windows 11 IoT |
| Security | TPM 2.0 |
Ports & Connectivity
| Display I/O | HDMI In (2.0) x 2, USB-A 2.0 x 1, Touch USB-B 2.0 x 1, Audio In x 1, Audio Out x 1, RS232 x 1, Mic In (RJ45) x 1 |
| PC Module I/O | USB-A 3.0 x 3, HDMI In (2.0) x 1, HDMI Out x 2, RJ45 (Ethernet) x 1, RJ45 (Touch Console) x 1 |
| Wireless | Wi-Fi 6, Bluetooth 5.1, wireless access point for wireless presentation |
Sensors
| Built-in Sensors | Ambient light sensor, motion sensor |
Compatibility & Software Support
Conferencing Platform
Runs Microsoft Teams Rooms on Windows on the included Windows 11 IoT PC module. A Microsoft Teams Rooms licence is required and is not included.
Screen Sharing & BYOD
HDMI input for wired content sharing, plus a built-in wireless access point for wireless presentation. Optional MAXHUB WT13M wireless share dongle.
Expansion
Optional MAXHUB UC BM45 expansion speakerphone for larger rooms, TCP30T Teams Rooms touch console, and ST33M / ST23G mobile stands.
Package Contents & XBoard for Microsoft Teams Rooms Ordering Information
In the Box
The slot-in Windows 11 IoT PC module is included. Please email us for the full in-box list for the V555T before ordering. Mobile stands are sold separately — see the ST33M mobile trolley and ST23G mobile stand; add the UC BM45 speakerphone or WT13M wireless dongle as needed.
XBoard for Microsoft Teams Rooms Models
| Model | Size | Resolution |
| V555T (this listing) | 55" | 3840 x 2160 |
| V655T | 65" | 3840 x 2160 |
| V755T | 75" | 3840 x 2160 |
| V865T | 86" | 3840 x 2160 |
| V925T | 92" | 5120 x 2160 |
Datasheet & Downloads
| Series brochure | XBoard for Microsoft Teams Rooms Brochure (PDF) |
| MAXHUB product page | XBoard for Microsoft Teams Rooms on maxhub.com |
Need a PDF sent directly? Email sales@sourceit.com.sg quoting V555T.
Frequently Asked Questions — MAXHUB V555T
Is a PC included?
Yes. The slot-in PC module (12th Gen Intel Core i5-1240P, 16GB DDR4, 256GB M.2 SSD, Windows 11 IoT) is included and runs Microsoft Teams Rooms.
Is a Microsoft Teams Rooms licence included?
No. A Microsoft Teams Rooms licence is purchased separately from Microsoft or your licensing partner.
Does it have a built-in camera and microphones?
Yes — a 50MP trident camera with 5x hybrid zoom and speaker tracking, and a 16-microphone array with 8 m best / 15 m maximum pick-up, so no separate video bar is needed.
Do I need a touch console?
Teams Rooms on Windows is normally operated from a touch console. The display has a dedicated RJ45 touch-console port; MAXHUB lists the TCP30T as its optional console — ask us for pricing.
How is this different from the XBoard V7 Vxx50 models?
The Vxx50 models are Windows all-in-ones with an optional MT71E/MT71F PC module. The V555T ships with a Windows 11 IoT module dedicated to Microsoft Teams Rooms.
What warranty do I get?
3 years local warranty in Singapore, supplied by SourceIT with a GST invoice.
