HP ZBook 8 G2i 16 U7-356H 48GB 1TB RTX PRO 500 Mobile Workstation
PRODUCT DESCRIPTION
HP ZBook 8 G2i 16 inch Mobile Workstation PC (DS3X5AT) - 3 Years Local Warranty
Mobile Workstation Performance
HP ZBook 8 G2i 16 is configured with the Intel Core Ultra 7 356H, 48 GB memory and a 1 TB PCIe Gen5 NVMe M.2 SSD. Graphics are handled by the NVIDIA RTX PRO 500 Blackwell Generation Laptop GPU for CAD, visualisation and GPU-accelerated workloads.
16-inch WUXGA Display and Collaboration
The 16-inch WUXGA (1920 x 1200) IPS anti-glare panel is rated at 400 nits. A 5 MP IR AI camera, Audio by Poly Studio and HP Premium Keyboard, spill-resistant, backlit, with numeric keypad cover video calls and everyday input.
Connectivity, Battery and Warranty
Wireless is Intel Wi-Fi 7 BE211 (2x2) and Bluetooth 6.0. Power comes from a HP Long Life 8-cell, 77 Wh polymer battery with the HP 140 W USB Type-C slim adapter, and the unit carries 3 years of local onsite support through SourceIT.
Buying for a team or project roll-out? Email sales@sourceit.com.sg for volume pricing and delivery lead time.
HP ZBook 8 G2i 16 Datasheet — Technical Specifications
General
| Product Name | HP ZBook 8 G2i 16 inch Mobile Workstation PC |
| Part Number | DS3X5AT |
| Product Line | HP ZBook mobile workstation |
| Local Warranty (Singapore) | 3 years onsite hardware support (HP 1-year limited warranty plus bundled HP 3-year Onsite Care Pack with Predictive Detection Alerts), supplied by SourceIT with a GST invoice |
Processor and Memory
| Processor | Intel Core Ultra 7 356H (up to 4.7 GHz with Intel Turbo Boost Technology, 18 MB L3 cache, 16 cores, 16 threads) |
| AI / NPU | 50 NPU TOPS |
| Memory | 48 GB (2 x 24 GB) DDR5-5600 SODIMM |
| Memory Slots | 2 SODIMM slots (both in use) |
Graphics and Display
| Graphics | NVIDIA RTX PRO 500 Blackwell Generation Laptop GPU (6 GB GDDR7 dedicated) |
| Display | 40.6 cm (16") WUXGA (1920 x 1200), IPS, anti-glare, 400 nits |
| Touchscreen | No |
Storage and Operating System
| Internal Storage | 1 TB PCIe Gen5 NVMe M.2 SSD |
| Operating System | Windows 11 Pro 64 |
Connectivity
| Wireless | Intel Wi-Fi 7 BE211 (2x2) and Bluetooth 6.0 |
| Ports | Left: 1 HDMI 2.1, 1 3.5 mm audio combo jack, 2 Thunderbolt 4 with USB Type-C 40Gbps (USB Power Delivery, DisplayPort 2.1). Right: 1 USB Type-A 5Gbps, 1 RJ-45, 1 nano security lock slot, 1 USB Type-C 10Gbps (USB Power Delivery, DisplayPort 1.4) |
Camera, Audio and Input
| Camera | 5 MP IR AI camera |
| Audio | Audio by Poly Studio, 2 integrated stereo speakers, discrete amplifiers, 2 integrated dual array digital microphones |
| Keyboard and Pointing Device | HP Premium Keyboard, spill-resistant, backlit, with numeric keypad; Clickpad with multi-touch gesture support |
| Security | Fingerprint sensor; active SmartCard reader |
Power and Physical
| Battery | HP Long Life 8-cell, 77 Wh polymer |
| Power Adapter | HP 140 W USB Type-C slim adapter |
| Dimensions (W x D x H) | 35.9 x 25.1 x 1.9 cm |
| Colour | Meteor silver aluminium |
Compatibility & Software Support
Operating System
Ships with Windows 11 Pro 64 preinstalled.
Docking and Displays
The Thunderbolt and USB Type-C ports support HP Thunderbolt and USB-C docks for single-cable desk setups; an HDMI 2.1 port connects an external monitor or projector directly.
Typical Use
3D CAD, BIM, visualisation, data science and engineering applications that benefit from professional NVIDIA RTX PRO graphics.
Package Contents & Ordering Information
In the Box
HP ZBook 8 G2i 16 (DS3X5AT), HP 140 W USB Type-C slim adapter, power cord and documentation.
HP ZBook Mobile Workstations
| Model | Configuration |
| HP ZBook X G1i 16 (DF7Q8AT) | Core Ultra 7 255H, 32GB, 1TB SSD, RTX PRO 1000, touch |
| HP ZBook Fury G1i 16 (D44HFUP) | Core Ultra 7 265HX vPro, 64GB, 4TB SSD, RTX PRO 3000 |
| HP ZBook 8 G2a 14 (DS3X6AT) | Ryzen AI 7 PRO 450, 48GB, 1TB SSD |
| HP ZBook 8 G2a 16 (DS3X7AT) | Ryzen AI 7 PRO 450, 48GB, 1TB SSD |
| HP ZBook 8 G2i 14 (DS3X4AT) | Core Ultra 7 356H, 48GB, 1TB SSD, RTX PRO 500 |
| HP ZBook 8 G2i 16 (DS3X5AT) (this listing) | Core Ultra 7 356H, 48GB, 1TB SSD, RTX PRO 500 |
| HP ZBook X G2i 16 (E67A7PT) | Core Ultra 7 356H, 32GB, 1TB SSD, RTX PRO 1000, touch |
Datasheet & Downloads
| HP product page | HP ZBook 8 G2i 16 on hp.com |
| HP support | HP ZBook 8 G2i 16 — HP Support, drivers and manuals |
Need a PDF sent directly? Email sales@sourceit.com.sg quoting DS3X5AT.
Frequently Asked Questions — HP ZBook 8 G2i 16
What is the exact configuration of DS3X5AT?
Intel Core Ultra 7 356H, 48 GB (2 x 24 GB) DDR5-5600 SODIMM, 1 TB PCIe Gen5 NVMe M.2 SSD, 40.6 cm (16") WUXGA (1920 x 1200) display, Windows 11 Pro 64.
Can the memory be upgraded?
Memory is fitted in SODIMM slots: 2 SODIMM slots (both in use).
Does it have a touchscreen?
No, this configuration has a non-touch display.
Which graphics does it use?
NVIDIA RTX PRO 500 Blackwell Generation Laptop GPU (6 GB GDDR7 dedicated).
What warranty do I get?
3 years onsite hardware support (HP 1-year limited warranty plus bundled HP 3-year Onsite Care Pack with Predictive Detection Alerts), supplied by SourceIT with a GST invoice.
