ATEN VC925 DisplayPort to VGA Adapter
PRODUCT DESCRIPTION
ATEN VC925 DisplayPort to VGA Adapter - 2 Years Local Warranty
Connect a DisplayPort PC to a VGA Display
The ATEN VC925 converts the DisplayPort output of a desktop, workstation or notebook into VGA, so you can keep using VGA monitors, projectors and meeting-room displays that would otherwise need replacing.
Sharp Output up to 1920 x 1200
VGA output supports VGA, SVGA, XGA, SXGA and UXGA modes with resolutions up to 1920 x 1200 on PC displays and 1080p on HDTVs, with a 165 MHz maximum pixel clock.
Plug-and-Play, No Drivers
DisplayPort 1.2 compliant, the VC925 needs no software or driver installation. Plug the DisplayPort male connector into the computer and your VGA cable into the HDB-15 female port.
Compact and Light
At just 0.04 kg with a plastic housing, the adapter is easy to keep in a laptop bag, meeting-room drawer or IT spares kit.
Equipping a fleet of PCs or meeting rooms with VGA adapters? Email sales@sourceit.com.sg for volume pricing.
ATEN VC925 Datasheet — Technical Specifications
General
| Product Name | ATEN DisplayPort to VGA Adapter |
| Model | VC925 |
| Order Code | VC925-AT |
| Local Warranty (Singapore) | 2 years carry-in warranty |
Connectors
| Video Input | 1 x DisplayPort Male (White) |
| Video Output | 1 x HDB-15 (VGA) Female (Blue) |
| Audio Output | N/A |
Video
| Max. Pixel Clock | 165 MHz |
| Max. Input Resolution | Up to 4096 x 2160 @ 60Hz (4:4:4) |
| Max. Output Resolution | Up to 1920 x 1200 (PC) / 1080p (HDTV) |
| Supported Modes | VGA, SVGA, XGA, SXGA, UXGA |
| Compliance | DisplayPort 1.2 |
Environmental
| Operating Temperature | 0–50 °C |
| Storage Temperature | -20–60 °C |
| Humidity | 0–80% RH, non-condensing |
Physical
| Housing | Plastic |
| Weight | 0.04 kg |
| Dimensions (L x W x H) | 18.00 x 4.50 x 1.50 cm |
Compatibility & Applications
Typical Sources and Displays
Desktops, workstations and notebooks with a full-size DisplayPort output, connected to VGA monitors, projectors or older meeting-room screens.
Typical Use
Keeping existing VGA projectors and monitors in service after a PC refresh, classrooms, training rooms and hot desks.
Selection Tip
The VC925 carries video only (no audio). For a computer with Mini DisplayPort choose the VC920; for an HDMI display choose the VC985 or VC986B.
Package Contents & ATEN Video Adapter Ordering Information
In the Box
1 x VC925 DisplayPort to VGA Adapter.
ATEN Video Adapter Models
| Model | Key feature |
| VC925 (this listing) | DisplayPort to VGA adapter |
| VC920 | Mini DisplayPort to VGA adapter |
| VC965 | DisplayPort to DVI adapter |
| VC985 | DisplayPort to HDMI adapter |
| VC986B | DisplayPort to True 4K HDMI active adapter |
| VC810 | HDMI to VGA adapter |
| UC3002A | USB-C to VGA adapter |
Datasheet & Downloads
| VC925 datasheet | VC925 / VC965 / VC985 Datasheet (PDF) |
| Quick start guide | VC925 / VC985 Quick Start Guide (PDF) |
| ATEN product page | VC925 on aten.com |
Need a PDF sent directly? Email sales@sourceit.com.sg quoting VC925-AT.
Frequently Asked Questions — ATEN VC925
Does the VC925 carry audio?
No. It converts DisplayPort video to VGA only; audio output is not supported.
What is the maximum resolution?
Up to 1920 x 1200 on a PC monitor, or 1080p on an HDTV.
Do I need drivers?
No. The adapter is plug-and-play with no software or driver installation.
Will it work with a Mini DisplayPort laptop?
The VC925 has a full-size DisplayPort male plug. For Mini DisplayPort, the ATEN VC920 is the matching adapter.
What warranty do I get?
2 years local carry-in warranty. Supplied by SourceIT with a GST invoice.
