MSI MAG 271KPD7 27" 5K 75Hz / WQHD 300Hz Dual-Mode Rapid IPS Gaming Monitor
PRODUCT DESCRIPTION
MSI MAG 271KPD7 27" 5K 75Hz / WQHD 300Hz Dual-Mode Rapid IPS Gaming Monitor
Key specifications: 27" · Dual-Mode WQHD-300Hz & 5K UHD-75Hz · Rapid IPS · 0.5ms(MPRT) · 0.5ms(GtG) · G-SYNC Compatible · FreeSync Premium · HDR400 · Adjustable Stand · Pivot 90° · 2x HDMI2.1 · DP1.4a · USB-C PD15W · USB Hub · KVM
Dual Mode Ultra
Swap instantly from 5K (5120 x 2880) 75Hz for rich details in immersive journeys, to WQHD (2560 x 1440) 300Hz for peak responsiveness in intense play.
Native 5K Display
Native 5K resolution delivers 218 pixels per inch for retina-level visual quality.
Vivid Color Performance
DCI-P3 95% colour coverage and VESA DisplayHDR 400 deliver rich, immersive content.
Enhanced Motion Clarity
Super Low Motion Blur Sync (SLMB Sync) effectively eliminates ghosting and motion blur.
Gaming Intelligence App
The MSI Gaming Intelligence app lets users customise display settings and application-specific profiles without manual OSD adjustments.
MSI MAG 271KPD7 Datasheet — Technical Specifications
General
| Product Name | MSI MAG 271KPD7 27" 5K 75Hz / WQHD 300Hz Dual-Mode Rapid IPS Gaming Monitor |
| Model | MAG 271KPD7 |
| MSI Part Number | 9S6-3CF69T-015 |
| EAN | 4711377426060 |
| Brand / Series | MSI MAG / MPG Gaming Monitors |
Display
| Panel Size | 26.9" |
| Active Display Area (mm) | 595.968 (H) x 335.232 (V) |
| Curvature | Flat |
| Panel Type | Rapid IPS |
| Panel Resolution | Normal: 5120 x 2880 (5K); Dual Mode: 2560 x 1440 (WQHD) |
| Pixel Pitch (H x V) | 0.1164 (H) x 0.1164 (V) |
| Aspect Ratio | 16:9 |
| Brightness (nits) | SDR: 350; HDR: 500 |
| Contrast Ratio | 1500:1 |
| DCR | 100000000:1 |
| Signal Frequency | Normal: 136.54~227.29KHz (H) / 48~75Hz (V); Dual Mode: 74.08~476.6KHz (H) / 48~300Hz (V) |
| Activated Range | Normal: 48~75Hz; Dual Mode: 48~300Hz |
| Refresh Rate | Normal: 75Hz; Dual Mode: 300Hz |
| Response time | 0.5ms (GtG, Min.) |
| Dynamic Refresh Rate Technology | AMD FreeSync™ Premium (WQHD 300Hz); G-SYNC™ Compatible |
| HDR Support | VESA DisplayHDR 400 |
| Viewing Angle | 178° (H) / 178° (V) |
| Adobe RGB / DCI-P3 / sRGB | 92.6% / 95% / 122.9% (CIE1976 Standard) |
| Surface Treatment | Anti-glare |
| Display Colors | 1.07B, 10 bits (8 bits + FRC) |
| Frameless Design | Yes |
Connectivity & Features
| Video ports | 2x HDMI™ 2.1 (5K@75Hz); 1x DisplayPort 1.4a (HBR3); 1x Type-C (DP alt.) w/ 15W Power Delivery |
| USB ports | 2x USB 5Gbps Type-A; 1x USB 5Gbps Type-B |
| Audio ports | 1x Headphone-out |
| Console Mode | Supported Resolution & Refresh Rate: 1080p: 60Hz and 120Hz; 1440p: 60Hz and 120Hz; 2160p: 60Hz and 120Hz; HDMI™ CEC: Supported; VRR: PS5 and Xbox Supported |
| PIP / PBP Function | Yes |
| Note | HDMI™: Normal (5K): 5120 x 2880 (Up to 75Hz), Dual Mode (WQHD): 2560 x 1440 (Up to 300Hz); DisplayPort: Normal (5K): 5120 x 2880 (Up to 75Hz), Dual Mode (WQHD): 2560 x 1440 (Up to 300Hz); Type-C: Normal (5K): 5120 x 2880 (Up to 75Hz), Dual Mode (WQHD): 2560 x 1440 (Up to 300Hz); Support: HDMI™ CEC, PIP/PBP, KVM |
Ergonomics & Mounting
| Adjustment (Tilt) | -5° ~ 20° |
| Adjustment (Swivel) | -30° ~ 30° |
| Adjustment (Pivot) | -90° ~ 90° |
| Adjustment (Height) | 0 ~ 130 mm |
| Kensington Lock | Yes |
| VESA Mounting | 100 x 100 mm |
Power
| Power Type | Internal Power Board |
| Power Input | 100~240V, 50/60Hz |
Dimensions & Weight
| Dimension with Stand (W x D x H) | 613.8 x 227.9 x 406.3 mm (24.17 x 8.97 x 16.00 inch) |
| Dimension without Stand (W x D x H) | 613.8 x 57.1 x 365.6 mm (24.17 x 2.45 x 14.39 inch) |
| Weight Without Stand | 4.2 kg (9.26 lbs) |
| Weight (NW / GW) | 6.7 kg (14.77 lbs) / 9.8 kg (21.61 lbs) |
| Carton Dimension (W X D X H) | 840 x 148 x 475 mm (33.07 x 5.83 x 18.70 inch) |
Certifications, Warranty & Accessories
| Accessories | 1x DisplayPort Cable (1.4a); 1x USB Type-B to A Cable; 1x Power Cord (C13); 1x Quick Guide; 4x Stand Screw |
Specifications are as published by MSI and may change without notice — see the MSI product page for the latest details.
Compatibility & Connectivity
Video Inputs
2x HDMI™ 2.1 (5K@75Hz); 1x DisplayPort 1.4a (HBR3); 1x Type-C (DP alt.) w/ 15W Power Delivery
USB
2x USB 5Gbps Type-A; 1x USB 5Gbps Type-B
Audio
1x Headphone-out
Supported Modes (MSI note)
HDMI™: Normal (5K): 5120 x 2880 (Up to 75Hz), Dual Mode (WQHD): 2560 x 1440 (Up to 300Hz); DisplayPort: Normal (5K): 5120 x 2880 (Up to 75Hz), Dual Mode (WQHD): 2560 x 1440 (Up to 300Hz); Type-C: Normal (5K): 5120 x 2880 (Up to 75Hz), Dual Mode (WQHD): 2560 x 1440 (Up to 300Hz); Support: HDMI™ CEC, PIP/PBP, KVM
Console Mode
Supported Resolution & Refresh Rate: 1080p: 60Hz and 120Hz; 1440p: 60Hz and 120Hz; 2160p: 60Hz and 120Hz; HDMI™ CEC: Supported; VRR: PS5 and Xbox Supported
Mounting
VESA 100 x 100 mm — fits standard VESA monitor arms; check the arm's weight rating against the monitor weight in the datasheet.
Package Contents & MSI MAG / MPG Gaming Monitors Ordering Information
In the Box
1x DisplayPort Cable (1.4a), 1x USB Type-B to A Cable, 1x Power Cord (C13), 1x Quick Guide, 4x Stand Screw
MSI MAG / MPG Gaming Monitors
| Model | Key feature |
| MAG401QR | 40" / UWQHD / IPS / 155Hz / 1ms(MPRT) |
| MAG 342CQRF E20 | 34" / UWQHD / Curved 1500R / Rapid VA / 200Hz |
| MAG 325QF E18V | 31.5" / WQHD / Rapid VA / 180Hz / 1ms(MPRT) |
| MAG 321CQF E18 | 31.5" / WQHD / Curved 1500R / Rapid VA / 180Hz |
| MAG 322URDF E16 | 31.5" / Dual-Mode FHD-320Hz & UHD-160Hz / Rapid IPS / 1ms(MPRT) / 0.5ms(GtG) |
| MAG 321CUPDF | 31.5" / Dual-Mode FHD-320Hz & UHD-160Hz / Curved 1500R / Rapid VA / 1ms(MPRT) |
| MAG 271KPD7 (this listing) | 27" / Dual-Mode WQHD-300Hz & 5K UHD-75Hz / Rapid IPS / 0.5ms(MPRT) / 0.5ms(GtG) |
| MPG 274URDFW E16M | 27" / Dual-Mode FHD-320Hz & UHD-160Hz / Rapid IPS / Mini-LED / 1ms(MPRT) |
| MAG 274QPF X30MV | 27" / WQHD / Rapid VA / 300Hz / Mini-LED |
| MAG 275UPD E14 | 27" / Dual-Mode FHD-288Hz & UHD-144Hz / Rapid IPS / 1ms(MPRT) / 0.5ms(GtG) |
| MAG 274QRFW X32 | 27" / WQHD / Rapid IPS / 320Hz / 1ms(MPRT) |
| MAG 274QPF E20 | 27" / WQHD / Rapid IPS / 200Hz / 1ms(MPRT) |
| MAG 274QF X24 | 27" / WQHD / Rapid IPS / 240Hz / 1ms(MPRT) |
| MAG 274F | 27" / FHD / Rapid IPS / 200Hz / 1ms(MPRT) |
| MAG 255F X24 | 24.5" / FHD / Rapid IPS / 240Hz / 1ms(MPRT) |
Datasheet & Downloads
| MSI product page | MAG 271KPD7 on msi.com |
| Specifications | MAG 271KPD7 specifications |
| Drivers, manuals & firmware | MAG 271KPD7 support |
Frequently Asked Questions — MSI MAG 271KPD7
What resolution and refresh rate does the MAG 271KPD7 support?
Resolution: Normal: 5120 x 2880 (5K); Dual Mode: 2560 x 1440 (WQHD). Refresh rate: Normal: 75Hz; Dual Mode: 300Hz (per MSI specification).
Can it charge a laptop over USB-C?
The USB-C port supplies up to 15W, enough for phones and accessories but not to charge most laptops; keep using your laptop charger.
Is the stand height-adjustable?
Yes — height 0 ~ 130 mm, tilt -5° ~ 20°, swivel -30° ~ 30°, pivot -90° ~ 90°.
Does it have built-in speakers?
No, connect headphones or external speakers.
Does it support KVM?
Yes, the built-in KVM lets you control two connected computers with one keyboard and mouse.
What warranty do I get?
Singapore local MSI warranty through the authorised distributor. Supplied by SourceIT with a GST invoice.
