ASUS ExpertCenter PN53-S1 Mini-PC Ryzen 7 7730U/ 16GB/ 512GB SSD WiFi 6E Win11 Pro

General

Processor & Graphics

Memory & Storage

Connectivity

Ports & I/O

Physical & Environmental

Power

Display and Video Output Compatibility

Two USB Type-C ports (front and rear) both carry DisplayPort 1.4, alongside a fixed HDMI 2.1 output and a rear configurable port that can be set to a second DisplayPort output, VGA or a second LAN. A USB-C to DisplayPort or HDMI cable is needed where the connected monitor has no native USB-C input; a straight HDMI cable covers the fixed HDMI port directly.

Storage Configuration

The PN53-S1 chassis is a multi-storage design: the primary 512 GB M.2 PCIe 3.0 NVMe SSD runs the operating system, and a separate 2.5-inch SATA HDD bay (drive not included, up to 1 TB) is available for adding bulk local storage without touching the boot drive. This is a genuine differentiator from the newer PN54/PN55/PN65 ranges, which do not carry a 2.5-inch bay.

VESA Mount and Desk Placement

A lockable VESA mounting bracket is available as an optional accessory, letting the unit be fixed to the back of a compatible monitor and physically secured against removal — a relevant feature for a shared or public-facing desk. At 115 x 115 x 49 mm it also sits comfortably on a desk where a VESA mount is not required.

Peripheral and Accessory Compatibility

The front and rear USB 3.2 Type-A and Type-C ports handle everyday peripherals — a USB keyboard, mouse, webcam or external drive — without needing awkward cable routing. Because the PN53-S1 has a free 2.5-inch SATA bay, an off-the-shelf 2.5-inch HDD or SSD can be fitted internally rather than relying on an external USB drive for extra storage, which keeps a shared or public-facing desk tidier and reduces the number of exposed cables and connectors.

In the Box

AC power adapter, power cord, screw pack, user manual and warranty card. Keyboard, mouse and the lockable VESA mount bracket are available as optional accessories and are not included as standard.

ASUS ExpertCenter PN-Series Mini-PC Range — Ordering Information

All six models above are current ASUS ExpertCenter Mini-PC configurations carried by SourceIT. Email sales@sourceit.com.sg quoting the part number to check stock and lead time.

ASUS hosts the official product and specification pages for this model. The links below are ASUS's current product and specification pages for this model, confirmed as the PN53-S1 variant that lists the Ryzen 7 7730U processor.

For the PDF datasheet, user manual or driver downloads, email sales@sourceit.com.sg quoting PN53-S1-S70020AD and we will send you the current files directly.

Is this a complete system or a barebone unit?

Complete system. The PN53-S1-S70020AD ships with the AMD Ryzen 7 7730U processor, 16 GB DDR4 memory and a 512 GB PCIe 3.0 NVMe SSD already fitted, with Windows 11 Pro preinstalled.

What is the difference between the "PN53-S1" and the plain "PN53" family?

The PN53-S1 is a distinct family from the standard PN53, with its own processor line-up (Ryzen 7000-series U-suffix mobile parts, including this Ryzen 7 7730U) rather than the Ryzen 7735HS/6800H used in the non-S1 PN53. Always order by the full part number, PN53-S1-S70020AD, to be sure of getting this exact configuration.

Can I add a second storage drive?

Yes. In addition to the 512 GB M.2 NVMe boot SSD, the chassis has a 2.5-inch SATA HDD bay (drive not included, up to 1 TB) for extra local storage — a feature the newer PN54/PN55/PN65 ranges do not carry.

Does it support Wi-Fi 6E or Wi-Fi 7?

This configuration is Wi-Fi 6E with Bluetooth 5.4, one generation behind the Wi-Fi 7 fitted to the PN54/PN55/PN65 ranges in our catalogue. If Wi-Fi 7 matters for your deployment, ask us about those ranges instead.

How many monitors can it drive?

Up to four displays using the front and rear USB-C DisplayPort 1.4 outputs, the fixed HDMI 2.1 port and the configurable rear port set to a second DisplayPort or LAN.

Is the VESA mount included?

No, it is available as an optional accessory. ASUS describes it as a lockable VESA mount, letting the unit be physically secured to a monitor arm or wall bracket — relevant for shared or public-facing deployments.

What does "onsite" warranty mean in practice in Singapore?

An onsite warranty means a qualifying hardware fault is diagnosed and repaired at your premises by an authorised technician, rather than requiring you to ship the unit back to a service centre and wait for a return. SourceIT coordinates the onsite claim on your behalf as part of the local support that comes with every unit we supply.

Does it come with a Singapore warranty and a GST invoice?

Yes. Every ASUS ExpertCenter PN53-S1-S70020AD sold by SourceIT comes with local Singapore support and a GST invoice; ASUS backs this model with a 3-year onsite warranty.
