Dell Pro 14 Plus PB14250 Core Ultra 7 255U 32GB 512GB Laptop
PRODUCT DESCRIPTION
Dell Pro 14 Plus Laptop PB14250 Intel Core Ultra 7 255U / 32GB / 512GB SSD (210-BPDR / 6656569) - 3 Years Local Warranty
Intel Core Ultra with Built-in NPU
This Dell Pro 14 Plus PB14250 runs an Intel Core Ultra 7 255U processor (12 cores, up to 5.2 GHz, with a 12 TOPS NPU) for on-device AI features, paired with 32GB of DDR5 memory (up to 5600 MT/s) and a 512GB SSD on a 14-inch 16:10 display.
Connected for Hybrid Work
Two Thunderbolt 4 ports, two 5Gbps USB-A ports (one with PowerShare), HDMI 2.1 and a built-in 1Gbps RJ45 Ethernet port cover docks, displays and peripherals without dongles. Both Thunderbolt ports support Power Delivery for charging and docking.
Serviceable and Secure
Two DDR5 SO-DIMM slots (up to 64GB) and an M.2 PCIe Gen 4 SSD slot keep the PB14250 upgradeable, while a discrete TPM 2.0 and a camera privacy shutter meet Dell's commercial security baseline. This Core Ultra 7 255U build does not include Intel vPro management.
Buying for an office roll-out? Email sales@sourceit.com.sg for volume pricing and delivery lead time.
Dell PB14250 Datasheet — Technical Specifications
Configuration
| Product Name | Dell Pro 14 Plus Laptop PB14250 |
| SourceIT SKU | 210-BPDR / 6656569 |
| Processor | Intel Core Ultra 7 255U |
| Memory | 32GB DDR5, up to 5600 MT/s |
| Storage | 512GB SSD |
| Display, camera, wireless, battery, keyboard, OS | Per the supplied distributor SKU - confirm with sales before ordering |
| Local Warranty (Singapore) | 3 Years (distributor configuration), supplied by SourceIT with a GST invoice |
Processor & Graphics
| Processor | Intel Core Ultra 7 255U: 12 cores, up to 5.2 GHz; 12 TOPS NPU |
| Graphics | Integrated Intel graphics |
Memory & Storage
| Memory Slots | 2 x DDR5 SO-DIMM, up to 5600 MT/s, up to 64GB (2 x 32GB) |
| Storage Slot | 1 x M.2 2230/2280 PCIe Gen 4 NVMe SSD slot |
Display
| Size / Aspect | 14-inch, 16:10 |
| Panel | Per the supplied distributor SKU - confirm with sales before ordering |
Ports & Slots
| Thunderbolt | 2 x Thunderbolt 4 (40Gbps) with DisplayPort Alt Mode / USB Type-C / USB4 / Power Delivery |
| USB-A | 1 x USB 3.2 Gen 1 (5Gbps) with PowerShare; 1 x USB 3.2 Gen 1 (5Gbps) |
| Video | 1 x HDMI 2.1 (TMDS) |
| Ethernet | 1 x RJ45 (1Gbps) on Core Ultra 200U models |
| Audio | 1 x global headset jack |
| Other | Wedge-shaped lock slot; smart card reader and nano-SIM slot are factory options |
Audio
| Speakers | 2 speakers, 2 W x 2 average (2.5 W x 2 peak) |
| Microphones | Dual-array microphones |
Power
| Battery | 3-cell, ExpressCharge and ExpressCharge Boost capable (capacity per supplied SKU) |
| Power Adapter | USB Type-C AC adapter |
Security
| TPM | Discrete TPM 2.0, FIPS 140-2 certified |
| Other | Camera privacy shutter; wedge-shaped lock slot; fingerprint reader in power button with ControlVault 3+ (option) |
Physical
| Width x Depth | 313.50 x 224 mm |
| Height | 19.50 mm (front) – 21.20 mm (max) |
| Material | Aluminium chassis |
Compatibility & Software Support
Operating System
Dell offers this platform with Windows 11 Pro; the installed OS edition depends on the supplied SKU - confirm with sales.
Docking & Displays
The two Thunderbolt 4 ports support DisplayPort and Power Delivery, so the laptop works with Thunderbolt and USB-C docks and USB-C monitors such as the Dell Pro USB-C hub monitors, and charges through either port. HDMI 2.1 connects a projector or monitor directly.
Typical Use
Corporate fleets and hybrid workers who want a 14-inch Dell Pro Plus with a built-in Ethernet port and two SO-DIMM slots.
Package Contents & Dell Pro 14 Plus (Core Ultra 200U) Ordering Information
In the Box
Dell Pro 14 Plus PB14250 laptop and USB-C power adapter.
Dell Pro 14 Plus (Core Ultra 200U) Configurations at SourceIT
| Processor | Memory / SSD |
| Core Ultra 5 235U vPro | 16GB / 512GB (Wi-Fi 7) |
| Core Ultra 5 235U vPro | 16GB / 512GB |
| Core Ultra 5 235U vPro | 32GB / 512GB |
| Core Ultra 7 255U | 16GB / 512GB |
| Core Ultra 7 255U (this listing) | 32GB / 512GB |
| Core Ultra 7 255U | 32GB / 1TB |
Datasheet & Downloads
| Product brochure | Dell Pro 13 / 14 / 16 Plus laptop product brochure (PDF) |
| Manuals & drivers | Dell Pro 14 Plus PB14250 manuals on Dell Support |
| Dell product page | Dell Pro 14 Plus on dell.com Singapore |
Need a PDF sent directly? Email sales@sourceit.com.sg quoting PB14250.
Frequently Asked Questions — Dell PB14250
Can the memory be upgraded?
Yes. The PB14250 has two DDR5 SO-DIMM slots and supports up to 64GB.
Does it have an Ethernet port?
Yes. Dell fits a built-in RJ45 port (1Gbps) on Core Ultra 200U models of the PB14250.
Can it charge over USB-C?
Yes. Both Thunderbolt 4 ports support Power Delivery, and a USB Type-C power adapter is included.
Does it support Intel vPro?
No. The Core Ultra 7 255U in this configuration is not a vPro processor. Choose a Core Ultra 5 235U vPro configuration if you need vPro remote management.
Which display, camera and Wi-Fi does this configuration have?
These depend on the supplied distributor SKU. Email sales@sourceit.com.sg quoting 210-BPDR / 6656569 and we will confirm before you order.
What warranty do I get?
3 years per the distributor configuration, supplied locally by SourceIT with a GST invoice.
