Ergotron CareFit™ Enclosure White
PRODUCT DESCRIPTION
Ergotron CareFit™ Enclosure, Snow White (61-367-030) - 5 Years Local Warranty
A Fold-Away Sit-Stand Clinical Workstation, Not Just an Enclosure
The Ergotron CareFit Enclosure (61-367-030, snow white) is easy to under-read as a cabinet. It is in fact a wall-mounted sit-stand computer workstation with 20 in (51 cm) of height adjustment, which folds away and locks when it is not in use. Clinicians work sitting or standing at the point of care; when the consultation ends, the whole workstation closes flat against the wall.
Stays Within 4 Inches of the Wall When Closed
The low-profile design keeps the closed enclosure within 4 in (10.2 cm) of the wall. In Singapore ward bays, consult rooms and clinic corridors, where circulation clearance is tightly regulated and floor space is at a premium, a workstation that vanishes into the wall between patients is worth considerably more than one that occupies floor area permanently.
Secure by Design — 10-Digit Lock Code
A 10-digit lock code secures the closed enclosure, keeping patient data and the technology inside protected in shared and public-facing clinical areas. Integrated cable management keeps cords organised and easy to clean, which matters both for infection-control routines and for keeping a wall-mounted unit tidy in an inspected environment.
Houses the Screen, Keyboard, Mini PC and Scanner Together
The enclosure fits most 24–27 inch screens against a black backing for a seamless look, and carries a monitor pivot rated 7–12.5 lb (3.2–5.7 kg), a keyboard tray rated 0.5–3 lb (0.2–1.4 kg) and a mini PC bay rated 3–8 lb (1.4–3.6 kg). A removable 24.7 x 7.4 in (62.7 x 18.9 cm) worksurface and a T-slot for accessories such as a proximity reader or printer complete the point-of-care setup, with easy access to a scanner for medication delivery.
Ergotron CareFit Enclosure Datasheet — Technical Specifications
General
| Part Number | 61-367-030 |
| Product Name | Ergotron CareFit Enclosure, Snow White |
| Product Type | Fold-away, lockable wall-mount sit-stand computer workstation |
| Finish | Snow white (matte black also available as 61-367-060) |
| Mounting | Wall mounted |
| 5-Year Manufacturer Warranty (Ergotron) | Included |
| Local Warranty (Singapore) | Supported by SourceIT Pte Ltd |
Capacity & Worksurface
| Worksurface | 24.7 x 7.4 in (62.7 x 18.9 cm), removable |
| Screen Fit | Fits most 24–27 in screens, with a black backing for a seamless background |
| Monitor Pivot Capacity | 7–12.5 lb (3.2–5.7 kg) |
| Keyboard Tray Capacity | 0.5–3 lb (0.2–1.4 kg) |
| Mini PC Enclosure Capacity | 3–8 lb (1.4–3.6 kg) |
| Input Devices | Mouse and keyboard tray with removable worksurface |
Adjustment & Motion
| Height Adjustment (Lift) | 20 in (51 cm) — work sitting or standing |
| Profile from Wall | Low-profile design stays within 4 in (10.2 cm) of the wall |
| Tilt / Pan / Rotation | Not published by Ergotron — see specification note |
Design, Security & Durability
| Security | 10-digit lock code keeps patient data and technology secure |
| Cable Management | Integrated — keeps cords organised and easy to clean |
| Accessory Mounting | T-slot for accessories such as a proximity reader or printer |
| Scanner Access | Provides easy access to a scanner for medication delivery |
| Front Panel Options | Interchangeable woodgrain laminate fronts available (98-419) |
| Product Weight | 73.8 lb (33.5 kg) |
| Shipping Weight | 77.2 lb (35 kg) |
| Shipping Dimensions | 45.3 x 37.5 x 8.2 in (115.1 x 95.3 x 20.8 cm) |
Specification note: Ergotron does not publish a VESA pattern for the CareFit Enclosure's integrated monitor pivot, nor tilt, pan or rotation degrees, nor the enclosure's internal cavity dimensions, nor its assembled open and closed dimensions (only shipping-carton dimensions are published), nor an itemised box-contents list. Those are omitted here rather than estimated. Ergotron makes no published antimicrobial or infection-control material claim for this product — its only stated cleanability claim concerns the cable management keeping cords easy to clean. Contact SourceIT if any of these figures are decisive for your specification and we will confirm them with Ergotron.
Compatibility & Fit
Display fit. Ergotron states the enclosure fits most 24–27 in screens, mounted against a black backing so the display reads as part of the unit. The integrated monitor pivot is rated 7–12.5 lb (3.2–5.7 kg) — a genuine window rather than a simple maximum, so confirm your monitor's weight falls inside it. Ergotron does not publish the pivot's VESA pattern; contact SourceIT with your monitor model and we will confirm compatibility before you order.
Computing device fit. The mini PC enclosure is rated 3–8 lb (1.4–3.6 kg). Ergotron's own wording is “mini PC”; thin clients and small-form-factor PCs within that weight band are the intended occupants. Because Ergotron does not publish the internal cavity dimensions, check physical size with SourceIT if your device is unusually tall or deep.
Input devices and peripherals. The keyboard tray is rated 0.5–3 lb (0.2–1.4 kg) and the removable worksurface measures 24.7 x 7.4 in (62.7 x 18.9 cm). A T-slot accepts accessories such as a proximity reader or a printer, and the design gives easy access to a scanner for medication delivery. Dedicated horizontal and vertical scanner brackets are available separately in matching finishes.
Mounting. This is a wall-mounted unit weighing 73.8 lb (33.5 kg) before any equipment is fitted, and it carries a moving 20-inch lift. It requires structural wall support — Ergotron does not publish a substrate specification for this part, so SourceIT strongly recommends a site survey before ordering. It is not a desk-clamp, grommet, pole or mobile-base product.
Choosing between finishes. The enclosure is available in snow white (61-367-030, this listing) and matte black (61-367-060). The two are mechanically identical and share this datasheet; only the finish differs. Interchangeable woodgrain laminate fronts are available separately if you need the unit to blend with a specific interior scheme.
Package Contents & CareFit Ordering Information
In the Box
- CareFit Enclosure, snow white (61-367-030)
- Integrated monitor pivot, keyboard tray and removable worksurface
- Integrated cable management
- Installation hardware and documentation
CareFit Enclosure Finishes
| CareFit Enclosure, Snow White — 61-367-030 (this listing) | Snow white |
| CareFit Enclosure, Matte Black — 61-367-060 | Matte black |
CareFit Enclosure Accessories at SourceIT
| Horizontal Scanner Bracket, Snow White — 98-424-030 | Scanner mounting |
| Horizontal Scanner Bracket, Matte Black — 98-424-060 | Scanner mounting |
| Vertical Scanner Bracket, Snow White — 98-425-030 | Scanner mounting |
| Vertical Scanner Bracket, Matte Black — 98-425-060 | Scanner mounting |
Datasheet & Downloads
- Ergotron CareFit Enclosure product page (61-367)
- Official Ergotron CareFit Enclosure datasheet — imperial and metric (PDF)
- Official Ergotron CareFit Enclosure datasheet — metric (PDF)
Ergotron publishes no installation manual or dimensional drawing for the 61-367 series that SourceIT was able to verify. The two datasheets above are the official specification sources. The box-contents list above reflects the product's documented configuration rather than a published Ergotron packing list.
Frequently Asked Questions — Ergotron CareFit Enclosure
Is this just a cabinet, or does it actually adjust?
It genuinely adjusts. Ergotron's datasheet specifies 20 in (51 cm) of lift, explicitly so clinicians can work sitting or standing. The word “enclosure” describes its fold-away, lockable form factor — it is a height-adjustable wall workstation that closes and locks, not a passive equipment box.
What is the difference between the white and the black version?
Finish only. 61-367-030 is snow white and 61-367-060 is matte black. They are mechanically identical and share the same Ergotron datasheet. Interchangeable woodgrain laminate fronts (98-419) are available separately in six finishes if you need the unit to match a particular interior.
What size monitor does it take?
Ergotron states it fits most 24–27 in screens, with the monitor pivot rated for 7–12.5 lb (3.2–5.7 kg). Check your monitor's weight against that window — both the lower and upper figures matter on a counterbalanced pivot. Ergotron does not publish the VESA pattern, so contact SourceIT with your monitor model and we will confirm fit.
Can it hold a PC as well as the screen and keyboard?
Yes. There is a dedicated mini PC enclosure rated 3–8 lb (1.4–3.6 kg), alongside the monitor pivot (7–12.5 lb) and the keyboard tray (0.5–3 lb). The removable worksurface measures 24.7 x 7.4 in (62.7 x 18.9 cm). Ergotron does not publish the internal cavity dimensions, so check physical size with SourceIT if your device is unusually large.
How is patient data kept secure?
The enclosure closes and locks with a 10-digit lock code, which Ergotron states keeps patient data and technology secure. In a shared ward bay or a public-facing clinic corridor, that is the practical difference between a workstation you can leave unattended and one you cannot.
Can I add a barcode scanner or a proximity reader?
Yes. The enclosure has a T-slot for accessories such as a proximity reader or printer, and Ergotron notes it gives easy access to a scanner for medication delivery. SourceIT stocks the matching horizontal and vertical scanner brackets in snow white, and in matte black to suit the black enclosure.
How does this compare with a StyleView medical cart?
Different deployment models. The CareFit Enclosure is fixed to the wall, folds away and locks — ideal where each bay or room has its own workstation and floor space is scarce. A StyleView cart is mobile and travels with the clinician. If you are equipping carts rather than rooms, look at the SV Height-Adjustable Keyboard Arm (97-827) and the StyleView range, or ask SourceIT for a comparison against your ward layout.
Does the CareFit Enclosure come with a Singapore warranty?
Yes. Every Ergotron CareFit Enclosure sold by SourceIT comes with local Singapore warranty and a GST invoice; Ergotron backs the CareFit Enclosure with a 5-year manufacturer warranty.
