ViewSonic ViewShare WPD-900 Wireless Screen Casting Kit 1080p USB-C
PRODUCT DESCRIPTION
ViewSonic ViewShare WPD-900 Wireless Screen Casting Kit - 1 Year Local Warranty
Plug-and-Play Wireless Casting
Plug the USB-C transmitter into your laptop and the receiver into the projector or display — cast up to 1080p 60Hz with no app or driver.
Low Latency, Up to 30 m
Peer-to-peer 5G Wi-Fi with auto channel hopping keeps latency under 80 ms at up to 30 m.
Charge While You Present
USB-C pass-through supports up to 60W PD, so your laptop keeps charging. Mirror or extend your screen, including DRM-protected streaming content.
Equipping several meeting rooms? Email sales@sourceit.com.sg for volume pricing.
ViewSonic WPD-900 Datasheet — Technical Specifications
General
| Product Name | ViewSonic ViewShare WPD-900 Wireless Screen Casting Kit |
| Model | WPD-900 |
| Output Resolution | Up to 1080p 60Hz |
| HDCP | HDCP 1.4 |
| Wi-Fi | 5G |
| Screen Mirror / Extend | Yes |
| Latency | <80 ms |
| Transmission Distance | Up to 30 m |
Transmitter
| Connectors | USB-C x 2 (video x1, power input supporting up to 60W PD x1) |
| Power Input | 5V/1A |
| Dimensions (W x D x H) | 87 x 42 x 15 mm |
| Net Weight | 23 g |
Receiver
| Connectors | HDMI x 1, USB-A x 1 |
| Power Input | 5V/0.5A |
| Net Weight | 27.5 g |
In the Box
WPD-900 transmitter (USB-C) and receiver (HDMI + USB-A) — see the ViewSonic user guide for the full package list.
Compatibility & Software Support
Devices
Connect the transmitter to a laptop's video-capable USB-C port; ViewSonic states it also supports Miracast and iOS/macOS mirroring.
ViewSonic Projectors Listed
ViewSonic lists the WPD-900 as an accessory for the following projectors. The receiver connects to the display's HDMI input and draws power from USB-A.
| LS832WU | ViewSonic projector |
| LS901HD | ViewSonic projector |
| LS920WU | ViewSonic projector |
| LS921WU | ViewSonic projector |
| LS950WU | ViewSonic projector |
| LS951WU | ViewSonic projector |
| LS960WU | ViewSonic projector |
| LSC601WU | ViewSonic projector |
| LSC801WU | ViewSonic projector |
| LSD400HD | ViewSonic projector |
| LSD400HD-ST | ViewSonic projector |
| LSD400W | ViewSonic projector |
| LSD500HD | ViewSonic projector |
| LX720-4K | ViewSonic projector |
| LX750-4K | ViewSonic projector |
| M1X | ViewSonic projector |
Datasheet & Downloads
| ViewSonic datasheet | WPD-900 Datasheet |
| User guide | WPD-900 User Guide (PDF, English) |
| ViewSonic product page | WPD-900 on viewsonic.com |
Need a PDF sent directly? Email sales@sourceit.com.sg quoting WPD-900.
Frequently Asked Questions — ViewSonic WPD-900
Do I need to install software?
No. It is plug-and-play: connect the transmitter to a USB-C laptop and the receiver to the display's HDMI port.
What resolution does it support?
Up to 1080p 60Hz with HDCP 1.4, so protected streaming content can be shown.
How far can the transmitter be from the receiver?
ViewSonic quotes up to 30 m with latency below 80 ms.
Can my laptop charge while casting?
Yes — the transmitter's second USB-C port passes through up to 60W PD.
Which projectors is it made for?
ViewSonic lists LS, LSC, LSD, LX and M1X models (see Compatibility). The receiver needs an HDMI input and USB-A power on the display.
What warranty applies?
1 year local warranty. Supplied by SourceIT with a GST invoice.
