Dell Pro P 24 P2426E 24" 16:10 USB-C Hub Monitor
PRODUCT DESCRIPTION
Dell Pro P 24 16:10 USB-C Hub Monitor P2426E (210-BVPW) - 3 Years Local Warranty
16:10 Space, One-Cable Desk
A 24.1-inch WUXGA 16:10 IPS screen with a USB-C hub that delivers video, data, Gigabit Ethernet and up to 100 W of laptop charging over one cable.
Clear and Comfortable
100 Hz refresh, 300 nits, 99% sRGB and 99% BT.709, 1,500:1 contrast, flicker-free with TÜV Eye Comfort 4-Star.
Ready for Multi-Monitor
HDMI and DisplayPort 1.4 inputs, DisplayPort daisy chain, a 15 W front USB-C port and a stand with 150 mm height, tilt, swivel and pivot.
Rolling out monitors across an office? Email sales@sourceit.com.sg for volume pricing and delivery lead time.
Dell P2426E Datasheet — Technical Specifications
General
| Product Name | Dell Pro P 24 16:10 USB-C Hub Monitor - P2426E |
| Model | P2426E |
| Dell SKU | 210-BVPW |
| Local Warranty (Singapore) | 3 Year Limited Hardware Warranty with 3-Year Advanced Exchange Service and Premium Panel Exchange (Dell), supplied by SourceIT with a GST invoice |
| Product Line | Pro P |
Display
| Viewable Screen Size | 61.2 cm (24.1") |
| Screen Mode | WUXGA |
| Panel Technology | In-plane Switching (IPS) Technology |
| Maximum Resolution | 1920 x 1200 |
| Standard Refresh Rate | 100 Hz |
| Aspect Ratio | 16:10 |
| Colour Supported | 16.7 Million Colours |
| Colour Depth | 8-bit (6-bit+FRC) |
| Brightness | 300 cd/m² |
| Native Contrast Ratio | 1,500:1 |
| Colour Gamut | 99% BT.709 (CIE 1931) / 99% sRGB (CIE 1931) |
| Response Time | 5 ms GTG (Fast) / 8 ms GTG |
| Horizontal Viewing Angle | 178° |
| Vertical Viewing Angle | 178° |
| Pixel Pitch | 0.27 mm x 0.27 mm |
| Pixel Per Inch (PPI) | 94 |
| Glass Hardness | 3H |
| Flicker Free | Yes |
Connectivity
| Number of HDMI Inputs | 1 |
| Total Number of HDMI Ports | 1 |
| Number of HDMI 2.1 (HDCP 1.4) | 1 |
| Number of DisplayPorts | 2 |
| Number of DisplayPort 1.4 (HDCP 1.4) | 1 |
| Number of USB Ports | 5 |
| Total Number of USB Type-C Ports | 2 |
| USB Type-C (Power Delivery) Upstream | 100 W |
| USB Type-C (Power Delivery) Downstream | 15 W |
| USB Type-C Upstream Data Rate (Rear) | 5 GB/s |
| USB Type-C Downstream Data Rate (Front) | 640 MB/s |
| USB Type-C Power Delivery Downstream (Front) | 15 W |
| USB Type-A Downstream Data Rate (Front) | 640 MB/s |
| USB Type-A Downstream Data Rate (Rear) | 640 MB/s |
| USB Type-B Upstream Data Rate (Rear) | 640 MB/s |
| Network (RJ-45) | Yes (1x Gigabit Ethernet) |
| Daisy Chain Port Type | DisplayPort |
| Built-in Devices | USB Hub |
Audio & Camera
| Speakers | No |
| Webcam | No |
Ergonomics
| Stand Adjustments | Height, Pivot, Swivel, Tilt |
| Maximum Adjustable Height | 150 mm |
| Tilt Angle | -5° to 21° |
| Swivel Angle | -45° to 45° |
| Pivot Angle | +/-90° |
| VESA Mount Standard | 100 x 100 |
Power
| Input Voltage Range/Current Details | 100 VAC to 240 VAC/50 Hz or 60 Hz ± 3 Hz/2.5 A |
| Operating Power Consumption | 15 W |
| Maximum Power Consumption | 205 W |
| Standby Power Consumption | 300 mW |
| Off-Mode Power Consumption | 300 mW |
Physical
| Height with Stand (Extended) | 511.20 mm (20.13 in.) |
| Height with Stand (Compressed) | 364 mm (14.33 in.) |
| Width with Stand | 531.80 mm (20.94 in.) |
| Depth with Stand | 181.75 mm (7.16 in.) |
| Monitor Height | 343.70 mm (13.53 in.) |
| Monitor Depth | 50.03 mm (1.97 in.) |
| Stand Height (Extended) | 410.80 mm (16.17 in.) |
| Stand Height (Compressed) | 364.00 mm (14.33 in.) |
| Stand Width | 249.80 mm (9.83 in.) |
| Stand Depth | 181.75 mm (7.16 in.) |
| Bezel Width (Top) | 6.70 mm |
| Bezel Width (Bottom) | 13 mm |
| Bezel Width (Left) | 6.70 mm |
| Bezel Width (Right) | 6.70 mm |
| Weight (Approximate) | 3.45 kg |
| Weight with Stand & Cables | 5.18 kg (11.41 lb) |
| Weight (with Packaging) with Stand | 7.03 kg |
Environmental & Certifications
| Energy Efficiency | ENERGY STAR 8.0 |
| Environmental Certification | China CEC, EPEAT Climate+, EPEAT Gold, TCO Certified 10.0, TCO Certified Edge |
| Environmental Compliance | China RoHS, EAEU RoHS, REACH, RoHS, WEEE |
| Energy Compliance | ErP Lot 5, Korea MEPS |
| Eye Comfort Certification | Yes |
| Eye Comfort Rating | 4 Star |
| Certifications & Standards | Arsenic-Free glass and Mercury-Free (panel only), BFR/PVC free (excluding external cables), California CEC, GS Mark, NFPA 99 leakage current |
| Operating Temperature Range | 0°C to 40°C |
| Non-operating Temperature Range | -20°C to 60°C |
| Operating Humidity Range | 10% to 80% (Non-condensing) |
| Non-operating Humidity Range | 5% to 90% (Non-condensing) |
| Maximum Operating Altitude | 5 km |
Software & Management
| Platform Supported | Mac, Windows |
| Dell Display and Peripheral Manager Compatibility | Yes |
| Remote Asset Management | Dell Display and Peripheral Manager (DDPM) |
Compatibility & Software Support
PC Connection
Connect a USB-C laptop for video, USB data, Ethernet and up to 100 W charging over one cable (USB-C to USB-C cable included). HDMI and DisplayPort 1.4 inputs are available for desktops.
Daisy Chain
DisplayPort daisy chain is supported for a second compatible monitor.
Management
Dell Display and Peripheral Manager (DDPM) with remote asset management. Mac and Windows supported.
Mounting
VESA 100 x 100 mm for monitor arms and wall brackets.
Package Contents & Dell Pro P 24 & 27 Monitors Ordering Information
In the Box
Monitor, Stand, Power cable, 1x USB Type-C to Type-C 5Gbps 100W cable (1.80 m), QR card, Safety, Environmental, and Regulatory Information.
Dell Pro P 24 & 27 Monitors
| Model | Key feature |
| P2226H | 22" FHD 100 Hz |
| P2426H | 24" FHD 120 Hz |
| P2426 | 24" WUXGA 16:10, 100 Hz |
| P2426E (this listing) | 24" WUXGA 16:10, USB-C 100 W, RJ45 |
| P2426HE | 24" FHD 120 Hz, USB-C 100 W, RJ45 |
| P2426HEB | 24" FHD 120 Hz, 4MP camera, mic, 2 x 5 W speakers |
| P2426HEV | 24" FHD 120 Hz, 4MP camera |
| P2726HE | 27" FHD USB-C hub |
| P2726DEB | 27" QHD 100 Hz, 4MP camera, mic, 2 x 5 W speakers |
| P2726DEV | 27" QHD 100 Hz, 4MP camera |
Datasheet & Downloads
| Dell monitors brochure (PDF) | Dell monitors family brochure on delltechnologies.com |
| Manuals & drivers | P2426E manuals and documents on Dell Support |
| Dell product page | P2426E on dell.com Singapore |
Need a PDF sent directly? Email sales@sourceit.com.sg quoting P2426E.
Frequently Asked Questions — Dell P2426E
How much power does USB-C deliver?
Up to 100 W through the USB-C upstream port, plus 15 W from the front USB-C port.
Does it have Ethernet?
Yes, one Gigabit Ethernet (RJ-45) port.
What resolution and refresh rate?
1920 x 1200 (16:10) at 100 Hz.
Does it have speakers or a webcam?
No. For a built-in 4MP camera, see the Dell P2426HEV or P2426HEB.
What warranty do I get?
3 Year Limited Hardware Warranty with 3-Year Advanced Exchange Service and Premium Panel Exchange (Dell), supplied locally by SourceIT with a GST invoice.
