Avocor S Series AVS-7510 75" 4K UHD Google EDLA Interactive Display for Education
Shipping calculated at checkout.
PRODUCT DESCRIPTION
Avocor S Series AVS-7510 75" 4K UHD Google EDLA Interactive Display for Education (AVS-7510) - 3 Years Warranty
The Avocor S Series AVS-7510 is a 75-inch 4K UHD interactive display built on Android 13 with Google EDLA certification and the Google Play Store, 40-point touch with stylus, 8GB RAM / 64GB storage and Bytello classroom software - an affordable, virtually edgeless display designed for education.
Key Features
- 75" 4K UHD (3840 x 2160) direct-lit LED panel, 350 cd/m2, 5000:1 contrast, 6.5 ms, 10-bit colour.
- Up to 40-point touch with 2 fine-tip styluses; 3.2 mm zero-bonded anti-glare glass, 7H hardness.
- Android 13, Google EDLA certified with Google Play preloaded; Amlogic T982 quad-core, 8GB RAM / 64GB storage.
- Front USB-C (65W PD) with HDMI and USB-B touch; 3 x HDMI in, HDMI out, VGA, OPS slot; Wi-Fi 6 module and Bluetooth.
- Bytello Class, Note, Share and Browse preloaded (licence required); Google Drive and OneDrive access; multi-window and picture-in-picture.
- 2 x 16W front-facing spatial-stereo speakers; wall mount included; NDAA compliant.
Avocor AVS-7510 Datasheet — Technical Specifications
General
| Product Name | Avocor S Series AVS-7510 75" 4K UHD Google EDLA Interactive Display for Education |
| Brand | Avocor |
| Part Number | AVS-7510 |
| Series | Avocor S Series (S10) |
| Warranty | 3 years (Avocor Asia region, return to base); optional 2-year extension available (AVC-EW-S75) |
| Compliance | NDAA compliant; Google EDLA certified |
Display
| Screen Size | 75" (16:9, landscape only) |
| Panel | LCD, direct-lit LED backlight |
| Resolution | 3840 x 2160 (4K UHD) @ 60Hz |
| Brightness | 350 cd/m2 |
| Contrast Ratio | 5000:1 |
| Response Time | 6.5 ms |
| Viewing Angle | 178 / 178 degrees |
| Colour | 10-bit, 1.07 billion colours |
| Glass | 3.2 mm zero-bonded, anti-glare, 7H hardness |
| Operation Time | 16/7 |
Touch
| Touch Points | Up to 40 points + 1 stylus (40-point in Windows PC mode; macOS and Linux single touch) |
| Touch Interface | 2 x USB-B 2.0, 1 x USB-C |
| Supported OS | Windows 8/10/11, macOS, Linux |
Android / Compute
| Operating System | Android 13 (Google EDLA certified, Google Play Store) |
| Chipset | Amlogic T982, quad-core Cortex-A55, Mali-G52 MP2 GPU |
| Memory / Storage | 8GB RAM / 64GB |
| OPS Slot | Yes (3840 x 2160 @ 60Hz) |
| Wi-Fi | Wi-Fi 6 (802.11ax) pluggable module |
| Bluetooth | Yes |
Audio
| Speakers | 2 x 16W spatial-stereo, front-facing |
| Microphone / Camera | None / None |
Connectivity
| Front | 1 x USB-C (65W PD, data, A/V), 1 x HDMI in, 1 x USB-B (touch), 2 x USB-A 3.0 hub |
| Side | 2 x HDMI in (4K@60Hz, HDCP 2.1, CEC, ARC on HDMI 1), 1 x HDMI out, 1 x VGA, 2 x USB-A 3.0, 1 x USB-B 2.0 (touch) |
| Audio | 1 x 3.5 mm audio out, 1 x 3.5 mm audio in, 1 x optical S/PDIF out |
| Control / Network | 1 x IR in, 1 x RS-232, 2 x RJ-45 LAN |
Power & Physical
| Power Supply | AC 100-240V, 50/60Hz |
| Max Power | <360W |
| Standby Power | <= 0.5W |
| Operating Temperature | 0 to 40 C, 10-90% RH |
| Dimensions (W x H x D) | 1709 x 1020 x 88 mm |
| Shipping Dimensions | 1863 x 1140 x 225 mm |
| Net / Gross Weight | 47.3 kg / 60.75 kg |
| VESA | 800 x 400 mm (wall mount included) |
| Handles | 2 |
Compatibility & Software Support
Software
| Bytello Class | Lesson delivery, quizzes, whiteboard and performance tracking (software licence required) |
| Bytello Note / Share / Browse | Whiteboard with handwriting recognition, wireless sharing and browser (licence required) |
| Bytello DMS | Remote device management for IT teams |
| Google Play, Google Drive and OneDrive access; Google Classroom / Meet integration requires a Google EDLA OPS PC | |
| Avocor UiQ | Not available on the S Series |
Expansion
| Software licences | Bytello Class for Windows (Perpetual) AVC-CLSW, Bytello DMS Pro AVC-DMS-YR |
| OPS PC modules | i5 Gen 11 OPS, i7 Gen 11 OPS, Google EDLA Android OPS |
| Mobile stand | Avocor Mobile Stand AVC-STND1 |
| Extended warranty | 2-Year Extended Warranty AVC-EW-S75 |
Package Contents & S Series Ordering Information
In the Box
- 1 x Remote control
- 2 x 3 mm fine-tip passive touch styluses
- 1 x Wall mount
- 1 x AC power cord
- 1 x USB-B 3.0 cable
- 1 x HDMI cable
- 1 x Quick start guide
Avocor S Series Education Displays & Software
Datasheet & Downloads
| Product page | Avocor S Series |
| Datasheet | Avocor S Series Datasheet (PDF) |
| User manual | AVS-xx10 User Manual |
| Education brochure | Avocor Education Brochure (PDF) |
| Warranty | Avocor Global Warranty by Region |
Frequently Asked Questions — Avocor AVS-7510
What does Google EDLA certification mean?
The display runs licensed Google Mobile Services, so teachers get the Google Play Store, Google Drive and familiar Android apps directly on the panel without a separate PC.
Is Bytello Class included?
Bytello Class, Note, Share and Browse are preloaded but require a software licence, such as Bytello Class for Windows (AVC-CLSW).
Is a wall mount included?
Yes, a VESA wall mount and two styluses are in the box; a mobile stand (AVC-STND1) is optional.
What warranty applies in Singapore?
3 years return to base under Avocor's Asia-region warranty; a 2-year extension (AVC-EW-S75) is available.
