Dell Pro 5 14 P514260 Core Ultra 7 355 32GB 512GB Laptop
PRODUCT DESCRIPTION
Dell Pro 5 14 Laptop P514260 Intel Core Ultra 7 355 / 32GB / 512GB SSD (DP5P514260U732G512) - 3 Years Local Warranty
Series 3 Intel Core Ultra with built-in NPU
This Dell Pro 5 14 runs an Intel Core Ultra 7 355 processor (8 cores, up to 4.70 GHz) with a built-in NPU for on-device AI, paired with 32GB of DDR5 memory and a 512GB NVMe SSD. This Core Ultra 7 355 is not a vPro processor; choose the Core Ultra 5 335 vPro configuration if you need vPro remote management.
Thin 14-inch business laptop
Dell engineered the Pro 5 14 with a new chassis that starts at 1.34 kg and 10.80 mm at the front, with a 14-inch 16:10 display and a spill-resistant keyboard with a Copilot key.
Connected and serviceable
Two Thunderbolt 4 ports with Power Delivery and DisplayPort 2.1, two USB-A ports, HDMI 2.1 and built-in Gigabit RJ45 Ethernet, plus two SO-DIMM slots up to 64GB and discrete TPM 2.0 security.
Buying for an office roll-out? Email sales@sourceit.com.sg for volume pricing and delivery lead time.
Dell P514260 Datasheet — Technical Specifications
Configuration
| Product Name | Dell Pro 5 14 Laptop P514260 |
| SourceIT SKU | DP5P514260U732G512 |
| Processor | Intel Core Ultra 7 355 |
| Memory | 32GB DDR5 SO-DIMM, 5600 MT/s (Dell platform memory for this processor) |
| Storage | 512GB M.2 2230 PCIe NVMe SSD |
| Display, wireless, camera, battery, keyboard, OS | Per the supplied distributor SKU - see platform options below; confirm with sales before ordering |
| Local Warranty (Singapore) | 3 Years (distributor configuration), supplied by SourceIT with a GST invoice; Dell Singapore base service is Basic Hardware Service with Collect and Return |
Processor & Graphics
| Processor | Intel Core Ultra 7 355: 8 cores (4 Performance-cores + 4 Low Power Efficient-cores), 8 threads, up to 4.70 GHz, 12 MB cache, NPU up to 49 TOPS (not vPro) |
| Graphics | Intel Graphics (4 Xe-cores), integrated, shared system memory |
| PCIe bus | Up to Gen5 (Intel Core Ultra Series 3) |
| External display support | Two Thunderbolt 4 (40 Gbps) ports with Power Delivery and DisplayPort 2.1; one HDMI 2.1 port |
Memory & Storage
| Memory | Two DDR5 SO-DIMM slots, 5600 MT/s, up to 64GB |
| Storage slot | One M.2 Key-M 2230 slot for solid-state drive |
| Storage interface (options) | M.2 2230 SSD, PCIe Gen4 x4 NVMe or PCIe Gen5 x4 NVMe |
Display (platform options)
| Option 1 | 14-inch WUXGA (1920 x 1200), non-touch, IPS, 400 nits, 60 Hz, 62.5% sRGB, anti-glare |
| Option 2 | 14-inch WUXGA (1920 x 1200), touch, IPS, ComfortView Plus, 400 nits, 48-60 Hz, 100% sRGB, anti-glare |
| Option 3 | 14-inch WUXGA (1920 x 1200), non-touch, IPS, ComfortView Plus, Super Low Power, 500 nits, 1-120 Hz, 100% sRGB, anti-glare |
| Option 4 | 14-inch WQXGA (2560 x 1600), non-touch, IPS, ComfortView Plus, 500 nits, 48-120 Hz, 100% sRGB, anti-glare |
| Option 5 | 14-inch WUXGA (1920 x 1200) OLED (AMOLED), non-touch, ComfortView Plus, 300 nits, 60 Hz, DCI-P3 100% |
| Option 6 | 14-inch WUXGA (1920 x 1200), touch, IPS, ComfortView Plus, Intelligent Privacy, 500 nits, 60 Hz, 100% sRGB |
| Option 7 | 14-inch WUXGA (1920 x 1200), non-touch, IPS, Low Power, 400 nits, 60 Hz, 62.5% sRGB |
Ports & Slots
| USB ports | Two Thunderbolt 4 (40 Gbps) ports with Power Delivery and DisplayPort 2.1; One USB 3.2 Gen 1 port (5 Gbps); One USB 3.2 Gen 1 port (5 Gbps) with PowerShare |
| Video port | One HDMI 2.1 port |
| Network port | One RJ45 Ethernet port (1 Gbps) |
| Audio port | One global headset jack |
| Security-cable slot | One security-cable slot (wedge-shaped) |
| Smart-card reader | One smart-card reader slot (optional) |
| SIM-card slot | One nano-SIM card slot (for computers shipped with a WWAN card) |
| Power-adapter port | Thunderbolt 4 ports with Power Delivery |
Wireless (platform options)
| Option | Intel BE211, Wi-Fi 7 (802.11be), up to 5760 Mbps, 2.4/5/6 GHz, Bluetooth Core 6.0 |
| Option | Intel BE213, Wi-Fi 7 (802.11be), up to 2880 Mbps, 2.4/5/6 GHz, Bluetooth Core 6.0 |
| Option | Intel AX211, Wi-Fi 6E (802.11ax), up to 2400 Mbps, 2.4/5/6 GHz, Bluetooth Core 5.4 |
| Option | MediaTek MT7920, Wi-Fi 6 (802.11ax), up to 1200 Mbps, 2.4/5 GHz, Bluetooth Core 6.0 |
| WWAN (optional) | DW5826e-m Qualcomm Snapdragon SDX12 Global LTE-Advanced (4G) or DW5933e-m MediaTek T700 Global 5G Modem |
Camera (platform options)
| Option 1 | FHD RGB HDR camera, 1920 x 1080 (FHD) at 30 fps, 2.07 MP still, 83-degree diagonal viewing angle |
| Option 2 | FHD RGB HDR + IR camera, 1920 x 1080 at 30 fps; IR 360 x 360 at 15 fps (Windows Hello) |
| Option 3 | 8MP RGB HDR + IR camera, 2560 x 1440 (QHD) at 30 fps, 8.29 MP still; IR 360 x 360 at 15 fps |
| Features | Temporal Noise Reduction; presence detection on IR options (fact sheet); camera privacy shutter |
Audio
| Speakers | Two speakers, 2 W average / 2.5 W peak |
| Audio controller | Cirrus Logic codec CS42L43B, or CS42L45 with Cirrus Logic CS35L63 Smart Amplifier (configuration dependent) |
| Microphone | Digital-array microphones in camera assembly (fact sheet: 2x noise-canceling microphones) |
| External audio | One global headset jack |
Power
| Battery (options) | 3-cell 45 Wh, 57 Wh or 70 Wh lithium-ion, 11.25 VDC (Long Life Cycle variants available) |
| Charging | Standard 3 hours; ExpressCharge 2 hours; ExpressCharge Boost: 0% up to 35% in as little as 20 minutes |
| Power adapter (options) | 65 W USB-C; 65 W GaN USB-C; 65 W GaN USB-C 2-pin; 100 W USB-C (100-240 VAC input) |
Security
| TPM | Trusted Platform Module (TPM) 2.0 discrete, TCG certified |
| Chassis intrusion | Chassis Intrusion Detection; BIOS - TPM clear and/or system boot lock after chassis intrusion detection |
| BIOS | Quantum-resistant BIOS verification and signing updates; quantum-resistant embedded controller (fact sheet) |
| Lock slot | Wedge-shaped lock slot (Noble / Kensington wedge) |
| Camera | Camera privacy shutter |
| Optional | Touch fingerprint reader in power button with ControlVault3 Plus; contacted smart-card reader with ControlVault3 Plus; contactless smart-card reader and NFC with ControlVault3 Plus; IR camera (Windows Hello) |
| Storage | SED SSD NVMe (Opal and non-Opal) options |
Keyboard & Touchpad
| Keyboard (options) | Spill-resistant standard non-backlit keyboard or Mini-LED backlit keyboard, with AI (Copilot) hotkey |
| Key pitch | Horizontal 19.05 mm, vertical 18.05 mm |
| Touchpad | Precision clickpad, 128 mm x 78.50 mm, >300 DPI |
Physical
| Height | Front 10.80 mm; rear 14.72 mm; peak 18.10 mm (aluminium chassis; glass-fiber-composite chassis: 10.99 / 14.42 / 18.65 mm) |
| Width | 315.50 mm (12.42 in.) |
| Depth | 226.00 mm (8.89 in.) |
| Minimum weight | 1.34 kg (2.96 lb) aluminium chassis; 1.33 kg (2.93 lb) glass-fiber-composite chassis. Weight depends on configuration. |
| Materials (configuration) | Display lid anodized aluminium; palmrest and base cover anodized aluminium or Glass Fiber Composite |
| Sustainability | 50% recycled aluminium in top cover/palmrest; 30% post-consumer recycled plastic in inner frame; 20% recycled glass in display; 100% recycled or renewable packaging (fact sheet) |
Operating System (platform options)
| OS | Windows 11 Pro; Windows 11 Home; Windows 11 Pro Education; Ubuntu Linux 24.04 LTS |
Compatibility & Software Support
Operating System
Dell offers Windows 11 Pro, Windows 11 Home, Windows 11 Pro Education and Ubuntu Linux 24.04 LTS on this platform; the installed OS depends on the supplied SKU - confirm with sales.
Docking & Displays
Both Thunderbolt 4 ports support DisplayPort 2.1 and Power Delivery, so the laptop works with Thunderbolt and USB-C docks and USB-C hub monitors such as the Dell Pro and UltraSharp hub monitors, and charges through either port. HDMI 2.1 connects a projector or monitor directly.
Typical Use
Corporate fleets and hybrid workers who want a thin 14-inch Dell Pro laptop with built-in Ethernet, upgradeable SO-DIMM memory and Wi-Fi 7 options.
Package Contents & Dell Pro 5 14 P514260 Ordering Information
In the Box
Dell Pro 5 14 P514260 laptop and USB Type-C power adapter.
Dell Pro 5 14 P514260
| Processor | Memory / SSD |
| Core Ultra 5 335 vPro | 16GB / 512GB |
| Core Ultra 7 355 | 16GB / 512GB |
| Core Ultra 7 355 (this listing) | 32GB / 512GB |
Datasheet & Downloads
| Product fact sheet | Dell Pro 5 laptop product fact sheet (PDF) |
| Manuals & drivers | Dell Pro 5 14 P514260 specifications on Dell Support |
| Dell product page | Dell Pro 5 14 on dell.com Singapore |
Need a PDF sent directly? Email sales@sourceit.com.sg quoting P514260.
Frequently Asked Questions — Dell P514260
Can the memory be upgraded?
Yes. On Core Ultra 5 335 / Core Ultra 7 355 configurations Dell uses DDR5 SO-DIMM memory at 5600 MT/s in two slots, supporting up to 64GB.
Does it have an Ethernet port?
Yes. The Dell Pro 5 14 has a built-in RJ45 Gigabit Ethernet port.
Does it support Intel vPro?
No. Dell lists the Intel Core Ultra 7 355 without vPro. Choose the Core Ultra 5 335 vPro configuration if you need vPro remote management.
How does it charge?
Over USB-C through either Thunderbolt 4 port. With ExpressCharge Boost, Dell states the battery charges from 0% up to 35% in as little as 20 minutes.
What warranty do I get?
3 years per the distributor configuration, supplied locally by SourceIT with a GST invoice.
