LG 32SM5J-B 32" Full HD Signage Display, 400 nit, 24/7, webOS 6.0
PRODUCT DESCRIPTION
LG 32SM5J-B 32" Full HD Standard Signage with webOS (32SM5J-B) - 3 Years Local Warranty
Full HD Signage for 24/7 Operation
The LG 32SM5J-B is a 32-inch Full HD (1,920 x 1,080) IPS signage display with 400 nit (typ.) brightness and 178° viewing angles. LG rates it for 24/7 operation — suited to retail shelves, counters, menu boards and meeting-room signage.
Compact and Easy to Place
At 55.5 mm deep and 5.7 kg, it mounts on a 200 x 200 mm VESA bracket or on LG's optional ST-322T stand, in landscape or portrait.
webOS 6.0 Built In
LG webOS 6.0 plays scheduled content from 8 GB internal memory, USB Plug & Play or a URL, with Screen Share, built-in Wi-Fi, a temperature sensor and an auto-brightness sensor.
Managed with LG Software
The display works with LG SuperSign CMS, SuperSign Control+ and LG ConnectedCare for remote monitoring, and supports SNMP, Control Manager and Wake on LAN.
Need help choosing a small signage display? Email sales@sourceit.com.sg with your location, mounting and content source, and we will recommend the right model.
LG 32SM5J-B Datasheet — Technical Specifications
General
| Product Name | LG 32SM5J-B 32" Full HD Standard Signage |
| Part Number | 32SM5J-B |
| Series | SM5J Standard Signage |
| Local Warranty (Singapore) | 3 years on-site, supplied by SourceIT with a GST invoice |
Panel
| Screen Size | 32" |
| Panel Technology | IPS |
| Backlight | Direct |
| Native Resolution | 1,920 x 1,080 (FHD), 16:9, 60 Hz |
| Brightness | 400 nit (typ.) |
| Contrast Ratio | 1,100:1 (typ.); dynamic 1,000,000:1 |
| Colour Gamut | NTSC 68% |
| Colour Depth | 16.7 million colours (8 bit) |
| Viewing Angle (H x V) | 178 x 178 |
| Response Time | 10 ms (G to G) |
| Surface Treatment (Haze) | 1% |
| Panel Life (Min.) | 50,000 hours |
| Operation Hours | 24/7 |
| Portrait / Landscape | Yes / Yes |
Connectivity
| Inputs | HDMI x 3 (HDCP 2.2), USB 2.0 Type-A |
| Outputs | Audio out (off / fixed / variable) |
| External Control | RS-232C in/out (phone jack), RJ45 (LAN) in, IR in (phone jack) |
| Wireless | Wi-Fi (built-in) |
| Speakers | 10 W x 2 |
Mechanical
| Bezel | Black, 13 mm (top/right/left), 18 mm (bottom) |
| Dimensions (W x H x D) | 729.4 x 428.9 x 55.5 mm |
| Dimensions with Stand (W x H x D) | 729.4 x 481 x 154.2 mm |
| Weight (Head) | 5.7 kg |
| Weight (Head + Stand) | 6.5 kg |
| Carton Dimensions (W x H x D) | 810 x 510 x 132 mm |
| Packed Weight | 7.4 kg |
| VESA Mount | 200 x 200 mm |
Power & Environment
| Power Supply | AC 100–240 V, 50/60 Hz, built-in power |
| Power Consumption | 55 W typ. / 75 W max.; Smart Energy Saving 38.5 W; DPM 0.5 W; power off 0.5 W |
| Heat Dissipation | 187.7 BTU/hr (typ.), 255.9 BTU/hr (max.) |
| Operating Temperature | 0 °C to 40 °C |
| Operating Humidity | 10% to 80% |
Certifications
| Safety | CB / NRTL |
| EMC | FCC Class A / CE |
| ErP / Energy Star | No / Yes |
Compatibility & Software Support
Platform
LG webOS 6.0 with 8 GB internal memory, temperature sensor and auto-brightness sensor. Features listed by LG include embedded CMS (local contents scheduling, Group Manager), USB Plug & Play, Fail Over, booting logo and no-signal image, Screen Share, Play via URL, setting data cloning, ISM method, Beacon, HDMI-CEC, SI server setting, webRTC and Pro:Idiom.
LG Software
| SuperSign CMS | Yes |
| SuperSign Control / Control+ | Yes |
| SuperSign WB | Yes |
| SuperSign Media Editor | Yes |
| LG ConnectedCare | Yes |
| SuperSign Cloud | No (per LG Global) |
Control & Integration
SNMP, Control Manager, Wake on LAN, PM Mode and Smart Energy Saving; LG Global also lists Crestron Connected. Tile Mode: not supported.
Package Contents & SM5J Ordering Information
In the Box
Remote controller, power cord, quick setup guide, HDMI cable, phone to RS-232C gender.
Optional Accessories (LG)
Stand ST-322T, wall bracket LSW230B, VESA adapter AM-B220S. Stands, wall brackets and installation are not included in the price.
Ordering Information
| Model | Part No. |
| 32" FHD, 400 nit (this listing) | 32SM5J-B |
| 32" FHD, 500 nit, webOS 6.1 | 32UL5Q-M |
| 22" FHD small signage | 22SM3G-B |
Datasheet & Downloads
| LG product page (Singapore) | 32SM5J-B on lg.com/sg |
| LG spec sheet (Global) | 32SM5J on lg.com/global |
| Manuals | LG Business manual download |
Need a PDF sent directly? Email sales@sourceit.com.sg quoting 32SM5J-B.
Frequently Asked Questions — LG 32SM5J-B
Can it run content without a media player?
Yes. webOS 6.0 plays content from its 8 GB internal memory, USB Plug & Play or a URL, and works with LG SuperSign CMS for scheduling.
Is it suitable for 24/7 use?
Yes. LG rates the 32SM5J-B for 24/7 operation.
Can it be mounted in portrait?
Yes. LG lists both portrait and landscape orientation.
Is a stand or wall bracket included?
No. LG's stand (ST-322T) and wall bracket (LSW230B) are optional and installation is quoted separately; the VESA pattern is 200 x 200 mm.
What warranty do I get?
3 years local on-site warranty in Singapore, supplied by SourceIT with a GST invoice.
