Epson Discproducer PP-100III Disc Publisher
PRODUCT DESCRIPTION
Epson Discproducer PP-100III Disc Publisher (C11CH40061) - 1 Year Local Warranty
The Epson PP-100III - Automated Disc Publishing.
High Precision & Reliability
The Discproducer PP-100III features a durable design and AcuGrip™ robotic arm for precise disc handling, reducing scratches and production interruptions.
High Quality & Cost Efficiency
Epson Micro Piezo™ technology delivers sharp, vibrant disc labels up to 1440 dpi x 720 dpi, while individual ink cartridges help reduce running costs.
Easy & Flexible Operation
The Total Disc Maker software enables simple disc creation, label design, and publishing. Monitoring software provides real-time status updates for reliable unattended operation.
Compact & Versatile
With a space-saving design, LCD status display, and multiple production modes, the PP-100III supports efficient CD, DVD, and Blu-ray publishing for various applications.
Ideal For
Organisations that publish and print CDs, DVDs and Blu-ray discs in batches — archives, medical imaging, education and media. Supplied by SourceIT with local Singapore warranty, GST invoice and corporate or project pricing on request.
Discproducer PP-100III Datasheet — Technical Specifications
General
| Model | Discproducer PP-100III |
| Official Product Name | Epson PP-100III |
| Epson Product Code | C11CH40061 |
| Brand | Epson |
| Warranty | 1 Year Local Warranty (Singapore) - 12 months |
Publishing Speed
| Printing Only (CD/DVD/BD) - Fast Mode | Up to 65 discs/hour |
| Printing Only (CD/DVD/BD) - Fine Mode | Up to 45 discs/hour |
| CD (Burn and print) | Up to 30 discs/hour |
| DVD (Burn and print) | Up to 15 discs/hour |
| BD (Burn and print) | Up to 8.5 discs/hour |
Publishing Modes (Unattended)
| Standard Mode | Up to 50 CDs/DVDs/BDs |
| Batch Mode | Up to 100 CDs/DVDs/BDs |
| External Output Mode - To stacker 3 | Up to 50 CDs/DVDs/BDs |
| External Output Mode - To stacker 4 | Up to 5 CDs/DVDs/BDs |
Printer Module
| Print Resolution - Fast Mode | 1440 dpi x 720 dpi |
| Print Resolution - Fine Mode | 1440 dpi x 1440 dpi |
Ink System
| Ink Type | Dye Ink |
| Ink Cartridge | Cyan, Light Cyan, Light Magenta, Magenta, Yellow, Black |
| Yield | 1,000 discs or more |
| Ink Pad Life | Approx. 30,000 discs |
CD/DVD Drives
| Number of Drives | 2 |
| Writing Speed (Max.) CD-R/CD+R | 40x |
| Writing Speed (Max.) DVD-R/DVD+R | 12x |
| Writing Speed (Max.) DVD-R DL/DVD+R DL | 8x |
| Writing Speed (Max.) BD-R/BD-R DL | 8x |
| Size - Outside diameter | 120 mm ± 0.3 mm |
| Size - Inside diameter | 15 mm + 0.1/- 0 mm |
| Size - Thickness | 1.2 mm + 0.3/- 0.1 mm |
| Format | Only standard 120mm (4.7") discs |
| Type | CD-R, DVD-R, DVD+R, DVD-R DL, DVD+R DL, BD-R, BD-R DL (BD archive disc not supported) |
| Surface | Inkjet Printable (for glossy discs, only Epson recommended are supported) |
Interface
| Standard | USB 3.0 Hi-Speed |
Software
| Standard | Total Disc Maker, Total Disc Net Administrator Tool |
Computer Requirements
| Operating System | Windows 11 Home, Pro, Enterprise; Windows 10 (32/64 bit) Home, Pro, Enterprise; Windows 7 (32/64 bit) Home Premium, Professional, Enterprise, Ultimate, SP1 or later; Windows Server 2025 Essentials, Standard; Windows Server 2022 Essentials, Standard; Windows Server 2019 Essentials, Standard; Windows Server 2016 Essentials, Standard |
| CPU | Must meet system requirements of each OS |
| Memory | Must meet system requirements of each OS |
| HDD Capacity | 1 GB free space for installation; Additional free space: approximately 1.5× the size of disc to be created (minimum 1 GB) in Working Folder drive |
| Graphics | XGA or better, 65,536 colours or better |
Electrical Specifications
| Rated Voltage | AC 100V to AC 240V |
| Frequency | 50Hz to 60Hz |
| Electric Power Consumption - Operating | Approx. 52W |
| Electric Power Consumption - Standby | Approx. 27W |
Consumables
| Black Ink Cartridge | PJIC7 (K) |
| Cyan Ink Cartridge | PJIC7 (C) |
| Light Cyan Ink Cartridge | PJIC7 (LC) |
| Magenta Ink Cartridge | PJIC7 (M) |
| Yellow Ink Cartridge | PJIC7 (Y) |
| Light Magenta Ink Cartridge | PJIC7 (LM) |
| Maintenance Box | C13S020476 PJMB100 |
Dimensions and Weight
| Dimensions (W x D x H) | 377 × 493 × 348 mm |
| Weight | Approx. 24kg (52.9lbs) |
Options
| Maintenance Box | Yes (Optional) |
| BD/BDXL Drive | Yes (Optional, BDE-PR1EP3) |
Compatibility & Software Support
Compatibility details below are taken from Epson Singapore's published specification for the Discproducer PP-100III. Drivers, utilities and firmware are available from Epson Singapore's support site (see Datasheet & Downloads).
| Operating System | Windows 11 Home, Pro, Enterprise; Windows 10 (32/64 bit) Home, Pro, Enterprise; Windows 7 (32/64 bit) Home Premium, Professional, Enterprise, Ultimate, SP1 or later; Windows Server 2025 Essentials, Standard; Windows Server 2022 Essentials, Standard; Windows Server 2019 Essentials, Standard; Windows Server 2016 Essentials, Standard |
Package Contents & Ordering Information
Ordering Information
| Model | Discproducer PP-100III |
| Epson Product Code | C11CH40061 |
| Recommended Retail Price (incl. GST) | S$5,472.00 |
| Consumables | PJIC7 ink cartridges (K, C, LC, M, Y, LM) - full C13 part numbers not published on page; Maintenance Box C13S020476 PJMB100. Yield 1,000 discs or more; ink pad life approx. 30,000 discs. |
In the Box
- Warranty card
- CD-ROM (Printer Driver, Application Software, User's Guide)
- Paper Manual (Setup Guide)
- 6 Ink Cartridges (Cyan, Magenta, Yellow, Light Cyan, Light Magenta, Black)
- USB cable
- AC Cable
Datasheet & Downloads
Frequently Asked Questions — Discproducer PP-100III
What warranty does the Discproducer PP-100III come with?
1 Year Local Warranty from Epson Singapore: 12 months. Every unit sold by SourceIT is a genuine Singapore set with a GST invoice.
Which consumables does the Discproducer PP-100III use?
PJIC7 ink cartridges (K, C, LC, M, Y, LM) - full C13 part numbers not published on page; Maintenance Box C13S020476 PJMB100. Yield 1,000 discs or more; ink pad life approx. 30,000 discs. Always use genuine Epson consumables to protect print quality and warranty coverage. SourceIT can supply them together with the unit.
Is stock held locally?
SourceIT holds fast-moving Epson models in Singapore. Anything not in local stock is ordered through Epson's local distributor - ask us for the current lead time before committing to a date.
Can SourceIT quote for multiple units or a project?
Yes. Send us your quantity and delivery requirements and we will quote the units together with consumables, options and installation where required, with local warranty and GST invoice.
