Zebra TC53e Wi-Fi Android Mobile Computer, 6" FHD+, 6GB/64GB, SE4720 1D/2D Scanner
PRODUCT DESCRIPTION
Zebra TC530E-0T1E1B1000-A6 TC53e Wi-Fi Android Mobile Computer with SE4720 Scanner, 6GB/64GB
Next-generation TC5 platform
Qualcomm 4490 octa-core processor and Wi-Fi 6E for fast apps and reliable coverage on busy store and warehouse networks.
Built for every shift
IP68/IP65 sealing and drop ratings up to 2.4 m with boot, plus 1,000 tumbles.
Scan with confidence
SE4720 1D/2D imager with dual scan buttons and trigger-handle support.
Power for the whole day
PowerPrecision+ 4,680 mAh battery with Warm Swap, fast charging and optional 7,000 mAh extended pack.
Zebra TC53e Datasheet — Technical Specifications
General
| Product Name | Zebra TC53e Mobile Computer |
| Part Number | TC530E-0T1E1B1000-A6 |
| Series | Zebra TC53e / TC58e |
| Dimensions | 164.8 mm L x 77.35 mm W x 16.75 mm H |
| Weight | 282 g with standard battery |
| Manufacturer Warranty | 1 year (Zebra hardware warranty) |
Performance
| CPU | Qualcomm 4490 Kryo octa-core, 2.4 GHz |
| Memory | 6 GB RAM / 64 GB UFS Flash |
| Expansion | MicroSD up to 2 TB |
| Operating System | Android (upgradable to Android 17 per distributor) |
| Display | 6.0" FHD+ 1080 x 2160, 600 nits, Gorilla Glass |
| Battery | 4,680 mAh PowerPrecision+; 7,000 mAh extended optional |
Data Capture
| Scan Engine | SE4720 1D/2D imager |
| Cameras | Rear 16 MP autofocus with flash; front 8 MP |
Wireless
| WLAN | Wi-Fi 6E (802.11ax), 2x2 MU-MIMO |
| Bluetooth | Bluetooth 5.3, BLE |
| GNSS | GPS, GLONASS, Galileo, BeiDou, QZSS |
| WWAN | None (Wi-Fi model) |
Rugged
| Operating Temperature | -20°C to 50°C |
| Drop | 2.4 m to concrete with boot; 1.8 m to tile over concrete (MIL-STD-810H) |
| Tumble | 1,000 at 0.5 m |
| Sealing | IP68 and IP65 |
Compatibility & Connectivity
Ports
USB-C 3.1 (host and client) plus Back I/O for trigger handle and accessories.
Accessories
Compatible with the TC5x accessory family: cradles, trigger handle, boots, holsters and RFD40/RFD90 RFID sleds.
Software
Zebra Mobility DNA, DataWedge and major EMM/MDM platforms; Android Enterprise Recommended.
Package Contents & Zebra TC5x Ordering Information
In the Box
TC53e mobile computer with battery. Cradles and chargers sold separately.
Zebra TC5x Models at SourceIT
| Model | Key feature |
| TC530E-0T1E1B1000-A6 (this listing) | TC53e Wi-Fi, 6/64 GB, SE4720 |
| TC58BE-3T1E1B1A80-A6 | TC58e 5G, 6/64 GB, SE4720 |
| TC5301-0T1E4B1000-A6 | TC53 Wi-Fi, 4/64 GB, SE4720 |
Datasheet & Downloads
| Zebra product page | TC53e on zebra.com |
| Specification sheet | TC53e/TC58e spec sheet |
Frequently Asked Questions — Zebra TC53e
TC53e or TC58e?
The TC53e is Wi-Fi only; the TC58e adds 5G cellular for use outside your premises.
Can I add RFID?
Yes, with an RFD40 or RFD90 sled and the TC5x eConnex adapter.
What warranty do I get?
Zebra warrants the TC53e for 1 year from shipment; Zebra OneCare plans available.
