Ergotron Neo-Flex® Cantilever, UHD
PRODUCT DESCRIPTION
Ergotron Neo-Flex® Cantilever, UHD (61-132-223) - 3 Years Local Warranty
Ultra-Heavy-Duty Full-Motion Wall Mount
The Ergotron Neo-Flex Cantilever, UHD is engineered for the largest, heaviest displays — 37 inches and up, weighing as much as 120 lbs (54.4 kg). Its extruded-aluminium arm delivers the strength to bring a very large panel out from the wall and hold it rock-steady, without sag or wobble, in demanding commercial and signage settings.
Long 18.8" Reach with Full Motion
Extend the display up to 18.8 inches (478 mm) from the wall, tilt it 16°, pan 180° and fine-tune 2.9 inches side to side, then retract it to a slim 3.8-inch profile. Whatever the room layout, viewers get a clear, glare-free angle.
Space-Saving, Low-Profile Design
The low-profile cantilever keeps a big screen close to the wall for a clean look while still allowing generous reach when needed — freeing floor and surface space for a tidy, modern installation.
Strength Built to Last
High-grade steel and aluminium construction provides the rigidity required for very large UHD displays and reliable, long-term performance. A bundled Spider 46 adapter helps fit a broad range of panels.
Ergotron Neo-Flex Cantilever UHD Datasheet — Technical Specifications
General
| Product | Neo-Flex® Cantilever, UHD |
| Part Number | 61-132-223 |
| Finish | Black |
| Displays Supported | 1 |
| Mounting Type | Wall mount (cantilever, full motion) |
Display Compatibility
| Screen Size | 37" and larger |
| Weight Capacity | Up to 120 lbs (54.4 kg) |
| VESA Compatibility | 200 x 200 mm to 600 x 400 mm |
Adjustment & Motion
| Tilt | 16° |
| Pan | 180° |
| Lateral Adjustment | 2.9" (7.4 cm) |
| Reach / Extension | Up to 18.8" (478 mm) |
| Folded Profile | 3.8" (97 mm) from wall |
Design & Durability
| Construction | Extruded aluminium / steel |
| Cable Management | Integrated |
| Manufacturer Warranty | 3-Year Manufacturer Warranty (Ergotron) |
| Local Warranty | Local Warranty (Singapore) |
Compatibility & Fit
The Neo-Flex Cantilever, UHD is a single-display wall mount for very large panels of 37 inches and up, weighing up to 120 lbs (54.4 kg). It supports VESA patterns from 200 x 200 mm up to 600 x 400 mm, with a Spider 46 adapter included.
This is Ergotron's heaviest-duty Neo-Flex cantilever — use it where a large UHD display needs full motion and long reach. For panels up to 63" and 80 lbs, the Neo-Flex Cantilever, VHD (45-385-223) is a lighter, lower-cost alternative.
Package Contents & Neo-Flex Cantilever Ordering Information
In the box: Wall plate, full-motion arm, monitor plate, cable management, Spider 46 adapter and complete installation hardware.
Neo-Flex Cantilever Range
| Cantilever, UHD (37"+, up to 54.4 kg) | 61-132-223 (this listing) |
| Cantilever, VHD (up to 63", 36.3 kg) | 45-385-223 |
Datasheet & Downloads
Frequently Asked Questions — Ergotron Neo-Flex Cantilever UHD
How large a display can the UHD cantilever hold?
Very large panels of 37 inches and up, weighing up to 120 lbs (54.4 kg).
What is the difference between UHD and VHD?
The UHD (61-132-223) is heavier-duty — up to 120 lbs and 18.8" of reach; the VHD (45-385-223) handles up to 63" / 80 lbs with 14" of reach.
How far does it extend from the wall?
Up to 18.8 inches (478 mm), and it folds back to a 3.8-inch (97 mm) profile.
Which VESA patterns are supported?
From 200 x 200 mm up to 600 x 400 mm, with a Spider 46 adapter included.
Can I angle the screen after mounting?
Yes — 16° tilt, 180° pan and 2.9 inches of lateral adjustment let you fine-tune the viewing angle.
Does it come with a local warranty?
Yes. Every Ergotron Neo-Flex Cantilever UHD sold by SourceIT comes with local Singapore warranty and a GST invoice; Ergotron backs the Neo-Flex Cantilever UHD with a 3-year manufacturer warranty.
