Epson SureColor SC-P8530DM Production Photo Printer (C11CJ51402) - 1 Year Local Warranty
The Epson SureColor SC-P8530DM Production Photo Printer - AMPLIFY YOUR IDEAS WITH TOP CLASS PRINT QUALITY.
HIGHEST STANDARDS IN PRINT
Utilising the innovative three-level black ink technology that simultaneously employs photo black, light black and light light black, Epson's UltraChrome PRO 6 inks produce rich true-to-life black density and grey balance to ensure top-notch PRINTHEAD TECHNOLOGY quality in every print. Generating smooth gradients, transitions, and neutral grayscale in every photo.
ERGONOMIC & FUNCTIONAL
With a flat back design, Epson's P-series printers can be easily arranged in a plethora of layouts according to your space's fit. With high installation flexibility, the compact printers maximises space usage and fit perfectly, even in narrow spaces. 4.3 inch Optical Touch Colour LCD allows easy and quick access to print jobs and printer function. The printer has print, scan and fax capability for enhanced productivity.
BOOSTED EFFICIENCY
Operating with top-tier reliability, the Epson SureColor P-series save time and manpower with the Automatic Roll switching, simplifying the loading of new media rolls. Minimising downtime, the seamless operation ensures continuous printing and smooth operation.
ADVANCED PRINTHEAD TECHNOLOGY
This new line-up of printers delivers extraordinary performance for the professional printing industry, along with unparalleled colour-matching capabilities, all these enabled by Epson's PrecisionCore technology. Possibly the most advanced inkjet printhead technology ever developed, this revolutionary printhead is capable of producing outstanding performance and long-lasting quality with ultra-precise control of dot size, shape and placements.
PHOTOGRAPHIC ACCURACY AND CLARITY ULTRACHROME INKS
Printers can see the difference the advanced ten-colour screening algorithm makes. Print results show superior colour and clarity, producing extremely fine blends and subtle photographic transitions. The most critical eye will see accurate highlight-to-shadow details with no visible photographic graininess. Regardless of the viewing light source, prints reveal a consistent colour balance. Combined with the precise dot placement accuracy of the PrecisionCore TFP printhead, overall photographic print quality shows a dramatic improvement.
PRINTING WITH ADOBE POST SCRIPT
Adobe PostScript allows powerful image processing and reproduction that guarantees seamless and worry-free printing of vivid, crisp prints. No longer would your business have to fret about colour accuracy and precise line printing with the in-built Adobe PostScript module in your P-series.
EPSON SMART PANEL
Make the most out of your Epson P-series printers with the Epson Smart Panel app. Transform your iOS® and Android™ mobile devices into an intuitive control center. Conveniently set up, monitor, print, and scan on your Epson printers and easily commence print jobs from your fingertips. With a wide variety of configuration features, you can also customise the app according to your requirements into an all-in-one management app.
Ideal For
Photo labs, print service providers, photographers and fine-art studios in Singapore producing large-format photo and graphic output. Supplied by SourceIT with local Singapore warranty, GST invoice and corporate or project pricing on request.
SureColor SC-P8530DM Datasheet — Technical Specifications
General
| Model |
SureColor SC-P8530DM |
| Official Product Name |
Epson SureColor SC-P8530DM Production Photo Printer |
| Epson Product Code |
C11CJ51402 |
| Brand |
Epson |
| Warranty |
1 Year Local Warranty (Singapore) - 1 year |
Printing
| Print Head |
PrecisionCore MicroTFP Printhead |
| Nozzle Configuration |
9,600 Nozzles - Black: Pk:1,600, Mk:1,600; Colour: C:1,600, M:1,600, Y:1,600, Gray:1,600 |
| Maximum Print Resolution |
2,400 x 1,200 dpi |
| Minimum Ink Droplet Size |
3.5pl |
| Print Speed |
B0 size Premium Glossy Photo Paper 170gsm: 152 sec (Speed), 281 sec (Quality), 614 sec (Max Quality); Poster – B0 size Epson Premium Glossy Photo Paper 170gsm 1200dpi x 1200dpi: Standard(sRGB)/Quality: 281 sec |
| Printing Method |
PrecisionCore Inkjet Technology, Variable-Sized Droplet Technology |
| Margin (Roll Paper) |
With border: Top, bottom, right, left: Min. 3mm (Might differ depending on applications/media) Borderless: Top, bottom, right, left: Min. 0mm (Might differ depending on applications/media) |
| Margin (Cut Sheet) |
With border: Top, right, left: Min. 3mm Bottom: Min. 12.7mm (Might differ depending on applications/media) Borderless: Top: Min. 3mm Bottom: Min. 12.7mm Right, left: Min. 0mm (Might differ depending on applications/media) |
Ink
| Ink Type |
Pigment Ink |
| Colours |
Cyan, Magenta, Yellow, Gray, Photo Black, Matte Black |
| Ink Capacity |
110, 350, 700 ml |
| Ink Case |
Ink Cartridge |
Paper Handling
| Paper Feed Method |
Friction Feed |
| Paper Path |
Roll (Double Roll), Cut Sheet (Manual Feed), Poster Board (Manual Feed) |
| Borderless Sizes |
254mm (10"), 300mm (11.8"), 330mm (13"), 356mm (14"), 406mm (16"), 432mm (17"), 500mm (19"), 508mm (20"), 515mm (20.3"), 594mm (23"), 610mm (24"), 700mm (27.5"), 728mm (28.6"), 841mm (33"), 914mm (36"), 1030mm (40.5"), 1188mm (44") |
| Paper Size & Thickness |
Width: Roll Paper: 254mm to 1,118mm; Cutsheet: 203mm to 1,118mm; Thickness: Roll: 0.07mm to 0.8mm; Cutsheet: 0.07mm to 0.8mm; Poster board : 0.8mm to 1.5mm |
| Maximum Reel Diameter |
Max. 170 mm*2 |
| Maximum Reel Weight |
12.5 Kg |
Recommended System Requirements
| Win PC System Requirements |
Windows 11/10/8.1/8/7/Vista/XP (32/64bit) or later; CPU : Core 2 Duo 3.05GHz or more; Memory : Memory more than 1GB; HDD : Free space more than 32GB |
| Mac System Requirements |
Mac OS X 10.6.8 or later, Mac OS 11 or later; CPU : Core 2 Duo 3.05GHz or more; Memory : Memory more than 4GB; HDD : Free space more than 32GB |
Dimensions and Weight
| Weight |
Approx. 166 Kg |
| Dimensions |
Printing: 1,848 x 828 x 975 mm (W x D x H); Stowed: 1,848 x 499 x 975 mm (W x D x H) |
Electrical Specifications
| Power Consumption |
Operating: Approx. 90W; Ready: Approx. 44W; Sleep: Approx. 2.0W; Power Off (Standby): Approx. 0.3W |
| Rated Current |
3.4 - 1.6A |
| Supply Voltage |
AC100-240V 50/60Hz |
Utility Software
| Utility Software (Bundled in CD) |
Windows: Printer Driver, EpsonNet Setup, EpsonNet Print, EpsonNet Config SE, Epson Manuals, Manual Launcher, LFP Print Plug-in for Office, PS Driver, PS Folder, Epson Scan 2 |
| Utility Software (Web delivery) |
Windows: Epson Media Installer, EpsonNet Setup Manager, Epson Device Admin, Epson Edge Dashboard, Epson Print Layout, Epson Print Automate, Epson Scan 2, Document Capture Pro, Epson Edge Print (Option), Epson Print Admin (Option), Order Controller (Option); Mac: Printer Driver, EpsonNet Config SE, Epson Manuals, Epson Media Installer, Epson Edge Dashboard, Epson Print Layout, PS Driver, Epson Scan 2, Document Capture iOS/Android, Epson Smart Panel |
Connectivity
| Interfaces |
SuperSpeed USB*4, 100BASE-TX /1000BASE-T/IEEE802.11b/g/n/ac, USB memory stick*5 |
| USB Direct |
Yes |
| Printer Language |
ESC/P raster |
Printable Area and Accuracy
| Maximum Printable Length |
91 m*3 |
General
| Memory |
6 GB |
| Acoustic Noise Level |
Sound Pressure Level: Approx. 47 dB(A); Sound Power Level: Approx. 6.4 B(A) |
| Control Panel |
4.3" Optical Touch Colour LCD |
| Printer Width |
44" |
| Options |
Roll Feed Spindle (44"), SSD Unit |
| Consumables |
Maintenance Box; Auto Cutter Spare Blade; Borderless Maintenance Box; Ink Cartridge |
Recommended Operating Temperature & Humidity
| Temperature |
Operating: 10°C to 35°C; Storage: -20°C to 40°C |
| Humidity |
Operating: 20 to 80% (no condensation); Storage: 5 to 85% (no condensation) |
Roll Media Handling
| Maximum Roll Diameter |
Max. 170 mm*2 |
| Maximum Roll Weight |
12.5kg |
Compatibility & Software Support
Compatibility details below are taken from Epson Singapore's published specification for the SureColor SC-P8530DM. Drivers, utilities and firmware are available from Epson Singapore's support site (see Datasheet & Downloads).
| Utility Software (Bundled in CD) |
Windows: Printer Driver, EpsonNet Setup, EpsonNet Print, EpsonNet Config SE, Epson Manuals, Manual Launcher, LFP Print Plug-in for Office, PS Driver, PS Folder, Epson Scan 2 |
| Utility Software (Web delivery) |
Windows: Epson Media Installer, EpsonNet Setup Manager, Epson Device Admin, Epson Edge Dashboard, Epson Print Layout, Epson Print Automate, Epson Scan 2, Document Capture Pro, Epson Edge Print (Option), Epson Print Admin (Option), Order Controller (Option); Mac: Printer Driver, EpsonNet Config SE, Epson Manuals, Epson Media Installer, Epson Edge Dashboard, Epson Print Layout, PS Driver, Epson Scan 2, Document Capture iOS/Android, Epson Smart Panel |
| Interfaces |
SuperSpeed USB*4, 100BASE-TX /1000BASE-T/IEEE802.11b/g/n/ac, USB memory stick*5 |
| USB Direct |
Yes |
| Printer Language |
ESC/P raster |
Package Contents & Ordering Information
Ordering Information
| Model |
SureColor SC-P8530DM |
| Epson Product Code |
C11CJ51402 |
| Recommended Retail Price (incl. GST) |
S$14,409.80 |
| Consumables |
UltraChrome PRO 6 inks. T50S 350ml: C13T48Y100 Photo Black, C13T48Y200 Cyan, C13T48Y300 Magenta, C13T48Y400 Yellow, C13T48Y800 Matte Black, C13T48YE00 Gray. T50L 700ml: C13T48R100 Photo Black, C13T48R200 Cyan, C13T48R300 Magenta, C13T48R400 Yellow, C13T48R800 Matte Black, Gray 700ml listed as C13T48Y200. Also listed without part numbers: Maintenance Box, Auto Cutter Spare Blade, Borderless Maintenance Box. |
In the Box
- Printer
- Initial ink cartridge
- AC Power Cable
- Setup Guide
- Software CD-ROM
- Borderless Maintenance Box
- Roll Feed Spindle
- USB 3.0 Cable
- Adobe PS Unit
Datasheet & Downloads
Frequently Asked Questions — SureColor SC-P8530DM
What warranty does the SureColor SC-P8530DM come with?
1 Year Local Warranty from Epson Singapore: 1 year. Every unit sold by SourceIT is a genuine Singapore set with a GST invoice.
Which consumables does the SureColor SC-P8530DM use?
UltraChrome PRO 6 inks. T50S 350ml: C13T48Y100 Photo Black, C13T48Y200 Cyan, C13T48Y300 Magenta, C13T48Y400 Yellow, C13T48Y800 Matte Black, C13T48YE00 Gray. T50L 700ml: C13T48R100 Photo Black, C13T48R200 Cyan, C13T48R300 Magenta, C13T48R400 Yellow, C13T48R800 Matte Black, Gray 700ml listed as C13T48Y200. Also listed without part numbers: Maintenance Box, Auto Cutter Spare Blade, Borderless Maintenance Box. Always use genuine Epson consumables to protect print quality and warranty coverage. SourceIT can supply them together with the unit.
Is stock held locally?
SourceIT holds fast-moving Epson models in Singapore. Anything not in local stock is ordered through Epson's local distributor - ask us for the current lead time before committing to a date.
Can SourceIT quote for multiple units or a project?
Yes. Send us your quantity and delivery requirements and we will quote the units together with consumables, options and installation where required, with local warranty and GST invoice.
