Epson SureColor SC-T3130N Technical Printer
PRODUCT DESCRIPTION
Epson SureColor SC-T3130N Technical Printer (C11CF11406) - 3 Years Local Warranty
The Epson SureColor SC-T3130N Technical Printer - Fast and Accurate, Down to the Finest Details.
Compact, User-Friendly Design
Small footprint measuring 970 x 505 x 230mm without stand, enabling placement in tight workspaces. Front-access operation allows positioning against walls or corners. Auto Switch Function seamlessly transitions between roll and cut-sheet paper. Ergonomic design accommodates users of varying heights for comfortable media loading and operation.
Trusted Productivity
Integrated Wi-Fi and Wi-Fi Direct connectivity enable printing from smart devices throughout the office. Apple AirPrint compatibility allows direct wireless printing from Apple devices without additional drivers. 4.3-inch touch panel provides convenient setup and PC-less operation, with a preview function to confirm documents before printing to prevent waste. Seamless scan-to-print capability with compatible Epson scanners. PrecisionCore printhead technology delivers speed, quality and reliability using piezo elements for heatless ink ejection. Nozzle Verification Technology monitors printhead health automatically during operation. Anti-dust design minimises maintenance requirements.
Outstanding Speed & Quality
Prints A1 documents in 34 seconds. UltraChrome XD2 pigment ink provides accurate line printing suitable for vector images, with reduced bleed-through and superior weather resistance.
Security & Workflow Management
Supports IEEE802.1X, SNMPv3 and TLS/SSL encryption standards. Compatible with Epson Edge Dashboard, EpsonNet Setup Manager and Epson Device Admin for streamlined multi-printer management.
Ideal For
Architects, engineers, construction firms and CAD/GIS teams in Singapore that print technical drawings, plans and posters. Supplied by SourceIT with local Singapore warranty, GST invoice and corporate or project pricing on request.
SureColor SC-T3130N Datasheet — Technical Specifications
General
| Model | SureColor SC-T3130N |
| Official Product Name | Epson SureColor SC-T3130N Technical Printer |
| Epson Product Code | C11CF11406 |
| Brand | Epson |
| Warranty | 3 Years Local Warranty (Singapore) - 3 years |
Ink
| Ink Type | Epson UltraChrome XD2 Pigment Ink |
| Colours | 4 Colours – Cyan, Magenta, Yellow, Black |
| Ink Capacity | Black: 50ml, 80ml; Cyan, Magenta, Yellow: 26ml, 50ml |
Roll Media Handling
| Maximum Roll Diameter | 2" core |
| Maximum Roll Weight | Max. 100 mm / 3kg |
Control Panel
| Control Panel | 4.3" Touch Screen |
Consumables
| Maintenance Box | Yes |
| Auto Cutter Spare Blade | Yes |
Printer Width
| Printer Width | 24" |
Connectivity
| Included Software | Windows: Install Navi, Printer driver, EpsonNet Setup, EpsonNet Print, EpsonNet Config, Epson Software Updater, LFP Print Plug-in for Office, Epson manuals; Mac: Setup Navi |
| Interface | USB/LAN/WiFi |
| Printer Interfaces | Super-Speed USB, 100BASE-TX/1000BASE-T, IEEE802.11 b/g/n |
| Printer Languages | ESC/P raster, HP-GL/2, HP RTL |
| Scanner Integration | Supports Epson Document Scanner |
| Advanced Printer Driver | Crop/Rotate/Enlarge Tools |
Printing
| Printing Technology | Printhead: PrecisionCore TFP Printhead 1.3" |
| Nozzle Configuration | 3200 nozzles (800 nozzles x 4 channels x 1 head) |
| Maximum Print Resolution | 2400 x 1200 dpi |
| Minimum Ink Droplet Size | 4.0pl |
| Print Speed | CAD (A1): 34 sec |
Paper Handling
| Media Thickness | Roll: 0.05–0.21 mm; ASF/Cutsheet: 0.12–0.27 mm |
| Maximum Paper Width | Roll: 329–610 mm; Cutsheet (ASF): A4 to A3; Cutsheet (1 sheet): 210–610 mm |
| Media Type | Inkjet Coated Paper, Tracing Paper, Plain Paper |
| Side Margin | 3mm |
| Auto-Sheet Feeder | Yes (Up to A3) |
Power
| Power Consumption | Operating: Approx. 28W; Ready: Approx. 8W; Sleep: Approx. 1.6W; Power Off: Approx. 0.2W |
| Power Requirement | AC 100–240V, 50/60Hz |
| Recommended Operating Humidity | Operating: 20–80% (no condensation); Storage: 5–85% (no condensation) |
General
| Dimensions (W x D x H) | 970 x 505 x 230 mm |
| Weight | 27kg (without ink cartridges) |
| Memory | 1GB |
| Warranty | 3-years warranty |
Compatibility & Software Support
Compatibility details below are taken from Epson Singapore's published specification for the SureColor SC-T3130N. Drivers, utilities and firmware are available from Epson Singapore's support site (see Datasheet & Downloads).
| Included Software | Windows: Install Navi, Printer driver, EpsonNet Setup, EpsonNet Print, EpsonNet Config, Epson Software Updater, LFP Print Plug-in for Office, Epson manuals; Mac: Setup Navi |
| Interface | USB/LAN/WiFi |
| Printer Interfaces | Super-Speed USB, 100BASE-TX/1000BASE-T, IEEE802.11 b/g/n |
| Printer Languages | ESC/P raster, HP-GL/2, HP RTL |
| Advanced Printer Driver | Crop/Rotate/Enlarge Tools |
Package Contents & Ordering Information
Ordering Information
| Model | SureColor SC-T3130N |
| Epson Product Code | C11CF11406 |
| Recommended Retail Price (incl. GST) | S$3,564.00 |
| Consumables | UltraChrome XD2 pigment ink (epson.com.sg ink page for C11CF11406): T40B series – Black 80ml C13T40B100, Cyan 50ml C13T40B200, Magenta 50ml C13T40B300, Yellow 50ml C13T40B400; T40A series – Black 50ml C13T40A100, Cyan 26ml C13T40A200, Magenta 26ml C13T40A300, Yellow 26ml C13T40A400. Maintenance box and auto cutter spare blade listed as available (part numbers not published on page). |
Epson Singapore does not publish an itemised in-the-box list for this model. Please ask SourceIT if you need the exact package contents confirmed before ordering.
Datasheet & Downloads
Frequently Asked Questions — SureColor SC-T3130N
What warranty does the SureColor SC-T3130N come with?
3 Years Local Warranty from Epson Singapore: 3 years. Every unit sold by SourceIT is a genuine Singapore set with a GST invoice.
Which consumables does the SureColor SC-T3130N use?
UltraChrome XD2 pigment ink (epson.com.sg ink page for C11CF11406): T40B series – Black 80ml C13T40B100, Cyan 50ml C13T40B200, Magenta 50ml C13T40B300, Yellow 50ml C13T40B400; T40A series – Black 50ml C13T40A100, Cyan 26ml C13T40A200, Magenta 26ml C13T40A300, Yellow 26ml C13T40A400. Maintenance box and auto cutter spare blade listed as available (part numbers not published on page). Always use genuine Epson consumables to protect print quality and warranty coverage. SourceIT can supply them together with the unit.
Is stock held locally?
SourceIT holds fast-moving Epson models in Singapore. Anything not in local stock is ordered through Epson's local distributor - ask us for the current lead time before committing to a date.
Can SourceIT quote for multiple units or a project?
Yes. Send us your quantity and delivery requirements and we will quote the units together with consumables, options and installation where required, with local warranty and GST invoice.
