Zebra DS3678-SR Ultra-Rugged Cordless 1D/2D Barcode Scanner Kit, Bluetooth, Industrial Green
PRODUCT DESCRIPTION
Zebra DS3678-SR3U4210SFW DS3678-SR Ultra-Rugged Cordless 1D/2D Barcode Scanner Kit
Ultra-rugged by design
Survives multiple 3 m drops to concrete, 7,500 tumbles and IP65/IP68 sealing for warehouses, cold rooms and production floors.
Scan it all at speed
Reads 1D and 2D barcodes, including damaged or poorly printed codes, and up to 20 barcodes with one trigger pull.
Cordless freedom
Class 1 Bluetooth with a range of up to 100 m line of sight and Wi-Fi Friendly Mode to avoid interference.
Full-shift battery
PowerPrecision+ 3100 mAh battery delivers more than 100,000 scans per charge.
Zebra DS3678-SR Datasheet — Technical Specifications
General
| Product Name | Zebra DS3678-SR Ultra-Rugged Cordless Scanner Kit |
| Part Number | DS3678-SR3U4210SFW |
| Series | Zebra DS3600 Series (standard range) |
| Colour | Industrial Green |
| Dimensions | 18.5 cm H x 7.6 cm W x 14.2 cm D |
| Weight | 407 g |
| Manufacturer Warranty | Scanner and cradle 3 years; battery 1 year (Zebra) |
Performance
| Image Sensor | 1,280 x 800 pixels |
| Field of View | 42° H x 28° V |
| Illumination / Aimer | 660 nm LED / 610 nm LED |
| Skew / Pitch / Roll | ±60° / ±60° / 360° |
| Symbologies | 1D: Code 39, Code 128, Code 93, Codabar, UPC/EAN, I 2 of 5, GS1 DataBar and more; 2D: PDF417, QR, Micro QR, DataMatrix, Aztec, MaxiCode, Han Xin, Postal; Digimarc |
| Decode Range | Code 128 20 mil: 7.1 to 71.1 cm; DataMatrix 10 mil: 3.5 to 21.8 cm |
| User Indicators | Direct decode indicator, LEDs, beeper, vibration |
Wireless & Battery
| Bluetooth | Class 1, Bluetooth 4.0 (LE), SPP and HID profiles |
| Radio Range | Minimum 100 m line of sight (Class 1) |
| Battery | PowerPrecision+ 3100 mAh Li-Ion |
| Scans per Charge | 100,000+ |
| Host Interfaces (via cradle) | USB, RS232, Keyboard Wedge; Industrial Ethernet options |
Rugged
| Operating Temperature | -20°C to 50°C (cordless) |
| Storage Temperature | -40°C to 70°C |
| Drop | Multiple 3.0 m drops at room temperature; 2.4 m from -20°C to 50°C |
| Tumble | 7,500 tumbles at 1.0 m |
| Sealing | Scanner IP65 and IP68; cradle IP65 |
Compatibility & Connectivity
Host Connection
Pairs with its cradle connected to a PC by USB, or directly by Bluetooth to tablets, mobile computers and vehicle terminals (HID or SPP).
Industrial Ethernet
Network Connect lets DS3600 cradles join EtherNet/IP, Profinet, Modbus TCP and standard TCP/IP networks without converters.
Management
123Scan, Scanner SDK and Scanner Management Service for configuration, firmware and asset tracking.
Package Contents & Zebra DS3600 Series Ordering Information
In the Box
Zebra DS3678-SR cordless scanner kit, part number DS3678-SR3U4210SFW. Contact us to confirm cradle, cable and power supply contents for your installation.
Zebra DS3600 Series
| Model | Key feature |
| DS3678-SR (this listing) | Cordless, standard range 1D/2D |
| DS3608-SR | Corded, standard range 1D/2D |
| DS3678-ER | Cordless, extended range |
| DS3678-HD / DP | High density / direct part marks |
| DS3678-KD | Keypad and colour display |
Datasheet & Downloads
| Zebra product page | DS3600 Series on zebra.com |
| Specification sheet | DS3600-SR spec sheet |
Frequently Asked Questions — Zebra DS3678-SR
Can it be used in a freezer?
The cordless model operates from -20°C to 50°C; Zebra recommends a heated holder when moving in and out of freezers to reduce condensation.
Can it pair directly with a tablet?
Yes. It supports Bluetooth HID and SPP for direct pairing with tablets and mobile computers.
What warranty do I get?
Zebra warrants the scanner and cradle for 36 months and the battery for 12 months from shipment.
