HP Thunderbolt 4 100W G6 Dock
PRODUCT DESCRIPTION
HP Thunderbolt 4 100W G6 Dock (9X472UT) - 3 Years Local Warranty
Thunderbolt 4 Docking over One Cable
The HP Thunderbolt 4 100W G6 Dock links a notebook to displays, wired network and peripherals through the included 1 m Thunderbolt 4 cable while delivering up to 100 W of charging power.
Ports for a Full Desk Setup
One HDMI 2.1 and two DisplayPort 1.4 outputs handle monitors, with a downstream Thunderbolt 4 port, two 10Gbps USB Type-C ports, three 10Gbps USB Type-A ports and RJ-45 Ethernet for everything else.
Small Footprint, Broad Compatibility
The 12.1 cm-square dock weighs 740 g and supports Windows 11, Windows 10, macOS, Linux, ThinPro and ChromeOS.
Equipping hot desks or a laptop fleet? Email sales@sourceit.com.sg for volume pricing and delivery lead time.
HP Thunderbolt 4 100W G6 Dock Datasheet — Technical Specifications
General
| Product Name | HP Thunderbolt 4 100W G6 Dock |
| Part Number | 9X472UT |
| Local Warranty (Singapore) | HP 3-year limited warranty, supplied by SourceIT with a GST invoice |
Ports
| Thunderbolt | 1 x Thunderbolt 4 |
| Video | 1 x HDMI 2.1; 2 x DisplayPort 1.4 |
| USB-C | 2 x USB Type-C 10Gbps |
| USB-A | 3 x USB Type-A 10Gbps |
| Network | 1 x RJ-45 |
Power
| Power to Host | Up to 100 W via Thunderbolt 4 |
| Power Adapter | 120 W external power adapter |
| Power Delivery Profiles | 5V/3A; 9V/3A; 12V/5A; 15V/5A; 20V/5A |
Physical
| Dimensions (W x D x H) | 12.1 x 12.1 x 4.95 cm (without stand) |
| Weight | 740 g |
Compatibility & Software Support
Operating Systems
Windows 11, Windows 10, macOS, Linux, ThinPro and ChromeOS.
Host Requirements
A notebook with a Thunderbolt 4 port, or a USB Type-C port supporting USB Power Delivery and DisplayPort Alt Mode.
Package Contents & Ordering Information
In the Box
Dock, 120 W power adapter, 1 m Thunderbolt 4 cable, power cord, product notice and warranty card.
HP G6 Docks at SourceIT
| Model | Key feature |
| HP USB-C 100W G6 Dock 9X3V1UT | USB-C, up to 100 W to host, 1GbE |
| HP Thunderbolt 4 100W G6 Dock 9X472UT (this listing) | Thunderbolt 4, up to 100 W to host |
| HP Thunderbolt 4 Ultra 180W G6 Dock 9X481UT | Thunderbolt 4, up to 180 W, 2.5GbE |
| HP Thunderbolt 4 Ultra 280W G6 Dock AW5M5UT | Thunderbolt 4, up to 280 W, 2.5GbE |
Datasheet & Downloads
| HP product page | HP Thunderbolt 4 100W G6 Dock (9X472UT) on hp.com Singapore |
| HP datasheet | HP Thunderbolt 4 100W G6 Dock Datasheet (PDF) |
| Support & drivers | HP Thunderbolt 4 100W G6 Dock software and drivers |
Need a PDF sent directly? Email sales@sourceit.com.sg quoting 9X472UT.
Frequently Asked Questions — HP Thunderbolt 4 100W G6 Dock
How much power does it deliver to my laptop?
Up to 100 W over Thunderbolt 4, from the included 120 W power adapter.
Is the Thunderbolt cable included?
Yes, a 1 m Thunderbolt 4 cable is in the box.
Which video outputs does it have?
One HDMI 2.1 port and two DisplayPort 1.4 ports.
Does it work with macOS and ChromeOS?
Yes. Windows 10, Windows 11, macOS, Linux, ThinPro and ChromeOS are supported.
What warranty do I get?
HP 3-year limited warranty, supplied locally by SourceIT with a GST invoice.
