Epson SureColor SC-T3435 24" Technical Printer (C11CJ55403) - 3 Years Local Warranty
The Epson SureColor SC-T3435 24" Technical Printer - Go Big on Exceptional Accuracy.
Go Big on Exceptional Accuracy
Enhance your ideas by showcasing them in a big way with stand-out performance, impeccable precision, and exceptional engineering.
Small Footprint
Sleek and minimally designed, the Epson SureColor SC-T3435 has a comfortable size that fits into tight work spaces effortlessly.
User Convenience In Mind
Designed with the user in mind, the printer will hold on to print jobs until it is ready for collection, to prevent it from dropping to the ground.
Control At Your Fingertips
A 4.3 inch touch panel on the Epson SureColor SC-T3435 gives you the convenience of an easy setup and a PC-less operation.
Ergonomic Design
The Epson SureColor SC-T3435 smart design can cater to users of different heights to help make it comfortable for them to load the media.
Outstanding Quality
The UltraChrome XD2 uses pigment ink for CMYK to provide quality, and to deliver accurate and sharp line printing suitable for vector images.
Wireless Connectivity
The Epson SureColor SC-T3435 is integrated with Wi-Fi and Wi-Fi Direct, making it convenient to print right from smart devices.
Ideal For
Architects, engineers, construction firms and CAD/GIS teams in Singapore that print technical drawings, plans and posters. Supplied by SourceIT with local Singapore warranty, GST invoice and corporate or project pricing on request.
SureColor SC-T3435 Datasheet — Technical Specifications
General
| Model |
SureColor SC-T3435 |
| Official Product Name |
Epson SureColor SC-T3435 24" Technical Printer |
| Epson Product Code |
C11CJ55403 |
| Brand |
Epson |
| Warranty |
3 Years Local Warranty (Singapore) - 3 years |
Printing
| Print Head |
PrecisionCore TFP Printhead |
| Nozzle Configuration |
3,200 nozzles (800 nozzles x 4 channels x 1 head) |
| Maximum Print Resolution |
2,400 x 1,200 dpi |
| Minimum Ink Droplet Size |
4.0 pl |
| Line Accuracy |
±0.1% or ±0.26 mm |
| Minimum Line Width |
0.07 mm; 0.02 mm (addressable) |
Print Speed
| POP |
24 sec (A1) |
| CAD |
25 sec |
Paper Handling
| Media Thickness |
Roll: 0.08–0.3 mm; Cutsheet: 0.08–0.3 mm |
| Media Type |
Inkjet Coated Paper, Tracing Paper, Plain Paper |
| Side Margin |
Roll: 3 mm (Borderless: 0 mm); Cutsheet: 3 mm (Top) / 20 mm (Bottom) / 3 mm (Left/Right); Borderless: 3 mm (Top) / 20 mm (Bottom) / 0 mm (Left/Right) |
| Borderless Print |
Yes |
| Maximum Roll Diameter / Weight |
2/3" Core, Max. 170 mm / 8kg |
| Paper Width |
Roll: 254–610 mm; Cutsheet: 210–610 mm |
Consumables
| Black Ink Cartridge |
110ml: C13T41Q500; 350ml: C13T41D500; 700ml: C13T41C500 |
| Cyan Ink Cartridge |
110ml: C13T41Q200; 350ml: C13T41D200; 700ml: C13T41C200 |
| Magenta Ink Cartridge |
110ml: C13T41Q300; 350ml: C13T41D300; 700ml: C13T41C300 |
| Yellow Ink Cartridge |
110ml: C13T41Q400; 350ml: C13T41D400; 700ml: C13T41C400 |
| Maintenance Box |
C13T699700 |
| Auto Cutter Spare Blade |
C13S902007 |
| Borderless Replacement Pad Kit |
C13S400064 |
Printer Width
Ink System
| Ink Type |
UltraChrome XD2 Pigment Ink |
| Colours |
Cyan, Magenta, Yellow, Black |
Connectivity
| Memory |
1GB |
| Interface |
USB 3.0, Ethernet (100BASE-TX/1000BASE-T), Wi-Fi (IEEE802.11b/g/n) |
| USB Direct |
Yes |
| Printer Languages |
ESC/P raster, HP-GL/2, HP RTL |
| Document Scanner Integration |
Epson WorkForce DS-530, DS-6500, DS-60000 |
| Business Inkjet Printer Integration |
WF-R8591, WF-C869R, WF-C878R, WF-C879R, WF-C17590, WF-C20590, WF-C20600, WF-C20750, WF-C21000, WF-M20590 |
| Wi-Fi Direct |
Wi-Fi Direct (Simple AP) |
| Control Panel |
4.3" Touch Screen |
Electrical Specifications
| Rated Voltage, Frequency, Current |
AC 100–240V, 50/60Hz, 2.8A |
| Power Consumption |
Operating: Approx. 34W; Ready: Approx. 13W; Sleep: Approx. 1.3W; Power Off: Approx. 0.25W |
Environmental Conditions
| Operating Temperature |
10°C–35°C |
| Storage Temperature |
–20°C–40°C |
| Operating Humidity |
20–80% (no condensation) |
| Storage Humidity |
5–85% (no condensation) |
| Sound Pressure |
Operating: Approx. 49dB(A); Sleep: Approx. 32dB(A) |
| Sound Power |
Approx. 7.5B(A) |
Options
| Roll Feed Spindle (24") |
C12C933281 |
Software Information
| Supported OS |
Windows XP SP3 or later / Vista / 7 / 8 / 8.1 / 10; Windows Server 2003 / 2008 / 2012 / 2016 / 2019; Mac OS X 10.6.8 or later |
| Printer Management Tools |
Epson Edge Dashboard, LFP Accounting Tool, Epson Device Admin, Epson Cloud Solution PORT |
Dimensions and Weight
| Dimensions with Stand (W x D x H) |
1,080 x 750 x 1,060 mm |
| Weight with Stand |
64 kg |
Warranty
Compatibility & Software Support
Compatibility details below are taken from Epson Singapore's published specification for the SureColor SC-T3435. Drivers, utilities and firmware are available from Epson Singapore's support site (see Datasheet & Downloads).
| Interface |
USB 3.0, Ethernet (100BASE-TX/1000BASE-T), Wi-Fi (IEEE802.11b/g/n) |
| USB Direct |
Yes |
| Printer Languages |
ESC/P raster, HP-GL/2, HP RTL |
| Wi-Fi Direct |
Wi-Fi Direct (Simple AP) |
| Supported OS |
Windows XP SP3 or later / Vista / 7 / 8 / 8.1 / 10; Windows Server 2003 / 2008 / 2012 / 2016 / 2019; Mac OS X 10.6.8 or later |
Package Contents & Ordering Information
Ordering Information
| Model |
SureColor SC-T3435 |
| Epson Product Code |
C11CJ55403 |
| Recommended Retail Price (incl. GST) |
S$4,934.00 |
| Consumables |
UltraChrome XD2 pigment ink cartridges: Black 110ml C13T41Q500 / 350ml C13T41D500 / 700ml C13T41C500; Cyan 110ml C13T41Q200 / 350ml C13T41D200 / 700ml C13T41C200; Magenta 110ml C13T41Q300 / 350ml C13T41D300 / 700ml C13T41C300; Yellow 110ml C13T41Q400 / 350ml C13T41D400 / 700ml C13T41C400. Maintenance Box C13T699700. Auto Cutter Spare Blade C13S902007. Borderless Replacement Pad Kit C13S400064. Option: Roll Feed Spindle 24" C12C933281. |
In the Box
- Printer
- Printer Stand
- Initial Ink Cartridge
- AC Power Cable
- Setup Guide
- Software CD-ROM
- Maintenance Box
Datasheet & Downloads
Frequently Asked Questions — SureColor SC-T3435
What warranty does the SureColor SC-T3435 come with?
3 Years Local Warranty from Epson Singapore: 3 years. Every unit sold by SourceIT is a genuine Singapore set with a GST invoice.
Which consumables does the SureColor SC-T3435 use?
UltraChrome XD2 pigment ink cartridges: Black 110ml C13T41Q500 / 350ml C13T41D500 / 700ml C13T41C500; Cyan 110ml C13T41Q200 / 350ml C13T41D200 / 700ml C13T41C200; Magenta 110ml C13T41Q300 / 350ml C13T41D300 / 700ml C13T41C300; Yellow 110ml C13T41Q400 / 350ml C13T41D400 / 700ml C13T41C400. Maintenance Box C13T699700. Auto Cutter Spare Blade C13S902007. Borderless Replacement Pad Kit C13S400064. Option: Roll Feed Spindle 24" C12C933281. Always use genuine Epson consumables to protect print quality and warranty coverage. SourceIT can supply them together with the unit.
Is stock held locally?
SourceIT holds fast-moving Epson models in Singapore. Anything not in local stock is ordered through Epson's local distributor - ask us for the current lead time before committing to a date.
Can SourceIT quote for multiple units or a project?
Yes. Send us your quantity and delivery requirements and we will quote the units together with consumables, options and installation where required, with local warranty and GST invoice.
