J5Create JCT425 Wood Monitor Stand with Docking Station
Shipping calculated at checkout.
PRODUCT DESCRIPTION
J5Create JCT425 Wood Monitor Stand with Docking Station - 2 Years Local Warranty
A desktop monitor riser with built-in connectivity, keeping cables and ports within reach.
Key Features
- Solid pine-wood top on an aluminium-alloy frame, rated to 40 kg (88 lbs)
- Raises the monitor toward eye level with storage space underneath for keyboard and mouse
- Built-in USB-C dock with 4K HDMI output and multiple USB 3.0 Type-A ports
- USB-C Power Delivery pass-through charging for the laptop
- Works with USB-C MacBook, Windows and Chromebook laptops
Equipping a team or office? Email sales@sourceit.com.sg for volume pricing and delivery lead time.
j5create JCT425 Datasheet — Technical Specifications
General
| Local Warranty (Singapore) | 2-year limited warranty (j5create), supplied by SourceIT with a GST invoice |
| Brand | j5create |
| Model | JCT425 |
| Product Name | Wood Monitor Stand with Docking Station |
| EAN | 4712795083286 |
Ports
| Host Connector | 1 x USB-C (female) - USB-C 3.1 Gen 1 host |
| USB-C | 1 x USB-C with Power Delivery 3.0; 1 x USB-C 3.1 Gen 1 (data & charging) |
| USB-A | 3 x USB 3.0 Type-A; 2 x USB 3.0 Type-A with BC 1.2 |
| Video Output | 1 x 4K HDMI |
Video & Audio
| Displays Supported | 1 |
| Max Resolution | 3840 x 2160 |
| Max Refresh Rate | 4K @ 30Hz; 1080p @ 60Hz |
| Audio | 2.1 via HDMI |
Power
| Power Delivery | Up to 60W |
| Input | Up to 20V / 1.5A |
| Output | Up to 20V / 2.75A |
| Power Consumption | ≤ 900 mA |
| Power Source | Bus-powered or self-powered |
Physical
| Colour | Natural Wood Grain, Tan |
| Material | Aluminum, Pine Wood |
| Dimensions (W x D x H) | 533.91 x 247.9 x 89.92 mm (21.02 x 9.76 x 3.54 in) |
| Weight | 2500 g ± 50 g (incl. cable) |
| Cable Length | 199.9 mm (7.87 in) |
| Load Capacity | 40 kg (88 lbs) |
Environmental
| Operating Temperature | 0 to 30°C |
| Storage Temperature | -10 to 65°C |
| Humidity | < 85% non-condensing |
Compatibility
| Laptops | MacBook, Windows, Chromebook (USB-C) |
Compatibility & System Requirements
System Requirements
- Available USB-C port supporting DisplayPort Alt Mode and USB Power Delivery 2.0 or 3.0 (USB 3.1 recommended)
- DisplayPort 1.2 on the video source for 4K @ 30Hz
- 4K-capable display required for 3840 x 2160
Compatibility
| Laptops | MacBook, Windows, Chromebook (USB-C) |
Package Contents & j5create Laptop & Monitor Stands Ordering Information
In the Box
- 1 x Wood Monitor Stand
- 1 x USB-C to 6-Port USB 3.1 Hub with 4K HDMI
- 1 x USB-C 3.1 male-to-male cable
- 1 x Quick Installation Guide
- 1 x Instruction manual and tools
j5create Laptop & Monitor Stands at SourceIT
| Model | Product |
| JTS223 | Laptop Stand with USB 4-Port Hub |
| JTS127 | Multi-Angle Laptop Stand |
| JTS427 | Multi-Angle Dual HDMI Docking Stand |
| JTSA302 | Ergonomic Dual-Monitor Mount with Docking Station |
| JCT425 (this listing) | Wood Monitor Stand with Docking Station |
Datasheet & Downloads
| j5create product page | JCT425 on j5create.com |
| Downloads & Drivers page | Downloads & Drivers page |
Need a document sent directly? Email sales@sourceit.com.sg quoting JCT425.
Frequently Asked Questions — j5create JCT425
How many external displays does it support?
1. Actual output depends on your laptop's USB-C / Thunderbolt video support; see the Compatibility section.
How much charging power reaches my laptop?
Up to about 55W, based on j5create’s published output rating, when a suitable USB-C PD power adapter is connected (adapter sold separately unless listed in the box).
What warranty do I get?
2-year limited warranty from j5create, supplied locally in Singapore by SourceIT with a GST invoice.
Can SourceIT quote for bulk or corporate orders?
Yes. Email sales@sourceit.com.sg quoting JCT425 and the quantity for volume pricing and delivery lead time.
