MAXHUB U4 Series U6540 65" 4K Interactive Flat Panel
PRODUCT DESCRIPTION
MAXHUB Education U4 Series U6540 65" 4K Google EDLA Interactive Flat Panel with 50MP Camera and 8-Mic Array (U6540) - 3 Years Local Warranty
65-inch 4K Interactive Display for the Classroom
The MAXHUB U4 Series U6540 is a 65" 4K (3840 x 2160) interactive flat panel built for teaching and hybrid lessons. It runs MAXHUB EDU OS V4 on Google EDLA-certified Android 15, with an octa-core processor, 6 TOPS NPU, 16GB RAM and 256GB storage (expandable via TF card up to 1TB), so Google Play, Google Drive, Google Meet and YouTube are available out of the box.
Built-in 50MP Camera and 8-Mic Array
A 50MP camera (115° diagonal field of view) with auto framing, speaker tracking and person counting, plus an 8-microphone array with a 180° pick-up angle and up to 12 m range, lets teachers run remote and hybrid classes without extra peripherals. Intelligent audio fence, AI spatial sound, AEC, ANC and AGC keep voices clear.
50-Point Touch and SkyWave 2.2 Sound
The zero-parallax 3 mm 9H tempered glass supports 50-point infrared touch with ±0.5 mm accuracy and ≤2.5 ms response, with direct annotation, palm rejection and sharp erase. The SkyWave 2.2-channel sound system (2 x 8 W + 2 x 18 W output) fills the classroom, and the DLED panel covers 98% sRGB with ΔE ≤ 1 colour accuracy and TÜV low blue light / flicker-free certification.
Connect Everything, Manage Centrally
Four HDMI inputs, DP in, two USB-C ports (front up to 65 W PD, rear up to 100 W PD), Wi-Fi 6 and Bluetooth 5.2 make it easy for teachers and students to connect. MAXHUB Connect handles wireless screen sharing, MAXHUB Class Pro provides the whiteboard, and MAXHUB Pivot manages a whole school fleet remotely. An OPS slot allows a Windows PC module to be added later.
Need help choosing? Email sales@sourceit.com.sg with your classroom size, platform and quantity and we will recommend the right configuration.
MAXHUB U6540 Datasheet — Technical Specifications
General
| Product Name | MAXHUB Interactive Flat Panel U4 Series U6540 |
| Part Number | U6540 |
| Series | MAXHUB U4 Series (Education) |
| Local Warranty (Singapore) | 3 years, supplied by SourceIT with a GST invoice |
Display
| Screen Size | 65" |
| Resolution | 3840 x 2160 (4K UHD) |
| Aspect Ratio | 16:9 |
| Backlight | DLED |
| Brightness | 500 nits (max.) |
| Contrast Ratio | 5,000:1 (typical), 50,000:1 (dynamic) |
| Refresh Rate | 60 Hz |
| Response Time | 6.5 ms |
| Colour Gamut | 98% sRGB |
| Colour Accuracy | ΔE ≤ 1 |
| Viewing Angle | 178° (H/V) |
| Glass | Zero parallax, 3 mm 9H tempered |
| Backlight Life | ≥ 60,000 hours |
Touch
| Technology | Infrared recognition |
| Touch Points | 50 |
| Accuracy | ±0.5 mm |
| Response Time | ≤ 2.5 ms |
| Writing Height | ≤ 1 mm |
| Object Recognition | 1.5 mm |
| Features | Direct annotation, palm rejection, sharp erase, erase and write simultaneously |
Camera
| Resolution | 50MP (x1) |
| Field of View | 115° DFOV, 101° HFOV, 85° VFOV |
| Features | Manual mode, auto framing, speaker tracking, person counting, random election |
Audio
| Sound System | SkyWave Sound System, 2.2 channel |
| Speaker Power | 2 x 8 W + 2 x 18 W (output); 2 x 12 W + 2 x 25 W (maximum) |
| Sound Pressure Level | 88 dB (1 W, 1 m) |
| Microphones | 8-mic array |
| Pick-up Angle / Range | 180° / 0–12 m |
| Processing | Intelligent audio fence, AI spatial sound, AEC, ANC, AGC |
Built-in System
| Operating System | Android 15.0 (Google EDLA certified), MAXHUB EDU OS V4 |
| CPU | A76 x 4 + A55 x 4 octa-core, 2.4 GHz (8 nm) |
| GPU | Mali-G610 MP4 |
| NPU | 6 TOPS |
| RAM / Storage | 16GB / 256GB |
| Wi-Fi | Wi-Fi 6, 802.11 a/b/g/n/ac/ax, 2.4 GHz / 5 GHz |
| Bluetooth | 5.2 |
Ports
| HDMI In | 4 (up to 4K@60Hz, HDCP 1.4 / 2.2 / 2.3) |
| DP In | 1 (4K@30Hz) |
| USB Type-C | 2 in (front up to 65 W PD, rear up to 100 W PD), 1 out |
| USB | 4 x USB 3.0 (2 front, 2 rear), 1 x USB 2.0 |
| Touch USB | 2 (USB 3.0) |
| HDMI Out | 1 (up to 4K@60Hz) |
| Audio | 1 x 3.5 mm in, 1 x 3.5 mm out, 1 x SPDIF |
| Network / Control | RJ45 in, RJ45 out (10/100/1000 Mbps), RS232 |
| Expansion | OPS slot, Wi-Fi module slot, TF card (up to 1TB) |
Power & Physical
| Power Supply | AC 100–240 V, 50/60 Hz |
| Power Consumption | 70 W typical, ≤ 0.5 W standby |
| Dimensions (L x H x D) | 1488.4 x 909.4 x 97 mm |
| Shipping Dimensions | 1628 x 1020 x 185 mm |
| Wall-Mount Thickness | 122 mm |
| Net / Gross Weight | 30.7 kg / 40.5 kg |
| VESA | No (MAXHUB wall-mount bracket included) |
| Operating Temperature | 0–40 °C |
| Dust Resistance | IP5X |
Certifications
| Platform | Google EDLA |
| Eye Care | TÜV Flicker Free, TÜV Low Blue Light |
| Energy | Energy Star |
Compatibility & Software Support
Built-in Software
MAXHUB EDU OS V4 with MAXHUB Class Pro whiteboard, Browser, Cloud Drive, Note and Palette, plus Google Play, Google Drive, Google Meet, Google Maps and YouTube via Google EDLA certification.
Screen Sharing & BYOD
MAXHUB Connect wireless screen sharing; HDMI, DP and USB-C wired connection for laptops, with USB-C touch-back and charging.
Management & Expansion
MAXHUB Pivot remote device management; RS232 control. Optional MAXHUB accessories listed on the datasheet include the OPS62A / OPS72A Windows PC modules, UC W31 USB camera, UC P30 PTZ camera, UC S07 video bar, SP30B smart pen, WL10C / WL20 sensor boxes and ST33M / ST23B / EST09 mobile stands.
Package Contents & U4 Series Ordering Information
In the Box
Per MAXHUB's U4 Series datasheet: 3 m power cord, 3 m HDMI cable, remote control, 2 x SW13F styluses, 2 x display brackets, WIB9060K wall-mount bracket and SI07B Wi-Fi module. Mobile stands are sold separately — see the ST33M mobile trolley and EST09 motorised stand.
U4 Series Models
| Model | Size | i5 bundle | i7 bundle |
| U6540 (this listing) | 65" | U6540 + OPS-i5 | U6540 + OPS-i7 |
| U7540 | 75" | U7540 + OPS-i5 | U7540 + OPS-i7 |
| U8640 | 86" | U8640 + OPS-i5 | U8640 + OPS-i7 |
Datasheet & Downloads
| MAXHUB U4 Series datasheet | U4 Series Datasheet V1.1 (PDF) |
| Series brochure | U4 Series Brochure (PDF) |
| MAXHUB product page | U4 Series on maxhub.com |
Need a PDF sent directly? Email sales@sourceit.com.sg quoting U6540.
Frequently Asked Questions — MAXHUB U6540
Is a Windows PC included?
No. The U6540 runs Google EDLA-certified Android 15 on its own. It has an OPS slot, and MAXHUB lists the OPS62A / OPS72A PC modules as options — see the bundle listings in the table above.
Does it have a built-in camera and microphones?
Yes — a 50MP camera with auto framing and speaker tracking, and an 8-mic array with up to 12 m pick-up range.
Can I use Google apps?
Yes. The U4 Series is Google EDLA certified, with Google Play, Google Drive, Google Meet and YouTube.
How do students and teachers share their screens?
Wirelessly with MAXHUB Connect, or by cable via 4 x HDMI, DP or USB-C (front USB-C up to 65 W charging).
Does it include a wall mount?
Yes. The WIB9060K wall-mount bracket is in the box. The panel does not use a VESA pattern. Mobile stands are sold separately, and we can quote delivery and installation.
What warranty do I get?
3 years local warranty in Singapore, supplied by SourceIT with a GST invoice.
