D-Link DBR-600-P Multi-Gig PoE+ Business Router
PRODUCT DESCRIPTION
D-Link DBR-600-P Multi-Gig PoE+ Business Router (DBR-600-P) - 5 Years Local Warranty
2.5G Router, PoE Switch and AP Controller in One Box
The D-Link DBR-600-P is a desktop business router from D-Link's DBR series. It combines a 2.5 Gigabit WAN port, a configurable 2.5G WAN/LAN port and seven 2.5G LAN ports, with IEEE 802.3at PoE+ output on eight 2.5GE ports to power access points, IP cameras and IP phones directly from the router.
Multi-WAN and Built-in VPN
Dual 2.5G WAN capability with load balancing and failover, plus a USB 3.0 port that D-Link describes as WAN backup, keeps the site online. The router supports IPSec, PPTP, L2TP, OpenVPN, WireGuard and GRE VPN, with D-Link quoting up to 50 IPSec tunnels and a 2 Gbps firewall.
Security and Guest Access
An SPI firewall, IPS/IDS, DoS/DDoS protection, MAC/IP filtering and URL blocking protect the network, while a captive portal (click-through, RADIUS or local database) handles guest Wi-Fi sign-in.
Manage Up to 10 DBR Access Points
The built-in controller manages up to 10 D-Link DBR-X3000-AP access points, so a small office can run router, PoE and Wi-Fi from one interface.
Need help choosing? Email sales@sourceit.com.sg with your user count, internet plan and PoE devices and we will size it for you.
D-Link DBR-600-P Datasheet — Technical Specifications
General
| Product Name | D-Link DBR-600-P Multi-Gig PoE+ Business Router |
| Part Number | DBR-600-P |
| Hardware Version | A1 (datasheet A1 v1.01 WW) |
| Form Factor | Desktop |
| Local Warranty (Singapore) | 5 years, supplied by SourceIT with a GST invoice |
Interfaces
| WAN | 1 x 10/100/1000/2.5G RJ45 |
| WAN/LAN | 1 x 10/100/1000/2.5G RJ45, configurable |
| LAN | 7 x 10/100/1000/2.5G RJ45 |
| USB | 1 x USB 3.0 (WAN backup) |
| Other | Console port, reset button, power connector |
PoE
| PoE Ports | 8 x 2.5GE PoE+ |
| PoE Standard | IEEE 802.3at |
| Per-Port Power | Up to 30 W (dlink.com product page) |
| PoE Budget | Up to 120 W (datasheet); dlink.com product page and D-Link press release state 123 W |
Security & VPN
| Firewall Throughput | 2 Gbps |
| Firewall Features | SPI firewall, IPS/IDS, DoS/DDoS protection, MAC/IP filtering, URL blocking |
| VPN Protocols | IPSec, PPTP, L2TP, OpenVPN, WireGuard, GRE |
| IPSec Tunnels | 50 |
| WAN Load Balance | Yes |
| Captive Portal | Click-through / RADIUS / Local DB |
| AP Management | Up to 10 x DBR-X3000-AP |
Physical & Environmental
| Power Input | 54 V / 2.7 A |
| Dimensions | 120 x 190 x 38 mm |
| Operating Temperature | 0 to 40 °C |
| Storage Temperature | -10 to 70 °C |
| Operating Humidity | 10% to 90% non-condensing |
| Storage Humidity | 0% to 95% non-condensing |
Compatibility & Software Support
Access Points
D-Link names the DBR-X3000-AP as the access point managed by the DBR-600-P's built-in controller (up to 10 units).
Typical Use
Small offices, retail shops and branch sites that want one device for multi-gig internet, VPN to head office, PoE for APs and cameras, and guest Wi-Fi sign-in.
Package Contents & D-Link Business Router Ordering Information
D-Link Business / VPN Routers
| Model | Ports | Wi-Fi | Part No. |
| DBR-600-P (this listing) | 1 x 2.5G WAN + 1 x 2.5G WAN/LAN + 7 x 2.5G LAN, 8 x PoE+ | No (manages DBR-X3000-AP) | DBR-600-P |
| DSR-250V2 | 1 x GE WAN + 1 x GE WAN/LAN + 3 x GE LAN | No | DSR-250V2 |
| DSR-500AC | 2 x GE WAN + 4 x GE LAN | 802.11ac | DSR-500AC |
| DSR-1000AC | 2 x GE WAN + 4 x GE LAN | Dual-band 802.11ac | DSR-1000AC |
Package contents are not listed in D-Link's datasheet — ask us if you need confirmation of the included power adapter.
Datasheet & Downloads
| D-Link datasheet | DBR-600-P A1 Datasheet (PDF) |
| D-Link product page | DBR-600-P on dlink.com |
Need a PDF sent directly? Email sales@sourceit.com.sg quoting DBR-600-P.
Frequently Asked Questions — D-Link DBR-600-P
How much PoE power does it provide?
D-Link's datasheet gives up to 120 W total across eight 802.3at PoE+ ports, while its product page quotes 123 W and up to 30 W per port. Plan on 120 W and ask us if your load is close to the limit.
Does it have built-in Wi-Fi?
No. It manages up to 10 D-Link DBR-X3000-AP access points instead.
Which VPN types are supported?
IPSec, PPTP, L2TP, OpenVPN, WireGuard and GRE, with up to 50 IPSec tunnels.
Can I use two internet lines?
Yes. One port is a dedicated 2.5G WAN and a second is configurable as WAN or LAN, with load balancing and failover; the USB 3.0 port can serve as WAN backup.
What warranty do I get?
5 years local warranty in Singapore, supplied by SourceIT with a GST invoice.
