Dell Pro 14 PC14255 Ryzen 5 220 16GB 512GB Laptop
PRODUCT DESCRIPTION
Dell Pro 14 Laptop PC14255 AMD Ryzen 5 220 / 16GB / 512GB SSD (Magnetite) (210-BQQD / 6758936) - 3 Years Local Warranty
AMD Ryzen Performance for Business
This Dell Pro 14 PC14255 pairs a 6-core, 12-thread AMD Ryzen 5 220 processor with Radeon 740M graphics for dependable everyday performance, 16GB of DDR5 memory (up to 5600 MT/s) and a 512GB PCIe Gen 4 NVMe SSD on a 14-inch FHD+ 1920 x 1200 16:10 display.
Ports for the Office and the Road
Two 40Gbps USB Type-C ports with Power Delivery and DisplayPort 1.4a, two 5Gbps USB-A ports (one with PowerShare), HDMI 2.1 and a built-in 1Gbps RJ45 Ethernet port cover docks, displays and wired networks without adapters.
Serviceable and Secure
Two DDR5 SO-DIMM slots (up to 64GB) and an M.2 2230 PCIe Gen 4 SSD slot keep the PC14255 upgradeable, while a discrete FIPS 140-2 certified TPM 2.0, chassis intrusion detection and a mechanical camera shutter protect company data.
Buying for an office roll-out? Email sales@sourceit.com.sg for volume pricing and delivery lead time.
Dell PC14255 Datasheet — Technical Specifications
Configuration
| Product Name | Dell Pro 14 Laptop PC14255 |
| SourceIT SKU | 210-BQQD / 6758936 |
| Processor | AMD Ryzen 5 220 |
| Memory | 16GB DDR5, up to 5600 MT/s |
| Storage | 512GB PCIe Gen 4 NVMe SSD |
| Colour | Magnetite |
| Display panel, camera, battery, keyboard, OS | Per the supplied distributor SKU - confirm with sales before ordering |
| Local Warranty (Singapore) | 3 Years (distributor configuration), supplied by SourceIT with a GST invoice |
Processor & Graphics
| Processor | AMD Ryzen 5 220: 6 cores / 12 threads, up to 4.9 GHz (no NPU) |
| Graphics | AMD Radeon 740M graphics |
Memory & Storage
| Memory Slots | 2 x DDR5 SO-DIMM, 5600 MT/s, up to 64GB (2 x 32GB) |
| Storage Slot | 1 x M.2 2230 PCIe Gen 4 NVMe SSD slot |
Display
| Size / Resolution | 14", FHD+ 1920 x 1200 (16:10), IPS, anti-glare |
| Panel options | Dell offers 300-nit non-touch, 400-nit 100% sRGB Low Blue Light non-touch and 300-nit touch panels; this configuration's panel is per the supplied SKU |
Ports & Slots
| USB-C | 2 x USB Type-C (40Gbps) with Power Delivery and DisplayPort 1.4a |
| USB-A | 2 x USB 3.2 Gen 1 (5Gbps), 1 with PowerShare |
| Video | 1 x HDMI 2.1 |
| Ethernet | 1 x RJ45 (1GbE) |
| Audio | 1 x global headset jack |
| Power | 4.5 mm barrel power input (in addition to USB-C charging) |
| Other | Wedge-shaped lock slot |
Wireless, Audio & Camera
| Wireless | MediaTek MT7922 Wi-Fi 6E with Bluetooth |
| Speakers | 2 x 2 W speakers, dual-array microphones |
| Camera options | HD 720p, FHD 1080p or FHD 1080p + IR, all with camera shutter - per supplied SKU |
Power
| Battery | 45 Wh or 55 Wh 3-cell (per supplied SKU), ExpressCharge and ExpressCharge Boost capable |
| Power Adapter | 65 W USB Type-C or 65 W 4.5 mm barrel adapter (per supplied SKU) |
Security
| TPM | Discrete TPM 2.0, FIPS 140-2 / TCG certified |
| Other | Chassis intrusion detection; mechanical camera shutter; wedge lock slot; fingerprint reader and IR camera (options) |
Physical
| Width x Depth | 313.70 x 225.30 mm |
| Height | 18.89 mm – 20.37 mm |
Compatibility & Software Support
Operating System
Dell offers the PC14255 with Windows 11 Pro or Home and Ubuntu Linux options; the installed OS edition depends on the supplied SKU - confirm with sales.
Docking & Displays
Both USB-C ports support DisplayPort and Power Delivery, so the laptop works with USB-C docks and USB-C monitors such as the Dell Pro USB-C hub monitors. HDMI 2.1 connects a projector or monitor directly.
Typical Use
Corporate fleets, finance and operations teams, and hybrid workers who want a mainstream AMD-powered 14-inch business laptop with wired Ethernet and upgradeable memory.
Package Contents & Dell Pro 14 PC14255 Ordering Information
In the Box
Dell Pro 14 PC14255 laptop and 65 W power adapter.
Dell Pro 14 PC14255 (AMD) Configurations at SourceIT
| Processor | Memory / SSD |
| Ryzen AI 5 PRO 340 | 16GB / 512GB |
| Ryzen 5 220 (this listing) | 16GB / 512GB (Magnetite) |
| Ryzen 5 PRO 230 | 16GB / 512GB (Magnetite) |
Prefer Intel? See the Dell Pro 14 PC14250 configurations.
Datasheet & Downloads
| Product brochure | Dell Pro 14 / 16 AMD laptop product brochure (PDF) |
| Manuals & drivers | Dell Pro 14 PC14255 manuals on Dell Support |
| Dell product page | Dell Pro 14 (AMD) on dell.com Singapore |
Need a PDF sent directly? Email sales@sourceit.com.sg quoting PC14255.
Frequently Asked Questions — Dell PC14255
Can the memory be upgraded?
Yes. The PC14255 has two DDR5 SO-DIMM slots and supports up to 64GB. This configuration ships with 16GB.
Does it have an Ethernet port?
Yes. The PC14255 has a built-in RJ45 port (1GbE).
Can it charge over USB-C?
Yes. Both USB-C ports support Power Delivery; the laptop also has a 4.5 mm barrel power input.
Is it a Copilot+ PC?
No. Copilot+ PC configurations of the PC14255 use Ryzen AI 300 series processors, such as the Ryzen AI 5 PRO 340.
Does it have AMD PRO business features?
No. The Ryzen 5 220 is not a PRO-series processor; for AMD's commercial PRO line choose the Ryzen 5 PRO 230 or Ryzen AI 5 PRO 340 configuration.
Which display, camera and battery does this configuration have?
These depend on the supplied distributor SKU. Email sales@sourceit.com.sg quoting 210-BQQD / 6758936 and we will confirm before you order.
What warranty do I get?
3 years per the distributor configuration, supplied locally by SourceIT with a GST invoice.
