Dell Latitude 7420 14" 11th Gen Intel Core Laptop
PRODUCT DESCRIPTION
Dell Latitude 7420 14-inch Laptop 11th Gen Intel Core i5 / i7 / 8GB–16GB / 256GB–1TB SSD / Windows (s001l742014sg / AL7420i516G512ssd / 210-AYBB-I7-512 / 210-AYBB-I7-1TB) - 3 Year Local Onsite Warranty
11th Gen Intel Core with Iris Xe Graphics
Four configurations on the 14-inch Latitude 7420 clamshell: Core i5 with 8GB / 256GB SSD or 16GB / 512GB SSD, and Core i7 with 16GB and a 512GB or 1TB PCIe NVMe SSD, all with dual-channel LPDDR4x memory and integrated Intel Iris Xe Graphics.
14-inch Business Laptop from 1.22 kg
Dell built the Latitude 7420 in carbon fibre (from 1.22 kg) or aluminium (from 1.31 kg), 321 x 209 mm and under 19 mm thick, with a fingerprint reader in the power button and a 42 Wh or 63 Wh ExpressCharge-capable battery.
Thunderbolt 4, Wi-Fi 6 and HDMI
Two Thunderbolt 4 ports with DisplayPort and Power Delivery, a USB-A port with PowerShare, HDMI 2.0 and a microSD reader, plus Intel AX201 Wi-Fi 6 with Bluetooth 5.1.
Buying for a team or project? Email sales@sourceit.com.sg for volume pricing and delivery lead time.
Dell Latitude 7420 Datasheet — Technical Specifications
Configuration
| Product Name | Dell Latitude 7420 (14-inch laptop, clamshell) |
| Variant: s001l742014sg | Core i5 / 8GB / 256GB SSD |
| Variant: AL7420i516G512ssd | Core i5 / 16GB / 512GB SSD |
| Variant: 210-AYBB-I7-512 | Core i7 / 16GB / 512GB SSD |
| Variant: 210-AYBB-I7-1TB | Core i7 / 16GB / 1TB SSD |
| Processor | 11th Gen Intel Core i5 or i7 (exact model per supplied configuration — see Processor & Graphics) |
| Memory | 8GB or 16GB LPDDR4x, onboard (dual-channel) |
| Storage | 256GB, 512GB or 1TB PCIe NVMe SSD |
| Local Warranty (Singapore) | 3 Year Local Onsite Warranty |
Processor & Graphics
| Core i5 options (Dell) | Intel Core i5-1135G7: 4 cores / 8 threads, 8 MB cache, 2.4–4.2 GHz; Intel Core i5-1145G7 vPro: 4 cores / 8 threads, 8 MB cache, 2.6–4.4 GHz |
| Core i7 options (Dell) | Intel Core i7-1165G7: 4 cores / 8 threads, 12 MB cache, 2.8–4.7 GHz; Intel Core i7-1185G7 vPro: 4 cores / 8 threads, 12 MB cache, 3.0–4.8 GHz |
| Power | 28 W max, 13–15 W cTDP |
| Chipset | Intel Tiger Lake U PCH |
| Graphics | Integrated Intel Iris Xe Graphics (shared system memory) |
Memory & Storage
| Memory | Dual-channel LPDDR4x (3733 MHz for 8GB / 16GB), integrated on the system board (not upgradeable); platform max 32GB at time of order |
| Storage | One M.2 2230/2280 PCIe Gen 3 x4 NVMe SSD slot (Dell offered up to 1TB) |
| Card Reader | microSD card reader (microSD / SDHC / SDXC) |
Display
| Panel options (Dell) | 14" FHD (1920 x 1080) WVA non-touch, anti-glare, 250 or 400 nits; 14" FHD WVA touch, 300 nits; 14" FHD WVA SafeScreen touch, 300 nits; 14" UHD (3840 x 2160) WVA non-touch, anti-glare, 400 nits |
| Refresh Rate | 60 Hz |
| Supplied Panel | Per supplied configuration — confirm with sales |
Ports
| Thunderbolt / USB-C | 2 x Thunderbolt 4 with DisplayPort Alt Mode, USB4 and Power Delivery |
| USB-A | 1 x USB 3.2 Gen 1 with PowerShare |
| Video | 1 x HDMI 2.0 |
| Network | No RJ45 Ethernet port |
| Other | Universal audio jack, microSD card slot, USB Type-C power input, wedge-shaped lock slot |
Wireless, Audio & Camera
| Wireless | Intel AX201 Wi-Fi 6 (802.11ax) with Bluetooth 5.1 |
| Mobile Broadband | Optional 4G LTE (Qualcomm Snapdragon X20, DW5821e / DW5829e) on configurations ordered with WWAN |
| Camera | HD RGB or HD / FHD RGB/IR webcam options, per configuration |
| Audio | Two speakers (2 W average / 2.5 W peak), Realtek ALC3281-CG audio, dual-array microphones |
Power
| Battery | 3-cell 42 Wh or 4-cell 63 Wh, ExpressCharge / ExpressCharge Boost capable |
| Charging | 65 W or 90 W USB Type-C adapter |
Security
| Hardware | Fingerprint reader in power button (capacitive, 500 dpi), wedge-shaped lock slot |
| Keyboard | Standard backlit or non-backlit, per configuration |
| Touchpad | 115 x 65 mm |
Physical
| Dimensions (W x D x H) | 321.35 x 208.69 x 16.90–18.00 mm (aluminium) / 17.27–18.88 mm (carbon fibre) |
| Weight | From 1.22 kg (carbon fibre) / 1.31 kg (aluminium) |
| Operating temperature | 0°C to 35°C |
Compatibility & Software Support
Operating System
Dell supports Windows 11 Pro, Windows 10 Pro and Ubuntu 20.04 LTS on the Latitude 7420; the supplied edition depends on the configuration ordered.
Docks & Displays
Two Thunderbolt 4 ports with DisplayPort and Power Delivery work with Dell Thunderbolt and USB-C docks; HDMI 2.0 adds another display. There is no built-in RJ45 port, so use a dock or USB-C adapter for wired Ethernet.
Upgrades
Memory is LPDDR4x soldered to the system board and cannot be upgraded, so choose the capacity you need at purchase. Storage uses a single M.2 2230/2280 PCIe NVMe slot (Dell offered up to 1TB).
Package Contents & Dell Latitude 7000 Series Ordering Information
In the Box
Dell Latitude 7420 laptop, USB-C AC adapter and documentation, per the supplied configuration.
Dell Latitude 7000 Series at SourceIT
| Model / Processor | Memory / SSD |
| Latitude 7420 11th Gen Core i5 / i7 (this listing) | 8GB / 256GB, 16GB / 512GB, 16GB / 1TB SSD |
| Latitude 7330 / 7430 | 12th Gen Core i5 / i7 — multiple options (successor generation) |
| Latitude 7340 | 13th Gen Core i5 / i7 — multiple options (13-inch) |
| Latitude 7440 | 13th Gen Core i5 / i7 — multiple options |
| Latitude 7440 Core i5-1335U | 8GB / 512GB SSD |
| Latitude 7440 Core i5-1335U | 16GB / 512GB SSD |
| Latitude 7440 Core i7-1355U | 16GB / 512GB SSD |
| Latitude 7440 Core i7-1355U | 16GB / 1TB SSD |
| Latitude 7450 Core Ultra 5 125U | 16GB / 512GB SSD |
| Latitude 7450 Core Ultra 7 165U | 16GB / 512GB SSD |
| Latitude 7450 Core Ultra 7 165U | 16GB / 1TB SSD |
Looking for the current generation? See the Dell Pro 14 Premium (PA14250) and Dell Pro 14 Plus (PB14250). Other configurations can be quoted on request — email sales@sourceit.com.sg.
Datasheet & Downloads
| Setup & specifications | Dell Latitude 7420 / 7420 2-in-1 Setup and Specifications |
| Processor options | Dell Latitude 7420 Setup and Specifications — Processor |
| Manuals & drivers | Dell Latitude 7420 on Dell Support Singapore |
Need a PDF sent directly? Email sales@sourceit.com.sg quoting Latitude 7420.
Frequently Asked Questions — Dell Latitude 7420
Which processor is in each variant?
The i5 variants use an 11th Gen Intel Core i5 (Dell offered the i5-1135G7 and i5-1145G7 vPro) and the i7 variants an 11th Gen Intel Core i7 (Dell offered the i7-1165G7 and i7-1185G7 vPro). Email sales for the exact model on a given unit.
Is this the 2-in-1 version?
No. This listing is the Latitude 7420 clamshell laptop. The 7420 2-in-1 is a separate convertible model with a 360-degree hinge and touch display.
Can I upgrade the memory?
No. The LPDDR4x memory is soldered to the system board and cannot be upgraded. The single M.2 SSD slot can be replaced with a larger drive.
Does it have an Ethernet port or SD card reader?
There is no RJ45 Ethernet port. There is a microSD card reader, two Thunderbolt 4 ports, one USB-A port and HDMI 2.0.
Is it still available?
No. The Latitude 7420 is no longer available for order. See the current Dell Pro 14 Premium (PA14250) or Dell Pro 14 Plus (PB14250) listings, or email sales for alternatives.
What warranty do I get?
3 Year Local Onsite Warranty, supplied locally by SourceIT with a GST invoice.
