Yealink CP965 SIP/UC IP Conference Phone
PRODUCT DESCRIPTION
Yealink CP965 Touch-Sensitive HD IP Conference Phone for SIP/UC (CP965 (SIP/UC)) - 1 Year Local Warranty
Flagship Audio for Medium Meeting Rooms
The Yealink CP965 is a touch-sensitive HD IP conference phone for medium meeting rooms. A built-in 12-microphone array picks up voices 360 degrees around the table at up to 6 metres, while a 5 W speaker delivers clear, full-duplex HD audio to everyone in the room.
Yealink Noise Proof Technology
Yealink Noise Proof Technology and Smart Noise Filtering suppress keyboard clicks, paper shuffling and other background noise, with a dedicated noise-cancellation microphone and echo cancellation up to 320 ms for natural conversations.
5-inch Touch Screen on Android 9.0
A 5-inch 720 x 1280 capacitive touch screen running Android 9.0 makes dialling, merging and managing up to 10-way conference calls simple. Built-in dual-band Wi-Fi, Bluetooth 4.2 and USB Type-A and Type-C ports connect laptops and mobiles for hybrid UC meetings.
Scalable Room Coverage
Add up to two expansion microphones, such as the Yealink CPW65 DECT wireless mic, to extend pickup for larger rooms, or connect the optional Yealink CPN10 for analogue PSTN calls.
Yealink CP965 (SIP/UC) Datasheet — Technical Specifications
| Model | Yealink CP965 (SIP/UC) |
| Part Number / SKU | CP965 (SIP/UC) |
| Product Type | Touch-sensitive HD IP conference phone |
| Warranty | 1 Year Local Warranty (Singapore) |
| Display | 5" 720 x 1280 capacitive touch screen |
| Operating System | Android 9.0 |
| Microphones | Built-in 12-microphone array for voice pickup; built-in 1-microphone array for noise cancellation |
| Pickup Range | 20-foot (6-metre), 360-degree voice pickup |
| Speaker | 56 mm diameter, 5 W speaker; 94 dB at 0.5 m peak volume |
| Audio Technology | Optimal HD audio, full-duplex; Yealink Noise Proof Technology; Smart Noise Filtering; echo cancellation tail length up to 320 ms |
| Audio Codecs | G.722, G.722.1C, G.726, G.729, G.729A, G.723, iLBC, PCMU, PCMA |
| Ethernet | 1 x RJ45 10/100M Ethernet port |
| PoE | Power over Ethernet (IEEE 802.3at), Class 4 |
| Wi-Fi | Built-in Wi-Fi (2.4GHz/5GHz, 802.11a/b/g/n) |
| Bluetooth | Built-in Bluetooth 4.2 |
| USB | 1 x USB 2.0 Type-A device port; 1 x USB 2.0 Type-C device port |
| Expansion | Up to two expansion microphones per CP965; PSTN via optional Yealink CPN10 for hybrid UC meetings |
| Protocols | SIP v1 (RFC2543), v2 (RFC3261) |
| Conferencing | 10-way conference call |
| Power Consumption (PoE) | 7.3 W – 20 W; optional Yealink PoE adapter YLPOE30 |
| Dimensions | 328 x 322 x 62 mm |
| Colour | Black |
| Operating Environment | -10 to +45 °C, 10–90% humidity |
Compatibility & Software Support
The CP965 (SIP/UC) edition is an open-SIP conference phone (SIP v1 RFC2543 and v2 RFC3261) for standards-based IP PBX and hosted voice platforms, with up to 10-way conference calls. Hybrid UC meetings are supported by connecting a PC or mobile over USB or Bluetooth, and the optional Yealink CPN10 adds analogue PSTN calling. Devices can be managed through Yealink's device management platform.
Package Contents & CP965 / CP Series Ordering Information
In the box: Yealink CP965 IP conference phone, Ethernet cable (7.5 m CAT5E UTP), M2x5 screw, screwdriver. PoE powered; the YLPOE30 PoE adapter is optional.
| Yealink CP965 Teams | CP965 Microsoft Teams edition, medium rooms |
| Yealink CP965-Wireless Mic Teams | CP965 Teams edition bundled with CPW65 wireless DECT expansion mics |
| Yealink CP965 Zoom | CP965 Zoom edition |
| Yealink CP965-Wireless Mic Zoom | CP965 Zoom edition bundled with CPW65 wireless DECT expansion mics |
| Yealink CP965 (SIP/UC) | CP965 open SIP / UC edition (this model) |
| Yealink CP965-Wireless Mic (SIP/UC) | CP965 SIP/UC edition bundled with CPW65 wireless DECT expansion mics |
| Yealink CP935W | Wireless DECT conference phone |
| Yealink CP935W-Base | CP935W with DECT base station |
| Yealink CP925 | Touch-screen IP conference phone, small-to-medium rooms |
Datasheet & Downloads
Frequently Asked Questions — Yealink CP965 (SIP/UC)
Is the CP965 screen a touch screen?
Yes. It has a 5-inch 720 x 1280 capacitive touch screen.
What is the voice pickup range?
The built-in 12-microphone array gives 20-foot (6-metre), 360-degree voice pickup.
Can the CP965 be powered by PoE?
Yes. It supports Power over Ethernet (IEEE 802.3at), Class 4. The Yealink YLPOE30 PoE adapter is optional.
How many expansion microphones can be added?
Up to two expansion microphones per CP965, such as the Yealink CPW65 DECT wireless mic.
Does the Yealink CP965 (SIP/UC) come with local warranty in Singapore?
Yes. Every CP965 (SIP/UC) sold by SourceIT comes with 1 year local Singapore warranty and a GST invoice.
