Lenovo ThinkPad E14 Gen 7 Intel U5-226V /16GB RAM /512GB SSD
PRODUCT DESCRIPTION
Lenovo ThinkPad E14 Gen 7, Intel U5-226V / 16GB RAM / 512GB SSD (21U2001JSG) - 3 Years Local Warranty
Clearance Promotion Model Strictly While Stock Last Only
A Copilot+ Class NPU in a Mainstream Business ThinkPad
This build uses Intel's Core Ultra 5 226V on the Lunar Lake platform, and the headline number is the neural processor: Intel AI Boost delivering up to 40 TOPS, against 12 TOPS on the Arrow Lake build of the same model. If your organisation is deploying on-device AI features, local inference or Copilot+ workloads, that difference is the reason to choose this part number.
Intel Arc Graphics 130V — a Real Step Up
Lunar Lake pairs that NPU with Intel Arc Graphics 130V, rated up to 53 TOPS, where the Arrow Lake build uses baseline Intel Graphics at 8 TOPS. For anyone driving multiple high-resolution displays, working with video, or running graphics-accelerated business applications, this is the stronger machine.
Two Thunderbolt 4 Ports, Not One
Lunar Lake builds carry two USB-C Thunderbolt 4 / USB4 40 Gbps ports, both with DisplayPort 2.1 and 15–65 W power delivery — where the Arrow Lake build has one Thunderbolt port and one 20 Gbps USB-C. On a desk with a dock on one side and a high-resolution display on the other, that second Thunderbolt port earns its place.
The Trade-off, Stated Plainly: the Memory Is Soldered
This is the fact to weigh before ordering. Lunar Lake puts memory on the processor package, so the 16GB is LPDDR5X-8533 soldered to the board, with no slots and no upgrade path — ever. It is faster memory than the socketed alternative, and the machine has fewer cores (8, against 12). If your policy is to extend laptop life by adding memory at year three, choose the Arrow Lake build (21SX000GSG) instead.
Lenovo ThinkPad E14 Gen 7 Datasheet — Technical Specifications
General
| Product | Lenovo ThinkPad E14 Gen 7 |
| Part Number | 21U2001JSG |
| Machine Type | 21U2 |
| Operating System | Windows 11 Pro 64-bit |
| Warranty | 3-Year Onsite, per the distributor configuration for this part number |
| Local Warranty (Singapore) | Included with every SourceIT purchase, with GST invoice |
Processor & Graphics
| Processor | Intel Core Ultra 5 226V (Lunar Lake) |
| Cores / Threads | 8 cores (4 P-core + 4 LP E-core) / 8 threads |
| Base Frequency | P-core 2.1 GHz / LP E-core 2.1 GHz |
| Max Turbo | P-core 4.7 GHz / LP E-core 3.5 GHz |
| Cache | 8MB Intel Smart Cache |
| Graphics | Intel Arc Graphics 130V, up to 53 TOPS |
| NPU | Intel AI Boost, up to 40 TOPS (platform up to 97 TOPS) |
Memory & Storage
| Memory Supplied | 16GB LPDDR5X-8533, memory on package |
| Memory Architecture | Soldered to the system board. No slots. Not upgradeable, dual-channel |
| Maximum Memory | 16GB as built — the platform is offered at 16GB or 32GB, fixed at manufacture |
| Storage Supplied | 512GB PCIe 4.0 x4 NVMe SSD with Opal 2.0 |
| Storage Architecture | Single M.2 slot on this platform — no second slot |
Display
| Screen Size | 14" |
| Resolution | WUXGA 1920 x 1200 |
| Aspect Ratio | 16:10 |
| Panel Type | IPS, anti-glare |
| Brightness | 300 nits |
| Colour Gamut | 45% NTSC |
| Refresh Rate | 60 Hz |
Ports & Connectivity
| Thunderbolt / USB-C | 2x USB-C Thunderbolt 4 / USB4 40 Gbps, USB PD 15–65 W, DisplayPort 2.1 |
| USB-A | 1x USB-A 5 Gbps (USB 3.2 Gen 1); 1x USB-A 10 Gbps (USB 3.2 Gen 2), Always On |
| Video Out | 1x HDMI 2.1, up to 4K at 60 Hz |
| Ethernet | 1x RJ-45 gigabit |
| Audio | 1x 3.5 mm headphone / microphone combo jack |
| Wireless | Wi-Fi 6E AX211 2x2, Bluetooth 5.3 |
| WWAN | Not supported on this model |
Battery & Power
| Battery | 64Wh Li-ion |
| Charging | Rapid Charge — up to 80% in one hour |
| AC Adapter | 65 W USB-C |
Security & Manageability
| TPM | Discrete TPM 2.0, TCG certified, FIPS 140-3 certified |
| Fingerprint Reader | Touch-style reader integrated in the power button, match-on-chip |
| Camera | FHD 1080p with IR, hybrid, with privacy shutter — supports Windows Hello facial recognition |
| Physical Lock | Kensington Nano Security Slot |
| Keyboard | Backlit, 6-row, spill-resistant, Copilot key, TrackPoint and precision touchpad |
Physical & Durability
| Dimensions | 313 x 220.3 x 19.7 mm maximum (10.1 mm front / 15.25 mm rear) |
| Weight | Approximately 1.34 kg |
| Chassis | Aluminium top with PC-ABS or aluminium bottom, depending on build |
| Durability | MIL-STD-810H military test passed |
| Audio | Stereo speakers 2 W x 2, Dolby Atmos, audio by HARMAN; dual-microphone array |
| Certifications | ENERGY STAR 9.0; EPEAT 1.0 Gold; TCO Certified generation 10; RoHS |
Configuration-Dependent Items
| SSD Form Factor | The distributor configuration lists an M.2 2242 drive while Lenovo's platform book describes an M.2 2280 slot for Lunar Lake builds. Ask us to confirm before planning a drive replacement |
| Chassis Finish | Black or Grey, depending on build |
Compatibility & Fit
Choose this build for AI capability and graphics; choose the other for upgradeability. Both machines are sold as "ThinkPad E14 Gen 7", and the difference does not appear in the model name. This one has a 40 TOPS NPU, Intel Arc 130V graphics, faster LPDDR5X-8533 memory and two Thunderbolt 4 ports. The 21SX000GSG has 12 cores instead of 8, two SODIMM slots to 64GB, and two M.2 slots.
The soldered memory deserves a decision, not a footnote. 16GB is comfortable for office work today. If your refresh cycle is five years and your policy is to top up memory mid-life, this machine cannot be topped up — the memory sits on the processor package. Organisations that buy on total cost of ownership rather than purchase price often prefer the socketed build for exactly this reason. Those deploying AI workloads usually prefer this one.
Windows Hello: this configuration includes an FHD 1080p camera with IR, so facial recognition sign-in works out of the box, alongside the power-button fingerprint reader. That is a better security posture than the HD 720p camera fitted to some other builds in this family.
Docking: two Thunderbolt 4 ports with DisplayPort 2.1 and up to 65 W power delivery, plus onboard gigabit ethernet and HDMI 2.1. It pairs well with a USB-C docking monitor such as the ThinkVision P24h-30.
Package Contents & ThinkPad Ordering Information
In the box: ThinkPad E14 Gen 7 laptop, 65 W USB-C AC adapter, and documentation. Windows 11 Pro is pre-installed.
ThinkPad Ordering Information
| 21SX000GSG | ThinkPad E14 Gen 7 — Intel Core Ultra 5 225U, 16GB, 512GB |
| 21U2001JSG (this listing) | ThinkPad E14 Gen 7 — Intel Core Ultra 5 226V, 16GB, 512GB |
| 21SR000DSG | ThinkPad E16 Gen 3 — Intel Core Ultra 7 255U, 16GB, 512GB |
| 21R5002BSG | ThinkPad L13 Gen 6 — Intel Core Ultra 5 225U, 16GB, 512GB |
Datasheet & Downloads
- Lenovo PSREF specification book — ThinkPad E14 Gen 7 (Intel) (PDF)
- Lenovo PSREF product page — ThinkPad E14 Gen 7 (Intel)
- Lenovo per-part-number configuration (21U2001JSG) on PSREF
The PSREF specification book documents the ThinkPad E14 Gen 7 (Intel) platform — chassis, ports, memory architecture and certifications, which are fixed for the machine type. The per-part-number link opens Lenovo's configuration record for this exact SKU and renders in a normal browser; it is the definitive reference for the options fitted to this particular build.
Frequently Asked Questions — Lenovo ThinkPad E14 Gen 7
Can the memory be upgraded?
No. This is a Lunar Lake build with LPDDR5X memory on the processor package — soldered, no slots, permanently 16GB. If upgradeable memory matters, order the 21SX000GSG, which has two SODIMM slots to 64GB.
What does the 40 TOPS NPU actually do?
It runs AI inference on the device rather than in the cloud — local Copilot+ features, background effects in video calls, transcription and similar workloads — without loading the processor or sending data off the machine. The Arrow Lake build of this model reaches 12 TOPS.
Is the graphics genuinely better?
Yes. Intel Arc Graphics 130V here against baseline Intel Graphics on the Arrow Lake build. It matters most for multiple high-resolution displays and graphics-accelerated applications.
Why does it have fewer cores than the cheaper build?
Different silicon design. Lunar Lake uses 8 cores and 8 threads optimised for efficiency and AI; Arrow Lake uses 12 cores and 14 threads. For heavily multi-threaded work the 12-core build may perform better despite being the lower-tier processor.
Does it support Windows Hello face sign-in?
Yes — this configuration has an FHD 1080p camera with IR and a privacy shutter, plus a fingerprint reader in the power button.
Does it have wired ethernet?
Yes, gigabit RJ-45 on board.
What warranty does it come with?
3-year onsite service per the distributor configuration for this part number, plus local Singapore warranty and a GST invoice from us. Lenovo's PSREF book lists 1-year options as the model's base warranty, so keep your invoice with the asset record as evidence of the cover supplied.
