ViewSonic VX3480-2K-PRO 34" UWQHD 165Hz Gaming Monitor
PRODUCT DESCRIPTION
ViewSonic VX3480-2K-PRO 34" 165Hz UWQHD Gaming Monitor - 3 Years Local Warranty
Panoramic Gaming
21:9 ultrawide display with a crystal clear 3440 x 1440 resolution.
165 Hz Refresh Rate
Hyper-responsive 165 Hz refresh rate for seamless gaming.
1 ms (MPRT)
Ghost-free clarity for sharp, immersive visuals.
AMD FreeSync Premium
Eliminates screen tearing and stuttering during gameplay.
Need monitors for a whole office, studio or gaming room? Email sales@sourceit.com.sg for volume pricing and delivery lead time.
ViewSonic VX3480-2K-PRO Datasheet — Technical Specifications
General
| Product Name | ViewSonic VX3480-2K-PRO 34" 165Hz UWQHD Gaming Monitor |
| Model | VX3480-2K-PRO |
| Local Warranty (Singapore) | 3 years on-site limited warranty on parts and labour |
Display
| Screen Size | 34" |
| Panel Type | VA |
| Resolution | 3440 x 1440 (UWQHD), 21:9 |
| Refresh Rate | 165 Hz (DisplayPort); 100 Hz (HDMI) |
| Response Time | 1 ms (MPRT) |
| Brightness | 300 cd/m² (typ) |
| Contrast Ratio | 4,000:1 static (typ); 80M:1 dynamic |
| HDR | HDR10 |
| Adaptive Sync | FreeSync Premium |
| Colours | 16.7M, 8-bit true |
| Colour Gamut | sRGB 128% size; NTSC 90% size (typ) |
| Viewing Angles | 178° H / 178° V |
| Pixel Size | 0.232 x 0.232 mm |
| Surface | Anti-glare, 3H hard coating |
| Flicker-Free / Low Blue Light | Yes / software solution |
| Backlight Life | 30,000 hours (min) |
Connectivity
| HDMI | 2 x HDMI 2.1 |
| DisplayPort | 1 x DisplayPort 1.4 |
| USB | 1 x USB 2.0 Type-A |
| Audio Out | 1 x 3.5 mm |
| Kensington Lock Slot | 1 |
Power
| Voltage | AC 100–240 V |
| Consumption | 43 W typical; 45 W max; 0.5 W standby |
| Eco Mode | 24 W (conserve) / 32 W (optimised) |
| Power Supply | External power adapter |
Operating Conditions
| Temperature | 0–40 °C |
| Humidity (non-condensing) | 20%–90% |
Physical & Ergonomics
| Dimensions with Stand (W x H x D) | 814 x 478–584 x 264 mm |
| Dimensions without Stand | 814 x 356 x 42 mm |
| Net Weight | 7.1 kg (5.1 kg without stand) |
| Packaging (W x H x D) | 933 x 498 x 213 mm |
| Gross Weight | 9.8 kg |
| Height Adjustment | 140 mm |
| Swivel | 90° |
| Tilt | -5° / 20° |
| VESA | 100 x 100 mm |
Compatibility & Software Support
Devices
Windows 10/11 certified and macOS tested at 3440 x 1440. Use DisplayPort 1.4 for 165 Hz; HDMI 2.1 inputs run up to 100 Hz.
Software
On-screen ViewMode presets (favourite hot key), Eco Mode and Eye Care flicker-free backlight with blue light filter.
Package Contents & ViewSonic VX Series Ordering Information
In the Box
VX3480-2K-PRO monitor, power cable (IEC C13), DisplayPort cable (v1.4), AC/DC adapter, quick start guide.
ViewSonic VX Series Monitors
| Model | Key feature |
| VX2479A-HD-PRO | 24" FHD IPS 240 Hz, 1 ms MPRT |
| VX2532 | 25" (24.5") FHD IPS 320 Hz, HDMI 2.1 |
| VX2718-2KPC-MHD | 27" QHD VA 180 Hz, 1500R curved, speakers |
| VX2766-2K-PRO-9 | 27" QHD IPS 320 Hz, 97% DCI-P3, HDMI 2.1 |
| VX2779A-HD-PRO | 27" FHD IPS 240 Hz, 1 ms MPRT |
| VX3219-PC-MHD | 32" FHD VA 240 Hz, 1500R curved, speakers |
| VX3276-2K-MHD-2 | 32" QHD IPS 75 Hz, HDR10, speakers |
| VX3418C-2K | 34" UWQHD VA 200 Hz, 1500R curved, 2 x 5 W speakers |
| VX3480-2K-PRO (this listing) | 34" UWQHD VA 165 Hz, height-adjust stand |
Datasheet & Downloads
| ViewSonic datasheet | VX3480-2K-PRO Datasheet |
| User guide | VX3480-2K-PRO User Guide (PDF, English) |
| Quick start guide | VX3480-2K-PRO Quick Start Guide (PDF) |
| ViewSonic product page | VX3480-2K-PRO on viewsonic.com |
Need a PDF sent directly? Email sales@sourceit.com.sg quoting VX3480-2K-PRO.
Frequently Asked Questions — ViewSonic VX3480-2K-PRO
How do I get 165 Hz?
Connect by DisplayPort 1.4; HDMI 2.1 inputs run up to 100 Hz.
Does it have built-in speakers?
No speakers are listed by ViewSonic; use the 3.5 mm audio out for headphones or speakers.
Is the stand adjustable?
Yes: 140 mm height adjustment, 90° swivel and -5° / 20° tilt.
What warranty do I get?
3 years on-site limited warranty on parts and labour in Singapore. Supplied by SourceIT with a GST invoice.
