Synology DS223 2-bay DiskStation

Synology DS223 2-bay DiskStation Quad Core , 1GB RAM , 1 x 1GbE RJ-45 , ing Btrfs and Snapshot Rep - 2 Years Local Warranty

Reliable 2-Bay NAS for Home and Business Storage

Synology DS223 is a versatile 2-bay NAS solution designed for centralized file storage, backup, and private cloud applications. It is suitable for home users, small offices, and teams looking for secure and efficient data management with Synology's powerful DSM operating system.

Efficient Quad-Core Performance for Daily Workloads

Powered by a quad-core processor with 1GB RAM, the DS223 delivers reliable performance for file sharing, synchronization, media streaming, and backup tasks. It supports smooth access for multiple users and connected devices, making it suitable for everyday storage operations.

Advanced Data Protection with Btrfs and Snapshot Replication

The DS223 supports the Btrfs file system and Snapshot Replication technology, enabling advanced data protection and recovery capabilities. Users can create point-in-time snapshots, restore files quickly, and protect important business or personal data from accidental deletion or ransomware attacks.

Centralized Backup and Private Cloud Features

Synology DSM provides powerful backup and synchronization tools for PCs, mobile devices, and cloud services. Users can securely access files remotely, share data across teams, and build a private cloud environment while maintaining full control over their information.

Technical Specifications

General
Brand: Synology
Model: DS223
Product Type: 2-Bay NAS (Network Attached Storage)
Deployment: Home, SOHO, SME storage and backup
Usage Mode: Centralized file storage, backup, synchronization, and sharing

Processor (CPU)
Processor Type: Quad-Core Processor
Processor Architecture: 64-bit
Hardware Engine: Hardware encryption supported

Memory (RAM)
Installed Memory: 1GB DDR4
Memory Configuration: Onboard memory
Upgradeable Memory: No

Storage & Drive Bays
Drive Bays: 2 × SATA drive bays
Drive Type Support:
• 3.5" SATA HDD
• 2.5" SATA SSD
RAID Support:
• Synology Hybrid RAID (SHR)
• RAID 0
• RAID 1
• JBOD
• Basic

File System Support
Internal Drives: Btrfs, EXT4
External Drives: EXT4, EXT3, FAT32, NTFS, exFAT, HFS+
Snapshot Replication: Supported via Btrfs

Network & Connectivity
LAN Port: 1 × 1GbE RJ-45 Ethernet
USB Ports: 3 × USB 3.2 Gen 1
Network Protocols: SMB, AFP, NFS, FTP, WebDAV, Rsync

Performance
Sequential Read Speed: Up to ~112 MB/s
Sequential Write Speed: Up to ~112 MB/s
Use Case: File sharing, backup, and synchronization

Software & Features
Operating System: Synology DiskStation Manager (DSM)
Backup Features: Hyper Backup, Active Backup Suite
Snapshot Replication: Supported
Cloud Sync: Google Drive, Dropbox, OneDrive support
Remote Access: QuickConnect and mobile app support
File Sharing: Multi-platform Windows / macOS / Linux support
User Management: Role-based access permissions

Security
Encryption: Shared folder encryption
Firewall: Built-in DSM firewall
Access Control: User and group permissions
Security Features: HTTPS, 2FA, automatic account protection

Power
Power Supply: External adapter
AC Input: 100V–240V AC
Energy Saving: HDD hibernation and scheduled power control

Cooling & Acoustics
Cooling Fan: 1 × 92 mm system fan
Noise Level: Approx. 18–20 dB(A)

Physical Specifications
Dimensions: ~165 × 108 × 232 mm
Weight: ~1.3 kg
Form Factor: Desktop NAS enclosure

Package Contents
Synology DS223 NAS unit
Power adapter
Power cable
RJ45 Ethernet cable
Quick installation guide

Key Features
2-bay NAS with RAID protection
Btrfs file system support
Snapshot Replication capability
Centralized backup and synchronization
Synology DSM operating system
1GbE network connectivity
Compact and energy-efficient design

Typical Use Cases
Centralized office file storage
PC and laptop backup server
Private cloud deployment
Department file sharing
SME backup and recovery
Document archive and collaboration storage
