AOC 16T20 15.6" Full HD IPS Portable Monitor with USB-C and Mini HDMI
PRODUCT DESCRIPTION
AOC 16T20 15.6" Full HD IPS Portable Monitor with USB-C and Mini HDMI - 3 years parts & labour warranty
Full HD on the go
A 15.6" Full HD (1920 x 1080) IPS panel with 178/178° wide viewing angles that keeps image quality and colours consistent from all viewing positions.
USB-C and Mini HDMI
Two USB-C ports and a Mini HDMI 2.0 input, plus a 3.5 mm headphone output, for connecting laptops and other devices.
Slim, light and protected
Just 9.6 mm thin and 0.7 kg, with a metal back and a Smart Cover that doubles as a tilt stand.
Built-in speakers
1 W x 2 speakers and a Flicker Free backlight for comfortable work anywhere.
Need monitors for a whole office, classroom or gaming room? Email sales@sourceit.com.sg for volume pricing and delivery lead time.
AOC 16T20 Datasheet — Technical Specifications
General
| Product Name | AOC 16T20 15.6" Full HD IPS Portable Monitor with USB-C and Mini HDMI |
| Model | 16T20 |
| Brand / Series | AOC 16T series |
| Local Warranty (Singapore) | 3 years parts & labour warranty (AOC Singapore, serviced by MPGS Singapore) |
| EAN | 6973985233098 |
Display
| Screen size | 15.6 inch, flat |
| Panel type | IPS |
| Panel resolution | 1920 x 1080 (FHD) |
| Aspect ratio | 16:9 |
| Max refresh rate | 60 Hz |
| Response time | 4 ms GtG |
| Brightness | 250 cd/m² |
| Static contrast ratio | 800:1 |
| Viewing angle (CR10) | 178/178 |
| Display colours | 262 K |
| Pixel pitch | 0.1793 mm |
| Display viewing area | 344.16 (H) × 193.59 (V) mm |
Video Features
| Flicker-Free | Flicker Free |
Connectivity
| USB-C | USB-C x 2 |
| HDMI | Mini HDMI 2.0 x 1 |
| Audio output | Headphone out (3.5mm) |
Audio
| Speakers | 1 W x 2 |
Ergonomics & Cabinet
| Tilt | via Smart Cover |
| Bezel colour / finish (front) | Black / Texture |
| Cabinet colour / finish (back) | Black / Metal |
Power
| Power supply | Internal |
| Power consumption on (typical) | 10.0 W |
| Power consumption on (maximum) | 15.0 W |
| Standby / off | 0.5 W / 0.3 W |
Dimensions & Weight
| Product (WxHxD) | 354.2 × 222.4 × 9.6 mm |
| Packaging (WxHxD) | 453 × 86 × 295 mm |
| Gross weight incl. package | 1.7 kg |
| Net weight excl. package | 1.1 kg |
| Product without stand | 0.7 kg |
Specifications per AOC's official 16T20 datasheet on aoc.com (Singapore).
Compatibility & Connectivity
Video Inputs
Two USB-C ports and one Mini HDMI 2.0 input. For single-cable USB-C connection, your laptop or device's USB-C port must support video output.
USB-C Laptops
Connect a USB-C laptop directly, or use Mini HDMI for laptops, consoles and other HDMI sources.
Stand
The included Smart Cover protects the screen and folds into a tilt stand; there is no VESA mount.
Package Contents & AOC Business & Office Monitors Ordering Information
In the Box
16T20 portable monitor with Smart Cover, cables and quick start guide. Cable types vary by AOC Singapore pack — email us to confirm before ordering.
AOC Business & Office Monitors
| Model | Key feature |
| 16T20 (this listing) | 15.6”, FHD, IPS, 60Hz, Portable, 2x USB-C, Foldable Smart Cover & Stand |
| 25B36X | 24.5", FHD, IPS, 144Hz, HDR10 |
| 27B36X | 27", FHD, IPS, 144Hz, HDR10 |
| Q27P4C | 27", QHD, IPS, 120Hz, USB-C 96W, USB Hub+USB-C 15W, KVM |
| Q27P3CV | 27", QHD, IPS, 100Hz, USB-C 65W |
| U27P4C | 27", UHD, IPS, 60Hz, USB-C 96W, USB Hub+USB-C 15W, KVM |
| Q32P4C | 31.5", QHD, IPS, 100Hz, USB-C 96W, USB Hub+USB-C 15W, KVM |
| U32P4C | 31.5", UHD, IPS, 60Hz, USB-C, USB Hub+USB-C 15W, KVM |
| CU34P3CV | 34", WQHD, Curved 1500R, VA, 100Hz, USB-C PD65W, KVM |
Datasheet & Downloads
| AOC product page | 16T20 on aoc.com |
| Product leaflet (PDF) | 16T20 Product leaflet (PDF) |
Need a PDF sent directly? Email sales@sourceit.com.sg quoting 16T20.
Frequently Asked Questions — AOC 16T20
What resolution does the 16T20 have?
15.6" Full HD 1920 x 1080 IPS at 60 Hz, with 250 cd/m² brightness.
How do I connect it?
Via either of its two USB-C ports or the Mini HDMI 2.0 input.
Does it have built-in speakers?
Yes, 1 W x 2 speakers, plus a 3.5 mm headphone output.
How does it stand up?
The Smart Cover folds into a stand and sets the tilt angle.
What warranty do I get?
3 years parts & labour warranty (AOC Singapore, serviced by MPGS Singapore). Supplied by SourceIT with a GST invoice.
