AOC CS25G 24.5" Full HD Fast IPS 310Hz Gaming Monitor with G-SYNC Compatible
PRODUCT DESCRIPTION
AOC CS25G 24.5" Full HD Fast IPS 310Hz Gaming Monitor with G-SYNC Compatible - 3 years parts & labour warranty
310 Hz for competitive play
A 24.5" Full HD Fast IPS panel with a 310 Hz refresh rate as advertised by AOC, 1 ms GtG and 0.3 ms MPRT response, Low Input Lag, CS Mode and MBR Sync.
G-SYNC Compatible
NVIDIA G-SYNC Compatible variable refresh keeps gameplay smooth and tear-free with compatible graphics cards.
DisplayHDR 400 colour
VESA DisplayHDR 400 with 400-nit peak brightness per AOC, NTSC 100% / sRGB 117% / DCI-P3 91% colour gamut, 1.07 billion colours and Delta E < 2 accuracy.
Ergonomic stand
130 mm height adjustment, -5° to 23° tilt, ±30° swivel and ±90° pivot, plus 100 x 100 VESA mounting and Flicker Free backlight.
Need monitors for a whole office, classroom or gaming room? Email sales@sourceit.com.sg for volume pricing and delivery lead time.
AOC CS25G Datasheet — Technical Specifications
General
| Product Name | AOC CS25G 24.5" Full HD Fast IPS 310Hz Gaming Monitor with G-SYNC Compatible |
| Model | CS25G |
| Brand / Series | AOC GAMING |
| Local Warranty (Singapore) | 3 years parts & labour warranty (AOC Singapore, serviced by MPGS Singapore) |
| EAN | 6973985233128 |
Display
| Screen size | 24.5 inch |
| Panel type | Fast IPS |
| Backlight type | WLED |
| Resolution | Full HD (FHD) |
| Aspect ratio | 16:9 |
| Max refresh rate | 310 Hz (as advertised by AOC; not listed in the datasheet table) |
| Response time | 1 ms GtG / 0.3 ms MPRT |
| Brightness | 350 cd/m² (datasheet); 400 cd/m² peak (HDR) per AOC product description |
| Static contrast ratio | 1000:1 |
| Dynamic contrast ratio | MEGA DCR |
| Viewing angle (CR10) | 178/178 |
| Display colours | 1.07 Billion |
| Colour gamut | NTSC 100% (CIE1976) / sRGB 117% (CIE1931) / DCI-P3 91% (CIE1976) |
| Pixel pitch | 0.2832 mm |
| Display viewing area | 543.744 (H) × 302.616 (V) mm |
Video Features
| Sync technology (VRR) | NVIDIA G-SYNC Compatible |
| HDR | VESA DisplayHDR 400 (per AOC product description) |
| Colour accuracy | Delta E < 2 |
Connectivity
| HDMI | HDMI 2.0 x 2 |
| DisplayPort | DisplayPort 1.4 x 1 |
| HDCP | HDCP 2.3 (HDMI and DisplayPort) |
| Audio output | Headphone out (3.5mm) |
Ergonomics & Cabinet
| Height adjust | 130 mm |
| Tilt | -5° / 23° |
| Swivel | -30° / 30° |
| Pivot | -90° / 90° |
| VESA wall mount | 100 x 100 |
| Cabinet colour (back) | Black, Gold |
Power
| Power supply | Internal |
| Power source | 100 - 240V～1.5A, 50 / 60Hz |
| Power consumption on (typical) | 30.0 W |
Dimensions & Weight
| Product incl. base (WxHxD) | 560.1 × 380.6~498.5 × 207.6 mm |
| Product excl. base (WxHxD) | 560.1 × 324.8 × 52.1 mm |
| Packaging (WxHxD) | 780 × 481 × 162 mm |
| Gross weight incl. package | 8.15 kg |
| Net weight excl. package | 4.63 kg |
| Product without stand | 2.81 kg |
Specifications per AOC's official CS25G datasheet on aoc.com (Singapore).
Compatibility & Connectivity
Video Inputs
HDMI 2.0 x 2 and DisplayPort 1.4 x 1. Use DisplayPort 1.4 from your graphics card for the full refresh rate; HDMI 2.0 suits consoles and laptops.
Graphics Cards
NVIDIA G-SYNC Compatible with compatible NVIDIA graphics cards.
Mounting
VESA 100 x 100 mm compatible for monitor arms and wall brackets.
Package Contents & AOC Gaming Monitors Ordering Information
In the Box
CS25G monitor with stand, power cable, signal cable and quick start guide. Cable types vary by AOC Singapore pack — email us to confirm before ordering.
AOC Gaming Monitors
| Model | Key feature |
| 24G4ZR | 23.8", FHD, Fast IPS, 260Hz(OC), HDR10 |
| CS24A/P | 24.1", FHD, E-Sport TN, 610Hz, HDR400 |
| 25G4S | 24.5", FHD, Fast IPS, 310Hz, HDR400 |
| 25G4K | 24.5", FHD, Fast IPS, 420Hz, HDR400 |
| Q25G4S | 24.5", QHD, Fast IPS, 320Hz, HDR400 |
| CS25G (this listing) | 24.5", FHD, Fast IPS, 310Hz(OC), HDR400 |
| AG276FK | 27", FHD, Fast IPS, 520Hz, HDR400 |
| U27G4 | 27", Dual: FHD-320Hz, UHD-160Hz, Fast IPS, HDR400 |
| CQ27G4S | 27", Dual: HD-400Hz OC, QHD-320Hz OC, Curved 1500R, Fast VA, HDR400 |
| 27G4H | 27", FHD, Fast IPS, 200Hz, HDR10 |
| 27G11ZE2 | 27", FHD, Fast IPS, 240Hz, HDR10 |
| 27G4ZR | 27", FHD, Fast IPS, 260Hz(OC), HDR10 |
| AG275QXW | 27", QHD, Fast IPS, 180Hz, HDR400, White |
| Q27G4/D | 27", QHD, Fast IPS, 200Hz, HDR400 |
| Q27G4/WS | 27", QHD, Fast IPS, 200Hz, HDR400, White |
| Q27G4S | 27", QHD, Fast IPS, 300Hz, HDR400 |
| Q27G4SL/WS | 27", QHD, Fast IPS, 320Hz, HDR400, White |
| Q27G4XY | 27", QHD, Fast VA, 180Hz, HDR400, USB-C 65W, Google Smart OS |
| Q27B36X | 27", QHD, IPS, 144Hz, HDR10 |
| U27G4XM | 27", Dual: FHD-320Hz, UHD-160Hz, Mini-LED, Fast IPS, HDR1000 |
| AG275UXM | 27", UHD, Mini-LED (QD), Fast IPS, 165Hz, HDR1000 |
| U32G4 | 31.5", Dual: FHD-320Hz, UHD-160Hz, Fast IPS, HDR400 |
| AGP327UZD | 31.5", Dual: FHD-480Hz, UHD-240Hz, W-OLED, HDR400, USB-C 65W |
| CQ32G4 | 31.5", QHD, Curved 1500R, Fast VA, 180Hz, HDR10 |
| Q32V5E | 31.5", QHD, IPS, 100Hz, HDR10 |
| U32G4ZMN | 31.5", UHD, Mini-LED, Fast VA, 165Hz |
| CU34G4Z | 34", WQHD, Curved 1500R, Fast VA, 240Hz, HDR400 |
| AG344UXM | 34", WQHD, Mini-LED (QD), 170Hz, HDR1000, USB-C 90W |
| AG493UCX2 | 49", DQHD, Curved 1800R, VA, SuperWide 32:9, 165Hz, HDR400 |
Datasheet & Downloads
| AOC product page | CS25G on aoc.com |
| Product leaflet (PDF) | CS25G Product leaflet (PDF) |
| User manual (PDF) | CS25G User manual (PDF) |
Need a PDF sent directly? Email sales@sourceit.com.sg quoting CS25G.
Frequently Asked Questions — AOC CS25G
What refresh rate does the CS25G support?
AOC advertises 310 Hz at Full HD, with 1 ms GtG and 0.3 ms MPRT response time.
Does it support G-SYNC?
Yes, it is NVIDIA G-SYNC Compatible.
Is the stand adjustable?
Yes: 130 mm height adjustment, -5° to 23° tilt, ±30° swivel and ±90° pivot.
Can I wall-mount it?
Yes, it supports 100 x 100 mm VESA mounting.
What warranty do I get?
3 years parts & labour warranty (AOC Singapore, serviced by MPGS Singapore). Supplied by SourceIT with a GST invoice.
