AOC 25B36X 24.5" Full HD IPS 144Hz Gaming Monitor with Adaptive Sync & HDR10
PRODUCT DESCRIPTION
AOC 25B36X 24.5" Full HD IPS 144Hz Gaming Monitor with Adaptive Sync & HDR10 - 3 years parts & labour warranty
Built for speed and accuracy
A 24.5" Full HD (1920 x 1080) IPS panel with a 144 Hz refresh rate and 0.5 ms MPRT (4 ms GtG) response for ultra-smooth visuals.
Adaptive Sync and Motion Blur Reduction
Adaptive Sync eliminates tearing, Motion Blur Reduction (MBR) sharpens fast-moving scenes and Game Mode optimises performance.
HDR10 and vibrant IPS colour
HDR10 support, 300 cd/m² brightness, 1500:1 static contrast and NTSC 102% (CIE1976) / sRGB 119% (CIE1931) colour gamut.
Eye comfort and flexible setup
Flicker-Free and Low Blue Light reduce eye strain, while the ultra-narrow bezel, -5° to 23° tilt and 100 x 100 VESA mount offer a flexible setup.
Need monitors for a whole office, classroom or gaming room? Email sales@sourceit.com.sg for volume pricing and delivery lead time.
AOC 25B36X Datasheet — Technical Specifications
General
| Product Name | AOC 25B36X 24.5" Full HD IPS 144Hz Gaming Monitor with Adaptive Sync & HDR10 |
| Model | 25B36X |
| Brand / Series | AOC Basic-line B36 series |
| Local Warranty (Singapore) | 3 years parts & labour warranty (AOC Singapore, serviced by MPGS Singapore) |
Display
| Screen size | 24.5 inch, flat |
| Panel type | IPS |
| Panel resolution | 1920 x 1080 (FHD) |
| Aspect ratio | 16:9 |
| Max refresh rate | 144 Hz |
| Response time | 4 ms GtG / 0.5 ms MPRT |
| Brightness | 300 cd/m² |
| Static contrast ratio | 1500:1 |
| Dynamic contrast ratio | MEGA DCR |
| Viewing angle (CR10) | 178/178 |
| Display colours | 16.7 Million |
| Colour gamut | NTSC 102% (CIE1976) / sRGB 119% (CIE1931) |
| Pixel pitch | 0.2832 mm |
| Display viewing area | 543.744 (H) × 302.616 (V) mm |
Video Features
| Sync technology (VRR) | Adaptive Sync |
| HDR | HDR 10 |
| Flicker-Free | Flicker Free |
| Blue light technology | Low Blue Light |
Connectivity
| HDMI | HDMI 1.4 x 1 |
| DisplayPort | DisplayPort 1.4 x 1 |
| Audio output | Headphone out (3.5mm) |
Ergonomics & Cabinet
| Tilt | -5° ~ 23° |
| VESA wall mount | 100 x 100 |
| Bezel colour / finish (front) | Black / Texture |
| Cabinet colour / finish (back) | Black / Texture |
Power
| Power supply | External |
| Power source | 19VDC, 2.0A |
| Power consumption on (typical) | 16.0 W |
Dimensions & Weight
| Product incl. base (WxHxD) | 561.6 × 420.1 × 197.9 mm |
| Product excl. base (WxHxD) | 561.6 × 325.1 × 34.9 mm |
| Packaging (WxHxD) | 640 × 460 × 112 mm |
| Gross weight incl. package | 4.72 kg |
| Net weight excl. package | 2.55 kg |
| Product without stand | 2.26 kg |
Other
| Operating system | Windows 10/11 |
Specifications per AOC's official 25B36X datasheet on aoc.com (sg).
Compatibility & Connectivity
Video Inputs
HDMI 1.4 x 1 and DisplayPort 1.4 x 1; check the AOC user manual for the refresh rates supported on each input.
Graphics Cards
Adaptive Sync works with compatible graphics cards to reduce tearing and stutter.
Operating Systems
Windows 10/11.
Mounting
VESA 100 x 100 mm compatible for monitor arms and wall brackets.
Package Contents & AOC Business & Office Monitors Ordering Information
In the Box
25B36X monitor with stand, power adapter, signal cable and quick start guide. Cable types vary by AOC Singapore pack — email us to confirm before ordering.
AOC Business & Office Monitors
| Model | Key feature |
| 16T20 | 15.6”, FHD, IPS, 60Hz, Portable, 2x USB-C, Foldable Smart Cover & Stand |
| 25B36X (this listing) | 24.5", FHD, IPS, 144Hz, HDR10 |
| 27B36X | 27", FHD, IPS, 144Hz, HDR10 |
| Q27P4C | 27", QHD, IPS, 120Hz, USB-C 96W, USB Hub+USB-C 15W, KVM |
| Q27P3CV | 27", QHD, IPS, 100Hz, USB-C 65W |
| U27P4C | 27", UHD, IPS, 60Hz, USB-C 96W, USB Hub+USB-C 15W, KVM |
| Q32P4C | 31.5", QHD, IPS, 100Hz, USB-C 96W, USB Hub+USB-C 15W, KVM |
| U32P4C | 31.5", UHD, IPS, 60Hz, USB-C, USB Hub+USB-C 15W, KVM |
| CU34P3CV | 34", WQHD, Curved 1500R, VA, 100Hz, USB-C PD65W, KVM |
Datasheet & Downloads
| AOC product page | 25B36X on aoc.com |
| Product leaflet (PDF) | 25B36X Product leaflet (PDF) |
| User manual (PDF) | 25B36X User manual (PDF) |
Need a PDF sent directly? Email sales@sourceit.com.sg quoting 25B36X.
Frequently Asked Questions — AOC 25B36X
What refresh rate does the 25B36X support?
Up to 144 Hz at 1920 x 1080, with 0.5 ms MPRT and 4 ms GtG response time.
Is the stand adjustable?
The stand tilts from -5° to 23°. For height or swivel adjustment, mount it on a VESA 100 x 100 monitor arm.
Does it have built-in speakers?
No, it has a 3.5 mm headphone output for headphones or external speakers.
Can I wall-mount it?
Yes, it supports 100 x 100 mm VESA mounting.
What warranty do I get?
3 years parts & labour warranty (AOC Singapore, serviced by MPGS Singapore). Supplied by SourceIT with a GST invoice.
