Epson WorkForce DS-410 A4 Duplex Sheet-fed Document Scanner
PRODUCT DESCRIPTION
Epson WorkForce DS-410 A4 Duplex Sheet-fed Document Scanner (B11B249501) - 1 Year Local Warranty
The Epson WorkForce DS-410 A4 Duplex Sheet-fed Document Scanner - Scan, Edit, Save. It's That Easy.
High Reliability & Durability
The DS-410 scanner is designed to deliver a high daily duty cycle of 3,000 pages, and it comes with separation roller that ensures stable and continuous scanning for large batch requirements.
A3 Scanning Without Carrier Sheet
A3 size documents can now be scanned without a carrier sheet. Simply switch the scanner to non-separation mode, and with the automatic stitching function in Epson Scan, both halves of the image will be reproduced as an entire image.
Easy File Management
Easily scan, view, edit, save and transfer scanned documents with Document Capture. The software optically recognises barcodes, characters and blank pages in scanned documents to separate them into different folders. It allows you to create up to 30 customised job settings, making multiple scan jobs a breeze.
Epson OCR Component
This OCR add-on allows you to create searchable PDF files, automatically straighten and orientate your documents based on character recognition.
High Speed Duplex Scanning
The DS-410 utilises LED technology and is always ready with zero warm-up time. With its 50-sheet Automatic Document Feeder, it performs speedily at 26ppm/52ipm at 300dpi for both colour and monochrome, resulting in significant improvements in office productivity.
ISIS Driver Support
The DS-410 comes with support for the web-downloadable, open standard ISIS driver, allowing quick and easy integration with document imaging solutions.
Powerful and Comprehensive Epson Scan Features
The Epson Scan suite of functions includes numerous useful and innovative capabilities including the following highlights:
Ideal For
Offices, clinics, accounts and admin teams in Singapore that digitise documents, receipts and records at volume. Supplied by SourceIT with local Singapore warranty, GST invoice and corporate or project pricing on request.
WorkForce DS-410 Datasheet — Technical Specifications
General
| Model | WorkForce DS-410 |
| Official Product Name | Epson WorkForce DS-410 A4 Duplex Sheet-fed Document Scanner |
| Epson Product Code | B11B249501 |
| Brand | Epson |
| Warranty | 1 Year Local Warranty (Singapore) - 12 months |
Connectivity
| Interface | USB 2.0 |
Supported OS and Applications
| Supported OS | Windows XP / Vista / 7 / 8 / 8.1 / 10 / Server 2003 / 2008 / 2012 / 2016, Mac OS X 10.6.8 or later |
| Scanner Driver Compatibility | TWAIN, SANE, WIA, ICA, ISIS (Windows) |
| Bundled Applications | Epson Scan 2, Epson Scan OCR Component, Epson Scan PDF Extensions, Document Capture Pro (Windows), Document Capture (Mac) |
Scanning
| Scanner Type | A4 sheet-fed, one-pass duplex colour scanner |
| Sensor Type | Contact Image Sensor (CIS) x 2 |
| Scanning Method | Fixed carriage and moving document |
| Light Source | RGB LED |
| Optical Resolution | 600 x 600 dpi |
| Output Resolution | 50 - 1,200 dpi (in 1 dpi increments) |
| Scanner Bit Depth (Colour) | 48-bit input, 24-bit output |
| Scanner Bit Depth (Grayscale) | 16-bit input, 8-bit output |
| Scanner Bit Depth (Black & White) | 16-bit input, 1-bit output |
| Min Document Size | 50.8 x 50.8 mm |
| Max Document Size | 215.9 x 3,048 mm |
| Supported Paper Weight | 50 - 209 g/m2, Less than A8 size: 127 - 209g/m2 |
| Output File Formats | Epson Scan 2: JPEG, TIFF, Multi-TIFF, PDF, Searchable PDF, BMP, PNG; Document Capture Pro (Win): JPEG, BMP, PDF, Searchable PDF, TIFF, Multi-TIFF, PNG, DOCX, XLSX, PPTX |
Scan Speed
| Resolution (Simplex / Duplex) | 200dpi: 26 ppm / 52 ipm (Monochrome, Colour); 300dpi: 26 ppm / 52 ipm (Monochrome, Colour); 600dpi: 21 ppm / 42 ipm (Monochrome), 7.0 ppm / 14 ipm (Colour) |
ADF Specifications
| ADF Capacity | 50 sheets (80g/m2) |
| Daily Duty Cycle | up to 3,000 sheets / day |
| Multi-feed Detection | Length Detection |
Consumables
| Consumables | Carrier Sheet, Order Code: B12B813431 |
| Roller Assembly Kit | 200,000 scans, Order Code: B12B819381 |
| Cleaning Kit | Order Code: DSCLKIT1 |
Environmental Conditions
| Temperature | Operating: 5 - 35°C; Storage: -25 - 60°C |
| Humidity | Operating: 15 – 80% (No condensation); Storage: 15 – 85% (No condensation) |
Electrical Specifications
| Rated Voltage | AC220–240V |
| Rated Frequency | 50 – 60Hz |
| Operating | 15W |
| Sleep | 0.6W |
| Power Off | 0.2W |
| Standby | 4.1W |
Compatibility & Software Support
Compatibility details below are taken from Epson Singapore's published specification for the WorkForce DS-410. Drivers, utilities and firmware are available from Epson Singapore's support site (see Datasheet & Downloads).
| Interface | USB 2.0 |
| Supported OS | Windows XP / Vista / 7 / 8 / 8.1 / 10 / Server 2003 / 2008 / 2012 / 2016, Mac OS X 10.6.8 or later |
| Scanner Driver Compatibility | TWAIN, SANE, WIA, ICA, ISIS (Windows) |
Package Contents & Ordering Information
Ordering Information
| Model | WorkForce DS-410 |
| Epson Product Code | B11B249501 |
| Recommended Retail Price (incl. GST) | S$634.00 |
| Consumables | Carrier Sheet B12B813431; Roller Assembly Kit B12B819381 (200,000 scans); Cleaning Kit DSCLKIT1 |
Epson Singapore does not publish an itemised in-the-box list for this model. Please ask SourceIT if you need the exact package contents confirmed before ordering.
Datasheet & Downloads
Frequently Asked Questions — WorkForce DS-410
What warranty does the WorkForce DS-410 come with?
1 Year Local Warranty from Epson Singapore: 12 months. Every unit sold by SourceIT is a genuine Singapore set with a GST invoice.
Which consumables does the WorkForce DS-410 use?
Carrier Sheet B12B813431; Roller Assembly Kit B12B819381 (200,000 scans); Cleaning Kit DSCLKIT1 Always use genuine Epson consumables to protect print quality and warranty coverage. SourceIT can supply them together with the unit.
Is stock held locally?
SourceIT holds fast-moving Epson models in Singapore. Anything not in local stock is ordered through Epson's local distributor - ask us for the current lead time before committing to a date.
Can SourceIT quote for multiple units or a project?
Yes. Send us your quantity and delivery requirements and we will quote the units together with consumables, options and installation where required, with local warranty and GST invoice.
