Micron 7450 PRO 960GB NVMe PCIe Gen4 M.2 2280 Enterprise SSD (TCG Opal)
PRODUCT DESCRIPTION
Micron 7450 PRO 960GB NVMe PCIe Gen4 M.2 2280 Enterprise SSD MTFDKBA960TFR-1BC15ABYYR - 5 Years Warranty
Enterprise NVMe Boot Drive
An M.2 2280 data center SSD with full power-loss protection, ideal as a server boot or caching drive.
PCIe Gen4 Speed
Up to 5,000 MB/s reads and 520,000 random-read IOPS with sub-2 ms 99.9999% quality-of-service latency.
Self-Encrypting
TCG Opal 2.01 SED with IEEE 1667 and Micron's Secure Execution Environment protects data at rest.
Micron 7450 PRO 960GB Datasheet — Technical Specifications
General
| Product Name | Micron 7450 PRO 960GB |
| Part Number | MTFDKBA960TFR-1BC15ABYYR |
| Form Factor | M.2 2280 (22 x 80 mm) |
| Interface | PCIe Gen4 x4, NVMe 1.4 |
| Capacity | 960GB |
| Security | Self-encrypting (SED), TCG Opal 2.01, IEEE 1667 |
| Warranty | 5 years |
Performance
| Sequential Read / Write | Up to 5,000 / 1,400 MB/s |
| Random 4K Read / Write | Up to 520,000 / 82,000 IOPS |
| Latency (typical) | Read 80 µs / write 15 µs |
| QoS | Sub-2 ms latency at 99.9999% |
Endurance & Reliability
| Endurance | 1,700 TBW (1 DWPD class) |
| MTTF | 2 million hours |
| UBER | <1 sector per 10^17 bits read |
| Data Protection | Full power-loss protection, Secure Execution Environment |
Power & Environment
| Power | Read 7 W, write 5.6 W avg, idle 2.9 W |
| Operating Temperature | 0 to 70 °C |
| Weight | Under 11 g |
NAND
| Flash | Micron 176-layer TLC NAND |
Compatibility & Applications
Typical Use
Server and appliance boot drives, hypervisor boot, logging and read caching.
Compatibility
Needs an M.2 2280 slot with PCIe NVMe support (M-key); not for SATA-only M.2 slots.
Selection Tip
Need a 2.5-inch SATA drive instead? See the Micron 5400 PRO.
Package Contents & Micron Ordering Information
In the Box
1 x Micron 7450 PRO 960GB M.2 2280 NVMe SSD (single pack). Mounting screw not included.
Micron Data Center Memory & SSDs at SourceIT
| Model | Key feature |
| MTC40F2046S1RC64BH1 | DDR5 RDIMM 64GB 2Rx4 6400 MT/s CL52 (tray) |
| MTC40F2047S1RC64BB1R | DDR5 RDIMM 128GB 2Rx4 6400 MT/s CL52, 32Gb die |
| MTFDDAK480TGA-1BC1ZABYYR | 5400 PRO 480GB SATA 2.5" 7mm |
| MTFDDAK1T9TGA-1BC1ZABYYR | 5400 PRO 1.92TB SATA 2.5" 7mm |
| MTFDKBA480TFR-1BC15ABYYR | 7450 PRO 480GB NVMe Gen4 M.2 2280, TCG Opal |
| MTFDKBA960TFR-1BC15ABYYR (this listing) | 7450 PRO 960GB NVMe Gen4 M.2 2280, TCG Opal |
| MTFDLAL3T8THG-1BP1DFCYYR | 7600 PRO 3.84TB NVMe Gen5 U.2 15mm |
| MTFDLAL15T3THG-1BP1DFCYYR | 7600 PRO 15.36TB NVMe Gen5 U.2 15mm |
| MTFDLBQ7T6THA-1BK1DABYYR | 9550 PRO 7.68TB NVMe Gen5 E3.S 7.5mm |
Official Micron Videos
Micron Data Center SSDs: When Your Business Demands More (official Micron Technology channel)
How Solid State Drives (SSDs) Are Made — Inside the Manufacturing Process (official Micron Technology channel)
Datasheet & Downloads
| Product brief | Micron 7450 NVMe SSD Product Brief (PDF) |
| Technical specification | Micron 7450 NVMe SSD Technical Product Specification (PDF) |
| Product page | Micron 7450 NVMe SSD on micron.com |
Frequently Asked Questions — Micron 7450 PRO 960GB
Is this an enterprise SSD?
Yes. The 7450 PRO is a data center NVMe SSD with full power-loss protection.
Is it self-encrypting?
Yes. This version supports TCG Opal 2.01.
What is the endurance?
1,700 TBW.
What warranty do I get?
5 years Micron warranty.
Do I get a GST invoice?
Yes. Supplied by SourceIT in Singapore with a GST invoice.
