HP Thunderbolt 4 Ultra 180W G6 Dock

HP Thunderbolt 4 Ultra 180W G6 Dock (9X481UT) - 1 Years Local Warranty

Enterprise Thunderbolt 4 Docking Solution for Modern Workspaces

HP Thunderbolt 4 Ultra 180W G6 Dock (9X481UT) is a high-performance docking station designed for business professionals and enterprise environments requiring fast connectivity, device expansion, and streamlined workspace management. Utilizing Thunderbolt 4 technology, the dock enables users to connect multiple peripherals and accessories through a single cable connection.

180W Power Delivery for Business and Workstation Devices

With up to 180W power capability, the HP Thunderbolt 4 Ultra G6 Dock supports charging and connectivity for compatible HP business laptops and workstations. It helps reduce cable clutter while maintaining power delivery, allowing users to work efficiently in office, hybrid, and enterprise environments.

Advanced Connectivity and Productivity Expansion

The Thunderbolt 4 interface provides high-speed data transfer and supports multiple peripherals including displays, storage devices, keyboards, mice, and network connections. The dock helps users create an organized workstation while improving productivity through expanded connectivity options.

Designed for Enterprise and Hybrid Work Deployment

Built for modern workplaces, the HP Thunderbolt 4 Ultra 180W G6 Dock supports flexible deployment across office desks, hot-desking environments, remote workstations, and enterprise setups. Its compact and professional design integrates easily into business workspaces.

Technical Specifications

General
Model: 9X481UT
Product Name: HP Thunderbolt 4 Ultra 180W G6 Dock
Product Type: Thunderbolt Docking Station / Enterprise Dock
Form Factor: Desktop Docking Station
Color: Black / Dark Gray
Deployment: Enterprise, Hybrid Workplace, Mobile Workstations, Hot Desk Environments
Usage Mode: Single-cable docking solution for power, display, network and peripheral expansion

Power Specifications
Host Charging Power: Up to 180W Power Delivery
Power Adapter Rating: 230W External Power Adapter
Power Delivery Technology: Thunderbolt 4 + USB Power Delivery
Power Input Type: External AC Adapter
Auxiliary USB-C Charging: Up to 15W via USB-C ports

Host Connectivity
Host Interface: Thunderbolt 4
Data Transfer Speed: Up to 40Gbps
Cable Length: 1m Integrated Thunderbolt 4 Cable
Connection Type: Wired Docking Station

Supported Interfaces:
• Thunderbolt 4
• USB4 Compatible
• USB-C DisplayPort Alt Mode
• USB Power Delivery

USB & Expansion Ports

Front Ports:
• 1 × USB-C 3.2 Gen 2 (10Gbps, data + 15W PD)

Side Ports:
• 3 × USB-A 3.2 Gen 2 (10Gbps, charging support)
• 1 × USB-C 3.2 Gen 2 (10Gbps, data + 15W PD)

Rear Ports:
• 2 × USB-A 3.2 Gen 1 (5Gbps, charging support)
• 1 × USB-C DisplayPort Alt Mode
• 1 × Thunderbolt 4

Total USB Ports: 8

Display & Video Output
Video Outputs:
• 2 × DisplayPort 1.4
• 1 × HDMI 2.1
• 1 × USB-C Display Output
• 1 × Thunderbolt 4 Display Support

Maximum Resolution: Up to 5K @ 60Hz
Display Support: Up to 4 External Displays

Display Performance:
Single Display: Up to 5K (5120 × 2880) @ 60Hz
Multiple Displays: Up to 4 × 4K (3840 × 2160) @ 60Hz
High Refresh Support: Up to 360Hz (supported configurations)

Networking
Ethernet Port: 1 × RJ-45
Ethernet Speed: 2.5 Gigabit Ethernet (2.5GbE)
Wake-on-LAN: Supported
MAC Address Pass-Through: Supported on compatible HP systems
PXE Boot: Supported

Management & Security Features
HP Quick Connect: Supported
HP Wolf Security: Supported
HP Sure Start: Supported
Poly Lens Remote Management: Supported
Firmware Self-Validation: Supported
Remote Device Monitoring: Supported
Kensington Nano Lock Slot: Supported

Compatibility
Supported Operating Systems:
• Windows 10
• Windows 11
• macOS
• Linux
• ChromeOS
• HP ThinPro

Compatible Devices:
• HP EliteBook Series
• HP ZBook Series
• HP ProBook Series
• Thunderbolt 4 Laptops
• USB4 Devices
• USB-C Systems

Performance Features
Thunderbolt 4 40Gbps connectivity
Up to 180W laptop charging
Supports up to 4 external displays
Enterprise remote manageability
High bandwidth workstation support
Hybrid workplace optimization

Design & Construction
Design: Compact Cube Design
LED Indicators: RGB LED Bar
Power Button: RGB Status Indicator
Security Slot: Kensington Nano Lock Slot
Construction: Enterprise Grade Housing

Physical Specifications
Dimensions (W × D × H): 12.1 × 12.1 × 4.95 cm
Weight: 790 g
Color: Black / Dark Gray

Environmental Specifications
Operating Temperature: 0°C – 35°C
Operating Humidity: 10% – 90% Non-Condensing
Storage Humidity: 5% – 95% Non-Condensing

Package Contents
HP Thunderbolt 4 Ultra 180W G6 Dock
230W Power Adapter
Thunderbolt 4 Cable (1m)
Power Cord
Warranty Card
Documentation

Key Features
180W laptop charging
Thunderbolt 4 connectivity
40Gbps transfer speed
Up to 4 external displays
2.5GbE networking
8 USB expansion ports
HP Wolf Security
HP Quick Connect
Enterprise deployment ready

Typical Use Cases
Mobile workstation deployment
ZBook docking environments
Hot desk workspaces
Enterprise notebook deployment
Multi-monitor productivity setups
Engineering and CAD users
Hybrid workplace environments
