Epson SureColor SC-T3130 Technical Printer
PRODUCT DESCRIPTION
Epson SureColor SC-T3130 Technical Printer (C11CF11403) - 3 Years Local Warranty
The Epson SureColor SC-T3130 Technical Printer - Fast and Accurate, Down to the Finest Details.
Fast and Accurate, Down to the Finest Details
Great performance packed into a compact size, the SC-T3130 printer is engineered to enhance work processes.
Compact, User-Friendly Design
Small footprint measuring 970 x 505 x 230mm without stand – one of the smallest in its class. Designed for full front operation, allowing placement in office corners without consuming excessive space. Auto Switch Function for seamless transitions between roll and cut sheet paper. Print-and-cut functionality retains output until collection. Ergonomically designed to accommodate users of varying heights for comfortable media loading and operation.
Trusted Productivity
Integrated Wi-Fi and Wi-Fi Direct connectivity enables printing from smart devices anywhere in the office; Wi-Fi Direct functions as an access point without requiring a router. Apple AirPrint support allows direct wireless printing from Apple devices without additional drivers. 4.3-inch touch screen provides convenient setup and PC-less operation, with a preview feature to review documents before printing to prevent wastage. Seamless scan-to-print (with compatible Epson scanners) in four steps without a computer. Advanced PrecisionCore printhead technology with piezo elements for heatless ink ejection; Variable Size Dot Technology controls ink droplets to 3.5 picolitres; Nozzle Verification Technology monitors printhead health and adjusts quality automatically during operation. Anti-dust design minimises cleaning requirements in dusty environments.
Outstanding Speed & Quality
PrecisionCore technology enables A1 printing in 22 seconds. UltraChrome XD2 pigment ink formulation optimised for plain and special media (tracing paper). All-pigment ink reduces bleed-through and withstands harsh weather better than dye inks. Delivers accurate, sharp line printing suitable for vector images.
Security & Workflow Management
Supports IEEE802.1X (LAN standard), SNMPv3 (network device management) and TLS/SSL encryption standards, plus HTTPS and IPsec protocols.
Convenience & Accessibility
Front-access design allows placement against walls and in corners. Printouts, ink changes and paper replacements are accessible from the front.
Ideal For
Architects, engineers, construction firms and CAD/GIS teams in Singapore that print technical drawings, plans and posters. Supplied by SourceIT with local Singapore warranty, GST invoice and corporate or project pricing on request.
SureColor SC-T3130 Datasheet — Technical Specifications
General
| Model | SureColor SC-T3130 |
| Official Product Name | Epson SureColor SC-T3130 Technical Printer |
| Epson Product Code | C11CF11403 |
| Brand | Epson |
| Warranty | 3 Years Local Warranty (Singapore) - 3 years |
Ink
| Ink Type | Epson UltraChrome XD2 Pigment Ink |
| Colours | 4 Colours – Cyan, Magenta, Yellow, Black |
| Ink Capacity | Black: 50ml, 80ml; Cyan, Magenta, Yellow: 26ml, 50ml |
Roll Media Handling
| Maximum Roll Diameter | 2" core |
| Maximum Roll Weight | Max. 110 mm / 3kg |
Control Panel
| Control Panel | 4.3" Touch Screen |
Consumables
| Maintenance Box | Yes |
| Auto Cutter Spare Blade | Yes |
Printer Width
| Printer Width | 24" |
Connectivity
| Included Software | Windows: Install Navi, Printer driver, EpsonNet Setup, EpsonNet Print, EpsonNet Config, Epson Software Updater, LFP Print Plug-in for Office, Epson manuals; Mac: Setup Navi |
| Interface | USB/LAN/WiFi |
| Printer Interfaces | Super-Speed USB, 100BASE-TX/1000BASE-T, IEEE802.11 b/g/n |
| Printer Languages | ESC/P raster, HP-GL/2, HP RTL |
| Scanner Integration | Supports Epson Document Scanner |
| Advanced Printer Driver | Crop/Rotate/Enlarge Tools |
Printing
| Printing Technology | Printhead: PrecisionCore TFP Printhead 1.3" |
| Nozzle Configuration | 3200 nozzles (800 nozzles x 4 channels x 1 head) |
| Maximum Print Resolution | 2400 x 1200 dpi |
| Minimum Ink Droplet Size | 4.0pl |
| Print Speed | CAD (A1): 34 sec |
Paper Handling
| Media Thickness | Roll: 0.05–0.21 mm; ASF/Cutsheet: 0.12–0.27 mm |
| Maximum Paper Width | Roll: 329–610 mm; Cutsheet (ASF): A4 to A3; Cutsheet (1 sheet): 210–610 mm |
| Media Type | Inkjet Coated Paper, Tracing Paper, Plain Paper |
| Side Margin | 3mm |
| Auto-Sheet Feeder | Yes (Up to A3) |
Power
| Power Consumption | Operating: Approx. 28W; Ready: Approx. 8W; Sleep: Approx. 1.6W; Power Off: Approx. 0.2W |
| Power Requirement | AC 100–240V, 50/60Hz |
| Recommended Operating Humidity | Operating: 20–80% (no condensation); Storage: 5–85% (no condensation) |
General
| Dimensions (W x D x H) | 970 x 696 x 913mm |
| Weight | 38kg (without ink cartridges) |
| Memory | 1GB |
| Warranty | 3-years warranty |
Compatibility & Software Support
Compatibility details below are taken from Epson Singapore's published specification for the SureColor SC-T3130. Drivers, utilities and firmware are available from Epson Singapore's support site (see Datasheet & Downloads).
| Included Software | Windows: Install Navi, Printer driver, EpsonNet Setup, EpsonNet Print, EpsonNet Config, Epson Software Updater, LFP Print Plug-in for Office, Epson manuals; Mac: Setup Navi |
| Interface | USB/LAN/WiFi |
| Printer Interfaces | Super-Speed USB, 100BASE-TX/1000BASE-T, IEEE802.11 b/g/n |
| Printer Languages | ESC/P raster, HP-GL/2, HP RTL |
| Advanced Printer Driver | Crop/Rotate/Enlarge Tools |
Package Contents & Ordering Information
Ordering Information
| Model | SureColor SC-T3130 |
| Epson Product Code | C11CF11403 |
| Recommended Retail Price (incl. GST) | S$3,933.00 |
| Consumables | UltraChrome XD2 pigment ink (epson.com.sg ink page): T40B series – Black 80ml C13T40B100, Cyan 50ml C13T40B200, Magenta 50ml C13T40B300, Yellow 50ml C13T40B400; T40A series – Black 50ml C13T40A100, Cyan 26ml C13T40A200, Magenta 26ml C13T40A300, Yellow 26ml C13T40A400. Maintenance box and auto cutter spare blade listed as available (part numbers not published on page). |
Epson Singapore does not publish an itemised in-the-box list for this model. Please ask SourceIT if you need the exact package contents confirmed before ordering.
Datasheet & Downloads
Frequently Asked Questions — SureColor SC-T3130
What warranty does the SureColor SC-T3130 come with?
3 Years Local Warranty from Epson Singapore: 3 years. Every unit sold by SourceIT is a genuine Singapore set with a GST invoice.
Which consumables does the SureColor SC-T3130 use?
UltraChrome XD2 pigment ink (epson.com.sg ink page): T40B series – Black 80ml C13T40B100, Cyan 50ml C13T40B200, Magenta 50ml C13T40B300, Yellow 50ml C13T40B400; T40A series – Black 50ml C13T40A100, Cyan 26ml C13T40A200, Magenta 26ml C13T40A300, Yellow 26ml C13T40A400. Maintenance box and auto cutter spare blade listed as available (part numbers not published on page). Always use genuine Epson consumables to protect print quality and warranty coverage. SourceIT can supply them together with the unit.
Is stock held locally?
SourceIT holds fast-moving Epson models in Singapore. Anything not in local stock is ordered through Epson's local distributor - ask us for the current lead time before committing to a date.
Can SourceIT quote for multiple units or a project?
Yes. Send us your quantity and delivery requirements and we will quote the units together with consumables, options and installation where required, with local warranty and GST invoice.
