MSI MAG 325QF E18V 31.5" WQHD 180Hz Rapid VA Gaming Monitor
PRODUCT DESCRIPTION
MSI MAG 325QF E18V 31.5" WQHD 180Hz Rapid VA Gaming Monitor
Key specifications: 31.5" · WQHD · Rapid VA · 180Hz · 1ms(MPRT) · 0.5ms(GtG) · AdaptiveSync · HDR Ready · 2x HDMI2.0b · DP1.4a
Smooth Rapidity and Accuracy
Equipped with a 180Hz refresh rate and 0.5ms (GtG, Min.) response time which has the benefit in fast moving game genres.
See Clearly, See Comfortably
Anti-Flicker and Less Blue Light technologies provide a very comfortable viewing experience by reducing flicker and blue light emission.
The Most Vivid Display
HDR Ready produces images with more detail, wider color range, and appearance closer to human eye perception versus traditional monitors.
Console Mode
Supports 1080p and 1440p at 60Hz and 120Hz, HDMI™ CEC, and VRR on PS5 and Xbox.
MSI MAG 325QF E18V Datasheet — Technical Specifications
General
| Product Name | MSI MAG 325QF E18V 31.5" WQHD 180Hz Rapid VA Gaming Monitor |
| Model | MAG 325QF E18V |
| MSI Part Number | 9S6-3DE11M-003 |
| EAN | 4711377347815 |
| Brand / Series | MSI MAG / MPG Gaming Monitors |
Display
| Panel Size | 31.5" |
| Active Display Area (mm) | 697.344 (H) x 392.256 (V) |
| Curvature | Flat |
| Panel Type | Rapid VA |
| Panel Resolution | 2560 x 1440 (WQHD) |
| Pixel Pitch (H x V) | 0.2724 (H) x 0.2724 (V) |
| Aspect Ratio | 16:9 |
| Brightness (nits) | SDR: 300 cd/m² |
| Contrast Ratio | 3500:1 |
| DCR | 100000000:1 |
| Signal Frequency | 71~266KHz (H) / 48~180Hz (V) |
| Activated Range | 48~180Hz |
| Refresh Rate | 180Hz |
| Response time | 0.5ms (GtG, Min.) |
| Dynamic Refresh Rate Technology | Adaptive-Sync |
| HDR Support | HDR Ready |
| Viewing Angle | 178° (H) / 178° (V) |
| Adobe RGB / DCI-P3 / sRGB | 85% / 84% / 109% (CIE1976 Standard) |
| Surface Treatment | Anti-glare |
| Display Colors | 1.07B, 10 bits (8 bits + FRC) |
Connectivity & Features
| Video ports | 2x HDMI™ 2.0b (WQHD@144Hz); 1x DisplayPort 1.4a (HBR3) |
| Audio ports | 1x Headphone-out |
| Console Mode | Supported Resolution & Refresh Rate: 1080p: 60Hz and 120Hz; 1440p: 60Hz and 120Hz; HDMI™ CEC: Supported; VRR: PS5 and Xbox Supported |
Ergonomics & Mounting
| Adjustment (Tilt) | -5°~20° |
| Kensington Lock | Yes |
| VESA Mounting | 100 x 100 mm |
Power
| Power Type | Internal Power Board |
| Power Input | 100~240V, 50/60Hz |
Dimensions & Weight
| Dimension with Stand (W x D x H) | 713.9 x 249.7 x 507.9 mm (28.1 x 9.8 x 19.9 inch) |
| Dimension without Stand (W x D x H) | 713.9 x 61.1 x 420.1 mm (28.1 x 2.4 x 16.5 inch) |
| Weight (NW / GW) | 5.4 kg (11.9 lbs) / 8.35 (18.4 lbs) |
| Carton Dimension (W X D X H) | 790 x 123 x 495 mm (31.1 x 4.8 x 19.4 inch) |
Certifications, Warranty & Accessories
| Accessories | 1x DP Cable (1.4a); 1x Power Cord (C13); 1x Quick Guide |
Specifications are as published by MSI and may change without notice — see the MSI product page for the latest details.
Compatibility & Connectivity
Video Inputs
2x HDMI™ 2.0b (WQHD@144Hz); 1x DisplayPort 1.4a (HBR3)
Audio
1x Headphone-out
Console Mode
Supported Resolution & Refresh Rate: 1080p: 60Hz and 120Hz; 1440p: 60Hz and 120Hz; HDMI™ CEC: Supported; VRR: PS5 and Xbox Supported
Mounting
VESA 100 x 100 mm — fits standard VESA monitor arms; check the arm's weight rating against the monitor weight in the datasheet.
Package Contents & MSI MAG / MPG Gaming Monitors Ordering Information
In the Box
1x DP Cable (1.4a); 1x Power Cord (C13); 1x Quick Guide
MSI MAG / MPG Gaming Monitors
| Model | Key feature |
| MAG401QR | 40" / UWQHD / IPS / 155Hz / 1ms(MPRT) |
| MAG 342CQRF E20 | 34" / UWQHD / Curved 1500R / Rapid VA / 200Hz |
| MAG 325QF E18V (this listing) | 31.5" / WQHD / Rapid VA / 180Hz / 1ms(MPRT) |
| MAG 321CQF E18 | 31.5" / WQHD / Curved 1500R / Rapid VA / 180Hz |
| MAG 322URDF E16 | 31.5" / Dual-Mode FHD-320Hz & UHD-160Hz / Rapid IPS / 1ms(MPRT) / 0.5ms(GtG) |
| MAG 321CUPDF | 31.5" / Dual-Mode FHD-320Hz & UHD-160Hz / Curved 1500R / Rapid VA / 1ms(MPRT) |
| MAG 271KPD7 | 27" / Dual-Mode WQHD-300Hz & 5K UHD-75Hz / Rapid IPS / 0.5ms(MPRT) / 0.5ms(GtG) |
| MPG 274URDFW E16M | 27" / Dual-Mode FHD-320Hz & UHD-160Hz / Rapid IPS / Mini-LED / 1ms(MPRT) |
| MAG 274QPF X30MV | 27" / WQHD / Rapid VA / 300Hz / Mini-LED |
| MAG 275UPD E14 | 27" / Dual-Mode FHD-288Hz & UHD-144Hz / Rapid IPS / 1ms(MPRT) / 0.5ms(GtG) |
| MAG 274QRFW X32 | 27" / WQHD / Rapid IPS / 320Hz / 1ms(MPRT) |
| MAG 274QPF E20 | 27" / WQHD / Rapid IPS / 200Hz / 1ms(MPRT) |
| MAG 274QF X24 | 27" / WQHD / Rapid IPS / 240Hz / 1ms(MPRT) |
| MAG 274F | 27" / FHD / Rapid IPS / 200Hz / 1ms(MPRT) |
| MAG 255F X24 | 24.5" / FHD / Rapid IPS / 240Hz / 1ms(MPRT) |
Datasheet & Downloads
| MSI product page | MAG 325QF E18V on msi.com |
| Specifications | MAG 325QF E18V specifications |
| Drivers, manuals & firmware | MAG 325QF E18V support |
Frequently Asked Questions — MSI MAG 325QF E18V
What resolution and refresh rate does the MAG 325QF E18V support?
Resolution: 2560 x 1440 (WQHD). Refresh rate: 180Hz (per MSI specification).
Can it charge a laptop?
No, this model has no USB-C power delivery; use your laptop's own charger.
Is the stand height-adjustable?
No, the stand tilts only (-5°~20°). Use the VESA mount with a monitor arm for height adjustment.
Does it have built-in speakers?
No, connect headphones or external speakers.
What warranty do I get?
Singapore local MSI warranty through the authorised distributor. Supplied by SourceIT with a GST invoice.
