MAXHUB UC BM45 PoE Conference Speakerphone
Email sales@sourceit.com.sg or use Request for Quotation below and our team will confirm the latest price, availability and lead time.
PRODUCT DESCRIPTION
MAXHUB UC BM45 Microsoft Teams Rooms Certified Meeting Room Speakerphone with 8-Mic Array, PoE and Daisy-Chain (UC BM45) - 3 Years Local Warranty
Meeting Room Speakerphone Built for Clear Conversations
The MAXHUB UC BM45 is a table-top meeting room speakerphone with an 8-microphone array and a 5 W speaker. MAXHUB rates its voice pick-up at best 4 m and up to 8 m, making it a clean way to add reliable audio to a huddle space or boardroom table.
AI Noise Reduction and Full-Duplex Audio
AI noise reduction, full-duplex communication, automatic echo cancellation (AEC) and automatic gain control (AGC) keep voices natural on both ends of the call, even when people talk over each other.
Scale the Room by Daisy-Chaining
For larger tables, multiple UC BM45 speakerphones can be daisy-chained — up to 6 units — using the PoE in / PoE out RJ45 ports, so the whole room is covered from one connection.
Certified for Microsoft Teams Rooms
The UC BM45 is Microsoft Teams Rooms certified and is managed with MAXHUB Align and MAXHUB Pivot. It connects over USB-C for plug-and-play use and is one of the components of MAXHUB's XCore Kit Pro room kit.
Need help choosing? Email sales@sourceit.com.sg with your room size, platform and quantity and we will recommend the right configuration.
MAXHUB UC BM45 Datasheet — Technical Specifications
General
| Product Name | MAXHUB UC BM45 Speakerphone |
| Part Number | UC BM45 |
| Series | MAXHUB UC Series |
| Local Warranty (Singapore) | 3 years, supplied by SourceIT with a GST invoice |
Audio
| Microphones | 8 |
| Voice Pick-up Range | Best 4 m (13.1 ft), maximum 8 m (26.2 ft) |
| Microphone Frequency Range | 100 Hz – 10 kHz |
| Speaker Output (max) | 5 W |
| Sound Pressure Level | 82 dB @ 1 m |
| Speaker Bandwidth | 100 Hz – 20 kHz |
| Audio Processing | AI noise reduction, full-duplex, AGC, AEC |
Ports
| USB | 1 x USB-C |
| Network / Power | 1 x RJ45 (PoE in), 1 x RJ45 (PoE out) |
| DC In | 54 V / 0.925 A |
| Daisy Chain | Up to 6 x UC BM45 |
Physical
| Dimensions | 122 mm (diameter) x 65 mm |
| Weight | 472 g |
| Package Dimensions | 226 x 187 x 91 mm |
| Package Weight | 1.2 kg |
Certifications & Software
| Certification | Microsoft Teams Rooms Certified |
| Compatible Software | MAXHUB Align, MAXHUB Pivot |
Compatibility & Software Support
Conferencing Platforms
Microsoft Teams Rooms certified. As a USB-C audio device it can also be used with other conferencing applications on the connected room PC.
Management
Configure and manage with MAXHUB Align and MAXHUB Pivot.
Room Kits
The UC BM45 is part of MAXHUB's XCore Kit Pro for Microsoft Teams Rooms, alongside the UC P30 camera.
Package Contents & UC Series Ordering Information
In the Box
UC BM45 unit x 1, table bracket x 1, power adapter x 1, USB-C to USB-A cable x 1 (3 m) and Ethernet cable x 1 (3 m), per MAXHUB's UC BM45 datasheet.
MAXHUB UC Series Models
| Model | Type |
| UC BM45 (this listing) | PoE conference speakerphone (8 mics, daisy-chain up to 6) |
| UC BM35 | Bluetooth / USB-C speakerphone (8 mics, battery) |
| UC P30 | 4K dual-camera PTZ, 12x optical zoom |
| UC P15 | Full HD PTZ, 12x optical zoom |
| UC S15 | 4K video bar with wireless BYOD |
| UC S07 | 4K USB video bar |
| UC W31 | 4K USB webcam |
Datasheet & Downloads
| MAXHUB UC BM45 datasheet | UC BM45 Datasheet V1.3 (PDF) |
| MAXHUB product page | UC BM45 on maxhub.com |
Need a PDF sent directly? Email sales@sourceit.com.sg quoting UC BM45.
Frequently Asked Questions — MAXHUB UC BM45
How many people can it cover?
MAXHUB rates the UC BM45's pick-up at best 4 m and up to 8 m. For bigger tables, daisy-chain up to 6 units.
Is it Microsoft Teams Rooms certified?
Yes — MAXHUB lists the UC BM45 as Microsoft Teams Rooms certified.
How is it powered?
Via the included power adapter (54 V DC) or PoE on the RJ45 PoE-in port; the PoE-out port feeds the next unit in a daisy chain.
Does it have Bluetooth?
No. MAXHUB's datasheet lists USB-C and RJ45 (PoE in/out) connections only. For a Bluetooth speakerphone see the UC BM35.
What warranty do I get?
3 years local warranty in Singapore, supplied by SourceIT with a GST invoice.
