Logitech Rally Mic Pod Hub
PRODUCT DESCRIPTION
Logitech Rally Mic Pod Hub (939-001647) - 2 Years Local Warranty
Logitech Rally Mic Pod Hub — Hub-and-Spoke Microphone Layouts for Any Table
The Logitech Rally Mic Pod Hub (939-001647) connects up to three Rally Mic Pods or additional hubs from one point under the table, eliminating back-and-forth cabling on U-shaped or asymmetrical conference tables and giving full flexibility over where each microphone sits.
Hidden Cabling and Mic Pod Mobility
Pods connect through table grommets to hubs beneath the table, so no cables cross the tabletop. Because each pod runs on its own single cable, a pod can be moved without disturbing its neighbours. Under-table mounting hardware is included.
Logitech Rally Mic Pod Hub Datasheet — Technical Specifications
General
| Part Number | 939-001647 |
| Product series | Logitech Rally Mic Pod accessories |
| Compatibility | Rally, Rally Plus, Rally Bar or Rally Bar Mini configured with external Rally Mic Pods |
| Warranty | 2 Years Local Warranty (Singapore) |
Connectivity
| Connections | Three 12-pin connections for any combination of Rally Mic Pods or additional Rally Mic Pod Hubs |
| Output | Captive 2.95 m (9.6 ft) 12-pin cable |
| Mounting | Under-table mounting hardware included |
Dimensions
| Dimensions (H x W x D) | 16 x 102 x 102 mm |
Compatibility & System Requirements
Rally Mic Pod Hub works with Rally Bar, Rally Bar Mini, Rally and Rally Plus when configured with external Rally Mic Pods. It is not compatible with the standalone USB Rally Camera, and it is not used with Rally Board 65 and Rally Mic Pod 2.
| System | Maximum Rally Mic Pods |
| Logitech Rally | Up to 7 (1 included) |
| Logitech Rally Plus | Up to 7 (2 included) |
| Logitech Rally Bar | Up to 3 |
| Logitech Rally Bar Mini | Up to 2 |
Package Contents & Rally Mic Pod Accessories Ordering Information
In the box: Mic Pod Hub, mounting hardware and documentation.
Rally Mic Pod family at SourceIT:
| Model | Part Number |
| Logitech Rally Mic Pod Graphite | 989-000430 |
| Logitech Rally Mic Pod Off-white | 952-000038 |
| Logitech Rally Mic Pod Mount Graphite | 952-000002 |
| Logitech Rally Mic Pod Mount Off-white | 952-000020 |
| Logitech Rally Mic Pod Hub (this listing) | 939-001647 |
| Logitech Rally Mic Pod Extension Cable 10 m | 952-000047 |
| Logitech Rally Mic Pod CAT Coupler Graphite | 952-000181 |
| Logitech Mic Pod Pendant Mount | 952-000123 |
Datasheet & Downloads
Frequently Asked Questions — Logitech Rally Mic Pod Hub
How many Mic Pods can one hub connect?
Three, in any combination of Rally Mic Pods or additional Rally Mic Pod Hubs. The overall pod limit is set by the system: up to seven on Rally and Rally Plus, three on Rally Bar and two on Rally Bar Mini.
When do I need a hub instead of daisy-chaining?
Daisy-chaining suits a long straight table. A hub is better for U-shaped or asymmetrical tables and when you want each pod on its own cable so pods can be moved independently.
Do I need a hub for pendant-mounted pods?
Yes — Logitech states that rooms with more than one Mic Pod Pendant Mount require a Mic Pod Hub.
Does it work with the standalone Rally Camera?
No. It is designed for Rally, Rally Plus, Rally Bar and Rally Bar Mini systems configured with Rally Mic Pods.
Does it come with a local warranty?
Yes. Every Logitech Rally Mic Pod Hub sold by SourceIT comes with 2 years local Singapore warranty and a GST invoice.
