Ergotron StyleView® Laptop Cart, SV40 Medical Cart
PRODUCT DESCRIPTION
Ergotron StyleView® Laptop Cart, SV40 Light-Duty Medical Cart (SV40-6100-0) - 5 Years Local Warranty
Light-Duty Mobile Laptop Cart for Point-of-Care Documentation
The Ergotron StyleView SV40 Laptop Cart is the light-duty member of the StyleView medical cart range, built for wards, clinics and outpatient areas where staff need a laptop at the bedside without the bulk of a full-featured cart. It carries laptops up to 17″ and a device payload of 18 lbs (8.2 kg) on a spacious 22.4″W x 19.75″D (56.7 x 50.2 cm) worksurface, and at 52.5 lbs (23.8 kg) it is the lightest cart in the SV4x family — an advantage in Singapore's compact ward layouts and lift-served buildings.
20″ (51 cm) Sit-Stand Height Adjustment
A single Constant Force lift column delivers 20″ (51 cm) of continuous sit-to-stand height adjustment, so a nurse who is 1.5 m and a doctor who is 1.9 m can each set the worksurface to their own elbow height in seconds without tools, knobs or levers. Encouraging clinicians to alternate between sitting and standing across a 12-hour shift is one of the simplest ergonomic interventions available on a ward, and it is why sit-stand carts have become the default specification for new EMR deployments.
Secure CPU Compartment and Integrated Cable Management
The SV40 ships with a secure CPU compartment, a scanner holder bracket, a mouse holder, a wrist rest, a negative-tilt keyboard tray and integrated cable storage. Cables run inside the column rather than trailing behind the cart, which matters in an infection-control audit and removes the snag hazard that causes most cart-related equipment damage.
Easy-Clean Construction for Singapore Healthcare Facilities
The exterior is a durable, easy-to-clean composition of aluminium, high-grade plastic and zinc-plated steel that withstands repeated wipe-down with hospital-grade disinfectant. Four 4″ (10.2 cm) casters — two of them front-locking — roll the 52.5 lb (23.8 kg) cart quietly between bays and hold it steady at the bedside. SourceIT supplies the SV40 in Singapore with local warranty and a GST invoice.
Ergotron StyleView SV40 Datasheet — Technical Specifications
General
| Brand | Ergotron |
| Model | StyleView SV40 Laptop |
| Part Number | SV40-6100-0 |
| Product Type | Mobile medical cart / workstation on wheels |
| Mount Type | Laptop tray |
| Power System | Non-powered |
| Manufacturer Warranty | 5-Year Manufacturer Warranty (Ergotron) |
| Local Warranty | Local Warranty (Singapore) |
Capacity & Worksurface
| Supported Device / Screen Size | Laptops up to 17″ |
| Weight Capacity | 18 lbs (8.2 kg) |
| Worksurface Dimensions | 22.4″W x 19.75″D (56.7W x 50.2D cm) |
| Storage Compartment | 17.75″W x 14.75″D x 4″H (45 x 37.5 x 10.1 cm) |
Adjustment & Motion
| Height Adjustment (Lift) | 20″ (51 cm) |
| Casters | Four 4″ (10.2 cm) standard casters with no bearings; two front casters are lockable |
Design, Power & Durability
| Construction / Materials | Durable, easy-to-clean exterior composed of aluminium, high-grade plastic and zinc-plated steel |
| Cable Management | Integrated cable storage |
| Product Weight | 52.5 lbs (23.8 kg) |
| Shipping Dimensions | 53.2″D x 24.2″W x 31.5″H (133 x 62 x 80 cm) |
| Shipping Weight | 72 lbs (32.7 kg) |
| Warranty Detail | 5-year warranty for mechanical components; 1-year warranty for electrical components |
All specifications above are taken from the official Ergotron StyleView SV40 Series product sheet. Where Ergotron does not publish a figure for this configuration, the row is omitted rather than estimated.
Compatibility & Fit
Display / device fit. This configuration supports Laptops up to 17″ with a mounted weight capacity of 18 lbs (8.2 kg).
VESA pattern. Ergotron does not publish a VESA pattern for this configuration on its official product sheet. If you are mounting a specific display, contact SourceIT and we will confirm fit against Ergotron before you order.
Number of screens. This cart is supplied as a single-screen workstation. Ergotron offers a separate SV Dual Monitor Kit for StyleView carts where a second screen is required — see the ordering tables below.
Mounting and mobility. This is a mobile cart on a rolling base, not a desk-clamp, grommet or wall mount — there is no desk-thickness requirement and no wall fixing to plan. Four 4″ (10.2 cm) standard casters with no bearings; two front casters are lockable
Ultrawide and curved displays. Ergotron rates this mount by weight and diagonal size, not by aspect ratio. An ultrawide or curved panel that falls within the stated size and weight limits will mount, but its centre of gravity sits further from the mount than a conventional panel — check the display's own weight against the capacity figure above rather than assuming.
Singapore power. This configuration is non-powered and requires no mains connection for the cart itself.
Package Contents & StyleView Ordering Information
In the Box
- Worksurface
- secure CPU compartment
- scanner holder bracket
- mouse holder
- wrist rest
- negative-tilt keyboard tray
- cable storage
- four casters (two locking)
StyleView Cart Range — Ordering Information
|
StyleView Pole Cart 24-818-211 |
Pole cart, non-powered, white |
|
StyleView SV40 Laptop Cart (this listing) SV40-6100-0 |
Light duty, laptop, non-powered |
|
StyleView SV40 Cart with LCD Pivot SV40-6300-0 |
Light duty, LCD Pivot, non-powered |
|
StyleView SV41 Laptop Cart SV41-6100-0 |
Full featured, laptop, non-powered |
|
StyleView SV41 Cart with LCD Arm SV41-6200-0 |
Full featured, LCD Arm, non-powered |
|
StyleView SV42 Cart with LCD Pivot SV42-6302-3 |
Full featured, LCD Pivot, LiFe powered, UK |
|
StyleView SV43 Cart with LCD Arm, 1 Drawer (1x1) SV43-1210-0 |
Medication delivery, LCD Arm, non-powered |
|
StyleView SV43 Cart with LCD Pivot, 1 Drawer (1x1) SV43-1310-0 |
Medication delivery, LCD Pivot, non-powered |
|
StyleView SV44 Cart with LCD Arm, 3 Drawers (1x3) SV44-1232-3 |
Medication delivery, LCD Arm, LiFe powered, UK |
|
StyleView SV44 Cart with LCD Arm, 1 Tall Drawer (1x1) SV44-12B2-3 |
Medication delivery, LCD Arm, LiFe powered, UK |
|
StyleView SV44 Cart with LCD Pivot, 3 Drawers (1x3) SV44-1332-3 |
Medication delivery, LCD Pivot, LiFe powered, UK |
Related StyleView Accessories & Drawer Modules
| SV Primary Storage Drawer, Single | 97-863 |
| SV Primary Storage Drawer, Triple | 97-865 |
| SV Supplemental Storage Drawer, Single | 97-862 |
| SV Height-Adjustable Keyboard Arm | 97-827 |
| SV Dual Monitor Kit | 98-030 |
| SV Storage Bin | 97-740 |
| SV Front Tray | 98-134 |
| SV LiFe Replacement Battery | 97-618 |
Datasheet & Downloads
- Ergotron StyleView Medical Cart, Light Duty — Laptop Cart (SV40-6100-0)
- StyleView SV40 Documentation Medical Cart — Product Sheet (PDF)
- StyleView® SV40 Electronic Medical Records (EMR) Cart — User's Guide (PDF)
- Dimensional Illustrations — SV40 / SV41 / SV42 / SV43 / SV44 Laptop Carts (PDF)
All documents above are hosted by Ergotron. Specifications published on this page are drawn from the official Ergotron StyleView SV40 Series product sheet.
Frequently Asked Questions — Ergotron StyleView SV40
What is the difference between the SV40 Laptop Cart and the SV40 Cart with LCD Pivot?
Both share the same light-duty SV40 chassis, worksurface and casters. The laptop version (SV40-6100-0) carries laptops up to 17″ with an 18 lbs (8.2 kg) capacity and 20″ (51 cm) of lift. The LCD Pivot version (SV40-6300-0) takes displays up to 24″ at 35 lbs (15.9 kg), gives 25″ (63.5 cm) of lift and adds tilt, pan and rotation on the screen.
What size laptop fits on the SV40 Laptop Cart?
Ergotron rates the SV40 laptop configuration for laptops up to 17″, with a total device weight capacity of 18 lbs (8.2 kg). That covers essentially every clinical notebook and mobile workstation in normal use.
How much sit-stand height adjustment does it offer?
20″ (51 cm) of continuous, tool-free sit-to-stand travel. The Constant Force lift holds position at any point in that range without knobs or levers.
How does the SV40 compare with the SV41 Laptop Cart?
The SV41 Laptop Cart (SV41-6100-0) is the full-featured version: same 18 lbs (8.2 kg) capacity and 20″ (51 cm) lift, but it adds a four-port USB hub, a PC/laptop cable lock, left and right mouse trays, a rear handle and a storage basket, and it rolls on bearing casters rather than standard ones. The SV40 is lighter at 52.5 lbs (23.8 kg) against 55 lbs (25 kg) and costs less; the SV41 is the better fit where the cart is in continuous use.
Do the casters lock?
Yes. The SV40 runs on four 4″ (10.2 cm) standard casters, of which the two front casters are lockable to hold the cart steady at the bedside.
Is the surface suitable for hospital disinfectant?
Ergotron specifies a durable, easy-to-clean exterior of aluminium, high-grade plastic and zinc-plated steel, designed for the repeated wipe-down cycles used in clinical infection-control protocols.
Does the Ergotron StyleView SV40 come with a Singapore warranty?
Yes. Every Ergotron StyleView SV40 sold by SourceIT comes with local Singapore warranty and a GST invoice; Ergotron backs the StyleView SV40 with a 5-year manufacturer warranty.
